ABB CI851K01 3BSE018101R1 Profibus-DP Interface Module

Configured for Profibus-DP communication in ABB automation networks, the ABB CI851K01 3BSE018101R1 (CI851K01 Profibus-DP Interface Kit) provides direct physical and electrical execution for connecting field devices through a Profibus-DP interface.

Hardware Specifications

Parameter	Specification
Model	CI851K01 3BSE018101R1
Brand	ABB
Product Type	Communication Module
Protocol Type	Profibus-DP
Interface Function	Profibus-DP Interface Kit
Communication Speed	12000 kbit/s
Number of Channels	1
Origin	Sweden
Weight	0.3 kg
Dimensions	210 mm x 160 mm x 90 mm
Battery Quantity	0
Customs Tariff Number	85389091
Minimum Order Quantity	1 piece
Part Type	New

ABB Industrial Network Communication Characteristics

The CI851K01 interface module provides Profibus-DP communication between ABB controller systems and connected field-level devices. The module supports a communication speed up to 12000 kbit/s and operates through a single Profibus-DP channel.

Additionally, the module integrates into ABB control system architectures through the designated communication interface. Its firmware and hardware design support industrial network data exchange, while backplane bus communication velocity management maintains synchronized controller and I/O data transmission.

The Profibus-DP interface uses standard industrial network practices, including shielded cable routing, proper grounding, and controlled signal termination to maintain communication integrity.

Frequently Asked Questions

Q: What communication protocol does the CI851K01 support?
A: The CI851K01 supports the Profibus-DP protocol and provides one communication channel for industrial network connection.

Q: Does the CI851K01 include battery components?
A: No. The module specification lists the number of batteries as 0.

Q: What installation considerations apply to the CI851K01 communication interface?
A: Installation requires correct Profibus cable routing, shield grounding, and network termination according to the applicable Profibus installation guidelines.

Field Installation Guidelines

• Install the CI851K01 module in the designated ABB system position according to the controller hardware configuration.
• Verify that the Profibus-DP cable shielding connects correctly to the protective grounding system.
• Maintain separation between communication cables and high-voltage power wiring to reduce electromagnetic interference.
• Confirm Profibus network termination settings before commissioning.
• Inspect connector seating and mechanical mounting conditions before applying system power.
• Verify communication status through the ABB engineering configuration tools after installation.
