Description
Overview
The ABB AO810 3BSE008522R1 Analog Output Module delivers precise control and reliable performance in S800 I/O systems. Its rugged design ensures durability in harsh environments, while the compact dimensions simplify installation in space-constrained setups.
Technical Specifications
| Parameter |
Value |
| Model Number |
AO810 3BSE008522R1 |
| Manufacturer |
ABB |
| Module Type |
Analog Output Module |
| Product Range |
S800 I/O |
| Dimensions |
4.3 × 10.4 × 11.8 cm |
| Weight |
0.18 kg |
| Resolution |
12-bit |
| Accuracy |
±1% of full scale |
| Operating Temperature |
-25°C to +60°C |
| Voltage Range |
Wide adjustable output |
| Communication Service |
Ethernet router |
| System |
DCS |
| HS Code |
8537101190 |
| Origin |
Sweden |
| Condition |
Brand New |
| MOQ |
1 |
Functional Highlights
The ABB AO810 3BSE008522R1 module provides high precision with a 12-bit resolution, ensuring accurate signal transmission. Engineers rely on its ±1% accuracy to minimize errors in critical processes. Its wide voltage range and adjustable current output enhance compatibility with diverse control systems. The module operates efficiently across extreme temperatures, guaranteeing stable performance in both cold storage and high-heat production environments.
Applications and Compatibility
The ABB AO810 3BSE008522R1 Analog Output Module integrates seamlessly into S800 I/O and DCS architectures. Its compact size and lightweight build make it suitable for retrofit projects and new installations. This module supports industrial automation, energy management, and process control applications requiring precise analog signal output and long-term reliability.
