Description
Overview
The ABB AI890 3BSC690071R1 Analog Input Module provides precise signal acquisition and reliable control in S800 I/O systems. Its compact dimensions and lightweight build simplify installation, while the rugged design ensures durability in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
AI890 3BSC690071R1 |
| Manufacturer |
ABB |
| Module Type |
Analog Input Module |
| Product Range |
S800 I/O |
| Dimensions |
4.5 × 10.5 × 12 cm |
| Weight |
0.24 kg |
| Input Channels |
8 |
| Output Channels |
8 |
| Current Rating |
50 mA per channel |
| Power Supply |
12V DC |
| Communication Protocol |
Profinet, Ethernet router |
| Operating Temperature |
-25°C to +60°C |
| Protection Class |
IP20 |
| System |
DCS |
| HS Code |
8537101190 |
| Origin |
Sweden |
| Condition |
Brand New |
| MOQ |
1 |
Functional Highlights
The ABB AI890 3BSC690071R1 module features 8 input and 8 output channels, enabling versatile signal processing for monitoring and control tasks. Engineers rely on its Profinet communication protocol for efficient data transfer across industrial networks. Its IP20 protection rating safeguards against dust and minor splashes, while the compact size ensures easy integration into existing systems. The stable 12V DC power supply and precise 50mA current rating per channel guarantee consistent performance.
Applications and Compatibility
The ABB AI890 3BSC690071R1 Analog Input Module integrates seamlessly into S800 I/O and DCS architectures. Its wide operating temperature range supports deployment in diverse environments, from cold storage facilities to high-heat production lines. This module suits industries such as manufacturing, energy management, and process automation requiring reliable analog input and output functionality.
