Overview
The ABB AI86-16 57087196 Analog Input Card from the Stromberg series enhances industrial automation with precise signal acquisition. ABB designed this module with 16 analog inputs, robust construction, and advanced communication protocols for seamless integration into demanding control systems.
Technical Specifications
| Parameter |
Value |
| Model Number |
AI86-16 57087196 |
| Module Type |
Analog Input Card |
| Manufacturer |
ABB |
| Product Range |
Stromberg |
| Dimensions |
2 × 18.5 × 26 cm |
| Weight |
0.34 kg |
| HS Code |
8537101190 |
| Origin |
Sweden |
| Condition |
Brand New |
| System |
DCS |
| Inputs |
16 high-precision analog channels |
| Sampling Rate |
1 kHz |
| Communication Protocol |
Modbus RTU |
| Interface |
RS-485 |
| Power Supply |
24V DC |
| Operating Temperature |
-20°C to +60°C |
| Certifications |
CE, UL |
Functional Highlights
The ABB AI86-16 57087196 captures signals with 16 analog inputs, ensuring accurate data acquisition for critical processes. Its 1 kHz sampling rate supports real-time monitoring, while Modbus RTU and RS-485 interfaces enable smooth integration with automation systems.
Energy and Design
Compact dimensions of 2 × 18.5 × 26 cm and a lightweight 0.34 kg build simplify installation in space-constrained environments. The ABB AI86-16 57087196 operates reliably across -20°C to +60°C, ensuring consistent performance in harsh industrial conditions.
Applications and Compatibility
The ABB AI86-16 57087196 Analog Input Card supports Stromberg series systems and integrates with DCS architectures. Industries such as manufacturing, energy, and process automation rely on this module for precise monitoring, efficient communication, and compliance with CE and UL standards.
