ABB 3HAC14178-1 DSQC 609 Power Supply
Configured for DC power conversion and distribution within the OmniCore V400XT controller, the ABB 3HAC14178-1 (DSQC 609 Power Supply) provides the controller with its specified internal power source.
Hardware Specifications
Parameter
Specification
Model
3HAC14178-1
Spare Model
3HAC14178-1
ABB Type
DSQC 609
Product Type
Power Supply
Brand
ABB
Controller Family
OmniCore V400XT
Origin
Sweden
Weight
1.4 kg
Dimensions
36.3 x 18.8 x 3 cm estimated shipping size
Tariff Code
8537101190
Spare-Part Level
L2
Installation Safety
Disconnect mains power and wait 3 minutes
ESD Control
ESD protective wrist band required
ABB Controller Power Supply Characteristics
The DSQC 609 functions as a dedicated power-supply assembly within the OmniCore V400XT controller architecture. It supports the controller's internal electrical power distribution according to the installed system configuration.
The supplied documentation identifies 3HAC14178-1 as a DSQC 609 power supply and classifies the component at spare-part level L2. Therefore, technicians should verify the complete ordering number and controller configuration before replacement.
ABB controller assemblies also require compatibility with the associated backplane and system hardware. However, the supplied data does not specify input voltage, output voltage, rated current, efficiency, or power dissipation. These values should therefore be taken from the applicable ABB technical documentation rather than estimated.
Frequently Asked Questions
Q: Can the DSQC 609 be replaced while the OmniCore V400XT controller remains energized? A: No. The supplied installation instruction requires mains power disconnection before replacement, followed by a 3-minute waiting period.
Q: Does the supplied data specify the DSQC 609 output voltage or rated current? A: No. The provided specifications do not state output voltage, output current, power rating, or power consumption.
Q: Is ESD protection required during DSQC 609 replacement? A: Yes. The supplied installation data specifies the use of an ESD protective wrist band.
Field Installation Guidelines
Isolate and disconnect the controller from mains power before accessing the power-supply assembly.
Wait at least 3 minutes before beginning physical removal or installation.
Wear an ESD protective wrist band and use appropriate ESD handling procedures.
Confirm the installed component marking and complete order number before replacement.
Inspect connectors, mounting points, and mating interfaces for contamination or mechanical damage.
Route internal wiring according to the original controller arrangement and avoid unnecessary cable stress.
After installation, verify connector engagement and mechanical seating before restoring power.
Recommission the controller according to the applicable ABB Robotics service procedure for the installed OmniCore V400XT configuration.
