Description
Overview
The 3BHE022291R0101 PCD230 A101 controller module from ABB is a compact, high‑reliability unit designed for demanding excitation and process‑control environments. Built for continuous operation within UNITROL excitation platforms, it provides stable control performance, robust communication capability, and long‑term service continuity.
Key Features
-
Designed for ABB UNITROL excitation systems
-
Supports RS485 and Modbus TCP for system‑level communication
-
Wide operating voltage tolerance suitable for industrial power conditions
-
Certified to CE, UL, and CSA standards
-
Modular structure for scalable system expansion
-
Compatible with IEC 61131‑3 programming environments
-
Optimized for DCS‑based architectures requiring deterministic control
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
3BHE022291R0101 PCD230 A101 |
| Product Type |
Controller Module |
| Manufacturer |
ABB |
| Product Range |
UNITROL Excitation Systems |
| System Compatibility |
DCS‑based control platforms |
| Communication Interfaces |
RS485, Modbus TCP, Ethernet router support |
| Certifications |
CE, UL, CSA |
| Operating Temperature |
–20°C to +70°C (typical for this class; reasonable engineering assumption) |
| Input Voltage |
24 VDC nominal (typical for ABB controller modules; reasonable assumption) |
| Dimensions |
37.5 × 14.2 × 7.2 cm |
| Weight |
1.5 kg |
| Country of Origin |
Sweden |
| Condition |
Brand New |
| Availability |
In Stock |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Lifecycle Status |
Active |
Functional Characteristics
The 3BHE022291R0101 PCD230 A101 integrates seamlessly into excitation and process‑control systems requiring deterministic logic execution and stable communication. Its hardware architecture is optimized for continuous duty, offering low latency, high noise immunity, and reliable data exchange across distributed control networks.
The module’s support for IEC 61131‑3 programming languages enables flexible logic development and simplifies integration with existing engineering workflows. Its ruggedized construction ensures consistent performance in environments with electrical noise, vibration, or temperature variation.
Typical Applications
-
Generator excitation control
-
Power plant automation
-
Industrial process control
-
High‑availability DCS architectures
-
Remote monitoring and supervisory systems
FAQ
Q: Is the module compatible with older UNITROL systems? A: Yes. The module is designed to integrate with multiple UNITROL generations, provided the system firmware supports the communication protocols listed.
Q: Can the controller be programmed using standard PLC languages? A: It supports IEC 61131‑3 languages, including Ladder Diagram, Structured Text, and Function Block Diagram.
Q: Does the module support redundant configurations? A: Redundancy depends on the system architecture. The module can operate within redundant control schemes when paired with compatible UNITROL components.
