Product Description
The 3BHE020570R1022 PPD114 B1022 power supply module is part of ABB’s AC 800PEC platform and is engineered to deliver stable, high‑efficiency power for demanding control and process applications. Its design ensures consistent voltage regulation and reliable operation in environments where electrical noise, thermal variation, and continuous load cycles are common. The module’s robust construction supports long‑term service life, making it suitable for mission‑critical industrial systems.
The 3BHE020570R1022 PPD114 B1022 provides regulated power to AC 800PEC controllers and associated I/O modules, ensuring uninterrupted operation of automation and control functions. Its electrical design incorporates protective features that guard against overload, transient disturbances, and supply fluctuations. Integrated communication interfaces, including Ethernet and Modbus TCP/IP, support system‑level monitoring and diagnostics.
Certified to international standards, the module meets global requirements for safety, EMC compliance, and manufacturing quality. Its mechanical layout and standardized connectors allow straightforward installation in both new and retrofit applications.
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
3BHE020570R1022 PPD114 B1022 |
| Product Type |
AC 800PEC Power Supply Module |
| Brand |
ABB |
| Product Range |
AC 800PEC |
| System Compatibility |
AC 800PEC controllers and I/O modules |
| Operating Voltage |
24 VDC input (typical) |
| Output Function |
Regulated power supply for control electronics |
| Communication Interfaces |
Ethernet, Modbus TCP/IP |
| Protection Features |
Overvoltage protection, transient suppression |
| Certifications |
CE, UL, CSA, ISO 9001 |
| Dimensions |
43.3 × 17 × 6.8 cm |
| Weight |
2.34 kg |
| Condition |
New |
| Origin |
Sweden |
| HS Code |
8537101190 |
| Availability |
In stock |
| Minimum Order Quantity |
1 |
| Lifecycle Status |
Active |
Functional Overview
The 3BHE020570R1022 PPD114 B1022 module provides stable and efficient power delivery for AC 800PEC‑based automation systems. Its internal circuitry ensures low‑ripple output and consistent voltage regulation, supporting reliable operation of control processors and I/O hardware. Integrated communication interfaces allow the module to report status information and support remote diagnostics.
Its rugged enclosure and protective features enable operation in environments where dust, vibration, and temperature fluctuations are present. The module’s design supports continuous duty cycles, making it suitable for high‑availability industrial applications.
Application Scenarios
• Power supply for AC 800PEC controllers and I/O systems • High‑demand process automation environments • Power generation and heavy‑industry control platforms • Retrofit upgrades for legacy power supply modules • Installations requiring stable, noise‑resistant power regulation
Similar Model Comparison
| Model |
Function |
Notes |
| PPD114 B1022 |
Power supply module |
Standard AC 800PEC power supply |
| PPD113 B1010 |
Power supply module |
Earlier version with reduced communication options |
| PPD115 B1030 |
Enhanced power supply |
Higher efficiency and extended diagnostics |
FAQ
Q: Is the PPD114 B1022 compatible with all AC 800PEC controllers? A: Yes. It is designed for full compatibility with AC 800PEC control hardware.
Q: Does the module support network‑based diagnostics? A: Ethernet and Modbus TCP/IP interfaces allow system‑level monitoring and communication.
Q: Can it operate in harsh industrial environments? A: Its construction and protective features support stable operation under demanding conditions.
