Description
Overview
The 3BHE014135R0011 / UAD149 A00‑0‑11 Combi IO module is part of ABB’s AC 800PEC control platform, designed to provide high‑speed input/output processing for advanced automation and power‑electronics applications. Its architecture supports precise signal acquisition, rapid control response, and reliable communication within demanding industrial environments.
Technical Specifications
General Information
-
Model: 3BHE014135R0011 / UAD149 A00‑0‑11
-
Manufacturer: ABB
-
Product Type: AC 800PEC Combi IO Module
-
Product Range: AC 800PEC Control System
-
System Compatibility: DCS / High‑Performance Control
-
Operating Status: Active
Mechanical Data
-
Dimensions: 27.5 × 14.8 × 10 cm
-
Weight: 1.68 kg
-
IP20‑rated enclosure for cabinet installation
-
Robust mechanical design for vibration‑resistant operation
Electrical & Functional Characteristics
-
Operating frequency: up to 1 MHz for high‑speed control
-
Power supply: 24 V DC and AC input compatibility
-
Designed for precise analog and digital signal handling
-
Stable operation in environments with electrical noise
-
Wide operating temperature range: −25°C to +60°C
-
Storage temperature: −40°C to +70°C
Communication Interfaces
-
Ethernet interface for system‑level communication
-
Modbus TCP/IP support for integration with external devices
-
Suitable for real‑time data exchange in high‑speed control loops
Integration & Connectivity
-
Fully compatible with AC 800PEC controllers
-
Modular architecture supports flexible system expansion
-
Suitable for both new installations and retrofit modernization
Environmental Ratings
-
IP20 protection against dust and incidental contact
-
Designed for power‑electronics environments such as converters and drives
-
High thermal stability for continuous operation
Diagnostics & Maintenance
-
Built‑in diagnostic functions for monitoring module health
-
Clear interface layout for simplified wiring and configuration
-
Modular design reduces downtime during replacement
Application Scenarios
-
High‑speed control in power‑electronics systems
-
AC 800PEC‑based converter and drive applications
-
Real‑time signal processing in advanced automation
-
Industrial environments requiring precise, fast I/O performance
FAQ
Q: Is the 3BHE014135R0011 / UAD149 A00‑0‑11 compatible with all AC 800PEC controllers? A: It is designed specifically for AC 800PEC systems; compatibility with earlier revisions should be verified.
Q: What communication protocols does this module support? A: It supports Ethernet and Modbus TCP/IP for flexible integration.
Q: Can this module operate in harsh environments? A: Yes, its −25°C to +60°C operating range and IP20 enclosure support demanding industrial conditions.
