Description
Overview
The ABB 1MRK000508-BDR04 Advanced PC Board ensures precise signal processing for Bay Control Systems. ABB designed this module to handle up to 32 digital signals, delivering high accuracy and efficiency in demanding industrial environments. Its compact dimensions and lightweight build simplify installation while maintaining robust performance.
Technical Specifications
| Parameter |
Value |
| Model Number |
1MRK000508-BDR04 |
| Manufacturer |
ABB |
| Module Type |
Advanced PC Board |
| System |
DCS / Bay Control System |
| Dimensions |
23.2 × 18.8 × 2 cm |
| Weight |
0.46 kg |
| HS Code |
8537101190 |
| Origin |
Sweden |
| Condition |
Brand New |
| Lead Time |
In Stock |
| MOQ |
1 |
| Communication Service |
Ethernet Router |
| Voltage Range |
12–24 V DC |
| Input Capacity |
32 digital signals |
| Power Consumption |
1.5 W (max) |
| Operating Temperature |
-25°C to +60°C |
| Housing Material |
Aluminum |
| Status |
Active |
Functional Highlights
The ABB 1MRK000508-BDR04 module processes 32 digital signals with a rapid response time under 1ms. Engineers benefit from its wide voltage range of 12–24V DC, ensuring compatibility across diverse automation systems. Its aluminum housing enhances durability, while efficient 1.5W power consumption supports sustainable operations. Terminal block connections simplify wiring and maintenance, reducing downtime and improving reliability.
Applications and Compatibility
The ABB 1MRK000508-BDR04 Advanced PC Board integrates seamlessly with Bay Control Systems and broader DCS architectures. Operators deploy this module in manufacturing plants, energy production facilities, and industrial automation networks. Its robust design and environmental tolerance make it ideal for real-time monitoring, actuator control, and precision automation tasks.
