Description

Overview

The 1KHW001432R0001 / P3LG Human Machine Interface module is designed for ABB Bay Control System platforms, providing a reliable operator interface for monitoring, configuration, and control tasks. Its durable construction, broad communication support, and stable performance make it suitable for substation automation and other mission‑critical industrial environments.

Technical Specifications

General Information

• Model: 1KHW001432R0001 / P3LG

• Manufacturer: ABB

• Product Type: Human Machine Interface (HMI)

• Product Range: Bay Control System

• System Compatibility: DCS

• Operating Status: Active

Mechanical Data

• Dimensions: 4.5 × 24.7 × 12.7 cm

• Weight: 0.74 kg

• Aluminum alloy housing with corrosion‑resistant finish

• Compact form factor suitable for panel‑mounted installations

Electrical & Functional Characteristics

• Operating temperature: −20°C to +60°C

• Storage temperature: −40°C to +70°C

• Designed for stable operation in harsh industrial environments

• High‑quality PCB construction for long‑term reliability

Communication Interfaces

• 4 × RS‑232 ports

• 2 × Ethernet ports

• Supports integration with supervisory systems and field devices

• Enables efficient data exchange for control and monitoring tasks

Integration & Connectivity

• Compatible with ABB Bay Control System architectures

• Supports multi‑protocol communication for flexible deployment

• Suitable for both new installations and retrofit projects

Certifications

• CE

• UL

• FCC

• Manufactured to meet industrial safety and electromagnetic compliance standards

Diagnostics & Maintenance

• Designed for straightforward installation and service

• Supported by ABB documentation and engineering tools

• Modular design simplifies replacement and reduces downtime

Application Scenarios

• Substation bay control and monitoring

• Operator interface for protection and automation systems

• Industrial DCS environments requiring robust HMI hardware

• Retrofit upgrades for legacy ABB bay control equipment

FAQ

Q: Is the 1KHW001432R0001 / P3LG compatible with older ABB bay control units?   A: It integrates with multiple ABB bay control generations, though verifying firmware compatibility is recommended.

Q: What communication interfaces does this HMI support?  A: It includes four RS‑232 ports and two Ethernet ports for flexible connectivity.

Q: Can this module operate in high‑temperature environments?  A: Yes, it supports operation up to +60°C and storage up to +70°C.

Specifications

• Dimensions: 4.5 × 24.7 × 12.7 cm
• Brand: ABB

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
