Product Description
Overview
The AAI143-S00/K4A00 from Yokogawa is a high-precision analog input module designed for process control systems. It provides reliable current signal acquisition with fully isolated multi-channel inputs, ensuring measurement accuracy and system safety. Ideal for various industrial monitoring applications.
Technical Specifications
| Parameter |
Description |
| Model |
AAI143-S00/K4A00 |
| Manufacturer |
Yokogawa |
| Product Type |
Analog Input Module |
| Number of Input Channels |
16 isolated channels |
| Input Signal Range |
4 to 20 mA |
| Allowable Input Current |
Maximum 24 mA |
| Isolation |
Channel-to-channel isolation |
| Interface |
KS Cable Interface Adapter (for AEA4D Terminal Board, Model ATK4A-00) |
| Module Type |
Standard type, Basic type |
| Weight |
0.3 Kg |
| Mounting |
DIN rail installation |
Applications
-
Process control and monitoring systems
-
Industrial equipment analog signal acquisition
-
Multi-channel data logging and analysis
-
System integration and remote monitoring solutions
FAQ
Q: What signal types does this module support?
A: The module supports 4-20 mA current signals, suitable for standard analog sensors.
Q: Are the channels isolated?
A: Yes, all 16 input channels are fully isolated to ensure safe and reliable signal acquisition.
Q: Can it connect directly to the AEA4D terminal board?
A: Yes, this model includes a KS Cable Interface Adapter, compatible with the ATK4A-00 terminal board.
Function Comparison
Compared to other AAI143 series modules, this module is a basic standard type, providing full isolation and 16-channel input but without advanced filtering or diagnostics, making it suitable for cost-effective industrial applications.
