Overview
The AAI141-S00/K4A00 from Yokogawa is a high-performance analog input module designed for industrial control systems. It supports 16 channels with 4-20 mA DC input signals and features a non-isolated architecture suitable for compact and cost-effective installations. This model includes the KS Cable Interface Adapter (ATK4A-00) for seamless connectivity.
Technical Specifications
-
Model: AAI141-S00/K4A00
-
Manufacturer: Yokogawa
-
Product Type: Analog Input Module
-
Input Channels: 16, non-isolated
-
Input Signal: 4 to 20 mA DC
-
Maximum Allowable Input Current: 27 mA
-
Interface Adapter: KS Cable Adapter (Model ATK4A-00)
-
Response Time: Typically < 100 ms per channel
-
Accuracy: ±0.1% of full scale
-
Operating Temperature: 0 to 55 degrees Celsius
-
Storage Temperature: -20 to 70 degrees Celsius
-
Dimensions: Standard module size (approx. 100 x 50 x 25 mm)
-
Weight: 0.2 kg
Applications
The AAI141-S00/K4A00 is ideal for process monitoring, data acquisition, and industrial automation systems requiring reliable 4-20 mA signal inputs. Common applications include chemical plants, water treatment facilities, and manufacturing process control systems.
Similar Models Comparison
FAQ
Q: Can this module handle voltage inputs?
A: No, this model is designed specifically for 4-20 mA current inputs only.
Q: Is the module hot-swappable?
A: No, the module requires power-down for safe installation or removal.
Q: Can multiple modules be connected together?
A: Yes, multiple AAI141-S00/K4A00 modules can be used in a system, but they share a common ground due to non-isolated design.
