Product Description
The AAI135-S00 is an 8-channel isolated analog input module from Yokogawa, designed for integration with the CENTUM VP Distributed Control System (DCS). It converts analog signals from various field instruments into digital signals for precise processing within the DCS.
This module is ideal for applications requiring reliable and high-accuracy measurement of electrical signals from industrial sensors. It supports a wide range of process measurement tasks, including temperature, pressure, flow, liquid level, and pH.
Technical Specifications
-
Input Signal: 4 to 20 mA
-
Accuracy: ±0.1 percent Full Scale
-
Resolution: 12 bits
-
Sampling Rate: 100 Hz
-
Isolation: Channel-to-channel isolation supported
-
Operating Temperature Range: 0 to 55 degrees Celsius
-
Storage Temperature Range: -20 to 70 degrees Celsius
-
Power Consumption: 5 W typical
-
Dimensions: 170 x 120 x 50 mm
-
Weight: 1 kg
-
Mounting: DIN rail or panel mount compatible
-
Compliance: CE certified
Applications
-
Temperature monitoring of industrial fluids
-
Measurement of gas or liquid pressure
-
Flow rate monitoring for gas or liquids
-
Level detection in tanks or vessels
-
pH measurement in process solutions
FAQ
Q: Can this module measure multiple signal types simultaneously?
A: The module is designed specifically for 4-20 mA current signals. It can read multiple sensors of this type but not voltage or thermocouple signals without an appropriate converter.
Q: Is the module hot-swappable?
A: No, module replacement requires system power-down to ensure signal integrity and safety.
Q: How does this compare to AAI136 series modules?
A: While both modules provide isolated analog inputs, the AAI136 offers higher channel density and faster sampling rates. The AAI135-S00 focuses on standard 8-channel reliability and high accuracy.
