Description
The ABB 3BSE020510R1, identified as the DO801, is a digital output module designed for the S800L I/O series. This module provides 16 digital output channels, engineered to support reliable switching operations in industrial control applications. It is rated for 24 VDC operation and supports a current capacity of 0.5 A per channel.
Features
- 16-channel digital output configuration
- 24 VDC nominal voltage rating
- 0.5 A current output per channel
- Compact design optimized for the S800L I/O system
- Designed for high-density industrial control environments
Applications
The DO801 module is typically deployed within ABB Advant or S800L I/O systems to manage discrete output signals for actuators, relays, and indicator lamps. It is suitable for process control, manufacturing automation, and distributed control system (DCS) architectures requiring robust digital signal handling.
Technical Specifications
| Model |
DO801 |
| Order Code |
3BSE020510R1 |
| Channels |
16 |
| Output Type |
Digital |
| Rated Voltage |
24 VDC |
| Output Current |
0.5 A per channel |
| System Family |
S800L I/O |
Installation Guidelines
- Ensure the system power is completely disconnected before attempting to install or remove the module from the I/O base.
- Handle the module using proper ESD (Electrostatic Discharge) mitigation techniques to prevent damage to internal electronic components.
- Verify that the module is correctly seated in the assigned slot of the S800L mounting base to ensure proper backplane communication.
- Ensure all field wiring is routed securely and conforms to local electrical standards for 24 VDC signal circuits.
- Maintain adequate ventilation within the control cabinet to prevent thermal accumulation around the I/O modules.
FAQ
Is the DO801 compatible with other S800 series modules?
The DO801 is specifically part of the S800L I/O family. Please consult your system documentation to ensure compatibility with your specific controller and baseplate configuration.
What is the maximum current per channel?
The DO801 module is rated for a maximum of 0.5 A per output channel.
