Bently Nevada 128275-01F 130944-01 Future Expansion Faceplate The Bently Nevada 128275-01F 130944-01, also cataloged as the 128275-01F 130944-01 Future Expansion...
Read more
The Bently Nevada 128275-01F 130944-01, also cataloged as the 128275-01F 130944-01 Future Expansion Faceplate, operates as a dedicated hardware component for unused slot protection within Bently Nevada 3500 Series rack platforms.
Hardware Specifications
Parameter
Specification
Model
128275-01F 130944-01
Brand
Bently Nevada
Product Type
Future Expansion Faceplate
System Series
3500 Series Rack
Origin
USA
Weight
0.05 kg
Dimensions
2.6 x 2.8 x 24 cm
Operating Temp
-40 deg C to +85 deg C
Storage Temp
-40 deg C to +85 deg C
Power Consumption
0 W
Power Supply
N/A
Tariff Code
8537101190
Mounting Function
Full-height rack position blank cover
Rack Compatibility
Bently Nevada 3500 Full-Size Rack and Mini-Rack systems
Mechanical Rack Protection and TSI System Integration
The 128275-01F 130944-01 faceplate provides a physical cover for unused module positions in the Bently Nevada 3500 rack assembly. It does not process vibration signals, perform alarm calculations, or provide communication functions.
The unit maintains the mechanical structure of the rack by closing reserved module openings. Therefore, it reduces exposure to dust, oil contamination, foreign objects, and accidental contact with internal rack interfaces.
Bently Nevada 3500 racks support monitor modules and rack power supplies through an internal rack architecture. The faceplate allows reserved positions to remain available for future installation of monitoring modules, communication modules, relay modules, or other compatible hardware.
For mechanical monitoring systems, correct rack configuration supports stable module alignment and maintains the designed installation arrangement for future TSI hardware expansion. The faceplate does not affect eddy-current probe scaling, gap voltage validation (-10 VDC targets), or rotor dynamics measurement functions because it contains no electronic circuits.
Frequently Asked Questions
Q: Does the 128275-01F 130944-01 perform any monitoring or communication function? A: No. The unit is a passive mechanical faceplate and provides no signal acquisition, processing, communication, or relay operation.
Q: Can the faceplate position be replaced with an active 3500 Series module later? A: Yes. The blank panel can be removed when a compatible 3500 Series module is installed in the reserved rack position.
Q: Does the faceplate require rack power or configuration settings? A: No. The device consumes 0 W and requires no electrical connection, firmware configuration, or software setup.
Field Installation Guidelines
Install the faceplate into an unused Bently Nevada 3500 rack module position according to the rack mechanical arrangement.
Verify that the panel aligns correctly with the rack frame before securing the hardware.
Keep unused rack openings covered to reduce contamination exposure inside the monitoring enclosure.
Maintain separation between future module wiring and installed signal cables to prevent interference during later expansion work.
Follow standard cabinet grounding and enclosure practices when installing or modifying 3500 Series rack assemblies.
Remove the faceplate only when installing an approved Bently Nevada 3500 Series functional module.
