Description
Yokogawa S9981DE-01 10-Slot Backplane Module
The Yokogawa S9981DE-01, also cataloged as the S9981DE-01 10-Slot Backplane Module, operates as a dedicated hardware component for interconnecting I/O and peripheral modules within Yokogawa DCS platforms.
Hardware Specifications
Parameter
Specification
ModelBrand
Yokogawa S9981DE-01
ProductType
10-Slot Backplane / Rack Base Module
SlotCount
10 Slots
Dimensions
17.5 in x 5.3 in x 1.0 in (44.5 cm x 13.3 cm x 2.5 cm)
Weight
~2 lbs 0.3 oz (0.9–1.0 kg)
Origin
Japan / Germany
OperatingTemp
Standard industrial cabinet conditions, natural convection cooling
PowerConsumption
Dependent on installed modules; backplane provides standardized voltage rails
Application
DCS/PLC Node Interface systems, process automation
DCS Connectivity Features
The S9981DE-01 implements channel-to-channel isolation to maintain signal integrity across analog and digital module buses. It supports FOUNDATION Fieldbus and Profibus PA connectivity through standardized module slots and ensures minimal cross-talk between adjacent module channels. The design accommodates cold junction compensation (CJc) in thermocouple measurement loops when interfacing with temperature I/O modules.
Frequently Asked Questions
Q: Can the backplane support hot-swap of modules? A: Only certain I/O modules designed for the S9981DE-01 can be inserted or removed under powered conditions. Verify individual module specifications before hot-swap operations.
Q: What is the maximum current capacity per slot? A: Each slot follows Yokogawa bus voltage and current specifications. The total current must not exceed the designed backplane load limits; consult system documentation for maximum per-slot consumption.
Q: Are firmware updates required on the backplane itself? A: The backplane does not contain firmware; updates apply only to installed intelligent modules or controllers.
Field Installation Guidelines
Mount the backplane in a standard cabinet or rack using recommended fasteners to prevent mechanical stress.
Ensure proper grounding of the backplane chassis to reduce EMI and maintain channel isolation.
Avoid routing high-current AC lines adjacent to signal modules; maintain separation according to industrial control wiring standards.
Allow for adequate airflow around the backplane to prevent overheating.
Verify all module connectors are fully seated and aligned to prevent bus communication faults.
