Schneider Electric provides comprehensive industrial automation solutions. Its portfolio includes Modicon Quantum PLCs, Magelis HMI panels, ATV VFD drives, PacDrive motion control systems, communication modules, and accessories. Schneider products ensure reliable operation, precise control, and efficient industrial automation worldwide.
Schneider Electric
-
Schneider Electric 170AAI14000 Modicon Momentum Schneider Electric Analog Input Base
Schneider Electric 170AAI14000 Modicon Momentum Analog Input Base The Schneider Electric 170AAI14000, also cataloged as the 170AAI14000 Analog Input Base, operates as a dedicated hardware component for analog signal acquisition within the Modicon Momentum automation platform. It accepts voltage and current process signals, converts them into 16-bit signed data, and transfers measurement values to the controller through the Momentum I/O architecture. Hardware Specifications Parameter Specification Model 170AAI14000 Brand Schneider Electric Series Modicon Momentum Product Type Analog Input Base Analog Input Channels 16, single-ended Input Ranges 4-20 mA, +/- 5 V, +/- 10 V Resolution 12-bit conversion, 16-bit signed data format Input Impedance > 2200 kOhm (voltage inputs), < 0.25 Ohm (4-20 mA) Input Filter Low-pass, 10 kHz Full Scale 16 mA (4-20 mA), 5 V (+/- 5 V), 10 V (+/- 10 V) Update Time 25 ms Absolute Accuracy +/- 0.15 % FS at 25 degC (voltage), +/- 0.25 % FS at 25 degC (current) Temperature Drift 30 ppm FS/degC (voltage), 60 ppm FS/degC (current) Channel-to-Ground Isolation 1780 VAC for 1 minute Supply-to-Ground Isolation 500 V for 1 minute Permissible Common Mode Voltage 250 VAC, 47-63 Hz; 100 VDC External Power Requirement +/- 30 VDC Power Consumption 305 mA at 24 VDC Maximum Power Dissipation 5.55 W Reverse Polarity Protection Internal Internal Protection 2 A slow-blow Associated Fuse 500 mA fast-blow Local Indicators 16 channel status LEDs Electrical Connection Two removable terminal block connectors Dimensions 141.5 x 125 x 47.5 mm Weight 0.215 kg Operating Temp 0 to 60 degC Storage Temp -40 to 85 degC Relative Humidity 95 % non-condensing Operating Altitude Up to 5000 m Certifications CE, UL, CSA, FM Class 1 Division 2 Protective Treatment TC Origin Schneider Electric manufacturing location not specified in the supplied data PLC Backplane Communication and I/O Density The 170AAI14000 is designed for the Modicon Momentum distributed I/O platform, where analog measurement data is transferred through the Momentum backplane interface to the controller. Sixteen single-ended analog input channels provide high I/O density for distributed acquisition while maintaining independent channel status indication through front-panel LEDs. The module delivers a fixed 25 ms update period for cyclic analog data acquisition. Frequently Asked Questions Q: Does the module support both voltage and current analog inputs? A: Yes. The module supports +/- 5 V, +/- 10 V, and 4-20 mA analog input ranges. Input type selection is determined during system configuration. Q: Is channel isolation provided? A: The module provides 1780 VAC isolation between input channels and ground for 1 minute, and 500 V isolation between the supply and ground. The supplied specification does not indicate channel-to-channel isolation. Q: Can field wiring be connected through removable terminals? A: Yes. The module uses two removable terminal block connectors to simplify field wiring and module replacement. Field Installation Guidelines Verify that the configured input range matches the connected field instrument before applying power. Route analog signal cables separately from motor power and high-current conductors to minimize electrical interference. Connect cable shields according to the plant grounding standard and avoid multiple shield grounding points unless specified by the control system design. Confirm that the external supply meets the specified +/- 30 VDC requirement before energizing the module. Install the specified external 500 mA fast-blow fuse and observe the internal protection limits during maintenance. Maintain ambient operating conditions within the specified temperature and humidity limits.
$200.00 $100.00
-
Schneider Electric BMXDRA0805 Modicon X80 Discrete Output Module Schneider Electric
Schneider Electric BMXDRA0805 Modicon X80 Discrete Output Module The Schneider Electric BMXDRA0805, also cataloged as the BMXDRA0805 Discrete Output Module, operates as a dedicated hardware component for relay-based discrete output switching within the Modicon X80 automation platform. The module provides eight relay outputs supporting both AC and DC loads with electrical isolation through mechanical relay contacts. Suffix Breakdown & Model Matrix The supplied documentation identifies BMXDRA0805 as a fixed catalog number. No official suffix breakdown or ordering matrix is specified. Hardware Specifications Parameter Specification Model BMXDRA0805 Brand Schneider Electric Series Modicon X80 Product Type Discrete Output Module Output Channels 8 relay outputs Output Standard EN/IEC 61131-2 Output Voltage 12 to 24 VDC (10 to 34 VDC), 24 to 240 VAC (10 to 264 VAC) Output Type Relay Conventional Thermal Current 3 A Minimum Switching Current 1 mA at 5 VDC Response Time <= 10 ms ON, <= 8 ms OFF Typical Current Consumption 100 mA at 3.3 VDC Power Consumption Power dissipation <= 2.7 W Insulation Resistance > 10 MOhm at 500 VDC MTBF 1,573,341 h Electrical Durability 1,000,000 cycles (AC-12, DC-12, DC-13), 2,000,000 cycles (AC-15) under specified loads Protection External overload protection, external short-circuit protection, inductive AC/DC overvoltage protection Recommended Output Protection Fast-blow fuse per channel or channel group; discharge diode for DC loads; RC circuit or ZnO surge limiter for AC loads Dielectric Strength 2000 VAC, 50/60 Hz, 1 min IP Rating IP20 Operating Temp 0 to 60 degC Storage Temp -40 to 85 degC Relative Humidity 5 % to 95 % non-condensing at 55 degC Operating Altitude 0 to 2000 m, derating required up to 5000 m Vibration Resistance 3 gn Shock Resistance 30 gn Dimensions Not specified in the supplied documentation Weight Not specified in the supplied documentation Certifications CE, CSA, UL, RCM, Merchant Navy, EAC Backplane Communication Integration The BMXDRA0805 interfaces with the Modicon X80 backplane through the platform bus, where output command data and module diagnostics are exchanged between the controller and the I/O module. Relay switching is executed locally by the module while logic execution remains in the PLC CPU. Firmware compatibility should be verified against the controller and rack configuration before system commissioning. Frequently Asked Questions Q: Does the module include internal short-circuit protection? A: No. The documentation specifies external short-circuit protection using one fast-blow fuse per channel or per channel group. Q: What suppression devices should be installed for inductive loads? A: Schneider Electric specifies a discharge diode for DC loads and either an RC suppression circuit or a ZnO surge limiter for AC loads to reduce switching transients. Q: Can the module switch both AC and DC loads? A: Yes. The relay outputs support DC loads from 12 to 24 VDC (10 to 34 VDC allowable) and AC loads from 24 to 240 VAC (10 to 264 VAC allowable). Field Installation Guidelines Verify rack compatibility with the Modicon X80 platform before module installation. Isolate all field wiring before connecting output circuits. Install the specified external fast-blow fuse for each protected output channel or channel group. Route output wiring separately from low-level signal cables to reduce electrical interference. Apply the recommended suppression device directly across inductive field loads. Maintain protective earth continuity for the control cabinet and follow applicable local electrical installation standards.
$200.00 $100.00
-
Schneider Electric TSXDSZ32T2 TSX Micro Discrete Output Module Schneider Electric
Schneider Electric TSXDSZ32T2 TSX Micro Discrete Output Module Configured for 24 VDC positive discrete output switching in Modicon TSX Micro automation platforms, the Schneider Electric TSXDSZ32T2 (TSXDSZ32 Discrete Output Module) provides direct electrical execution through 32 transistor output channels. The module is designed for DC load control using positive logic with integrated output protection and backplane communication. Suffix Breakdown & Model Matrix The available technical information identifies TSXDSZ32T2 as a fixed catalog number. No official suffix decoding or ordering matrix is specified in the provided documentation. Hardware Specifications Parameter Specification Model TSXDSZ32T2 Brand Schneider Electric Product Series Modicon TSX Micro Product Type Discrete Output Module Origin Not specified Discrete Outputs 32 Output Connection Screw terminal block Output Type Positive logic transistor outputs Rated Output Voltage 24 VDC Output Voltage Limits 19 to 30 VDC Output Current 0.5 A per channel Maximum Current Limit 0.625 A Leakage Current (OFF State) <= 0.5 mA Residual Voltage <= 0.3 V Minimum Load Impedance 48 Ohm Response Time < 0.5 ms ON, < 0.5 ms OFF Switching Frequency < 0.6 / LI^2 Hz Overvoltage Protection Zener diode Short-Circuit Protection Current limiter and thermal circuit breaker Reverse Polarity Protection Reverse diode on power supply Output Paralleling Up to 2 outputs Current Consumption 94 mA Power Consumption 3.2 W per module Power Dissipation 0.15 W per channel Isolation Voltage 1500 VAC for 1 s Weight 0.42 kg Dimensions Not specified Operating Temp Not specified Backplane Communication and I/O Density Within the Modicon TSX Micro PLC architecture, the TSXDSZ32T2 exchanges output data through the system backplane while providing 32 DC output channels in a single module. The output density allows multiple field devices to be controlled from one hardware position without altering the module's electrical characteristics. Compatibility with the platform depends on the PLC rack configuration and supported TSX Micro hardware. Frequently Asked Questions Q: Does the module support hot swapping during PLC operation? A: The supplied technical documentation does not specify hot-swap capability. Module replacement should follow the controller maintenance procedure with power removed unless the PLC platform documentation explicitly permits energized replacement. Q: What protection mechanisms are integrated into each output stage? A: The module includes Zener diode overvoltage protection, current limiting, thermal circuit breaker protection, and reverse polarity protection through a reverse diode on the power supply. Q: Can output channels be connected in parallel? A: Yes. The documentation specifies that a maximum of two output channels may be connected in parallel. Field Installation Guidelines Verify that the external DC supply remains within the specified 19 to 30 VDC operating range before energizing field wiring. Tighten screw terminal connections according to the applicable Schneider Electric installation procedure. Route output wiring separately from high-power AC conductors to minimize electrical interference. Connect field cable shields according to the system grounding practice to reduce conducted electrical noise. Confirm output load current does not exceed the specified channel rating before commissioning. Perform insulation and continuity checks before applying field power after installation or maintenance.
$200.00 $100.00
-
Schneider Electric Schneider Electric TSXDEY32D2 Modicon Premium Discrete Input Module
Schneider Electric TSXDEY32D2 Modicon Premium Discrete Input Module The Schneider Electric TSXDEY32D2, also cataloged as the TSXDEY32D2 Discrete Input Module, operates as a dedicated hardware component for 24 VDC digital signal acquisition within the Modicon Premium Automation Platform. It provides 32 isolated current-sink input channels for direct field signal interfacing through the PLC backplane. Hardware Specifications Parameter Specification Model TSXDEY32D2 Brand Schneider Electric Product Series Modicon Premium Automation Platform Product Type Discrete Input Module Input Channels 32 isolated current-sink digital inputs Input Voltage 24 VDC positive Sensor Supply Voltage 19 to 30 VDC Input Current 3.5 mA per channel Logic State 1 Voltage >= 11 V Logic State 1 Current >= 3 mA Logic State 0 Voltage <= 5 V Logic State 0 Current <= 1.5 mA Input Impedance 6300 Ohm at logic state 1 Response Time 4 ms, <= 7 ms Insulation Resistance < 10 MOhm at 500 VDC Power Dissipation 1 W + 0.1 W x active channels Electrical Connection HE-10 connector Backplane Current Consumption 135 mA at 5 VDC; 160 mA at 24 VDC Module Format Standard Protection Rating IP20 Pollution Degree 2 Operating Temp 0 to 60 degC Storage Temp -25 to 70 degC Operating Humidity 10% to 95%, non-condensing Storage Humidity 5% to 95%, non-condensing Operating Altitude 0 to 2000 m Protective Treatment TC Certifications CE, ABS, GL, BV, RINA, RMRS, DNV, LR Weight 0.3 kg Origin France PLC Backplane Communication Characteristics The TSXDEY32D2 exchanges discrete input data with the Modicon Premium backplane through the platform's internal bus architecture. Input status is cyclically transferred to the processor without requiring external communication configuration. Backplane current loading should be included during rack power budget calculations, particularly when multiple high-density I/O modules are installed in the same chassis. Frequently Asked Questions Q: Does the TSXDEY32D2 support hot replacement while the PLC remains energized? A: The supplied technical data does not specify hot-swap capability. Module replacement should follow the maintenance procedure defined for the installed Modicon Premium system. Q: What type of field devices can be connected to the inputs? A: The module is designed for 24 VDC positive current-sink digital signals conforming to EN/IEC 61131-2 Type 1 input characteristics. Q: How is module power consumption determined? A: Internal power dissipation is specified as 1 W + 0.1 W multiplied by the number of active input channels. Backplane current consumption is 135 mA at 5 VDC and 160 mA at 24 VDC. Field Installation Guidelines Verify the PLC rack power budget before installing multiple high-density input modules. Connect field wiring using the specified HE-10 connector with correct pin assignment. Route digital input cables separately from high-power AC conductors to minimize electrical interference. Terminate cable shielding according to the plant grounding practice and avoid multiple shield grounding points unless required by the control system design. Confirm field voltage remains within the specified 19 to 30 VDC sensor supply range before commissioning. Maintain the enclosure environment within the specified IP20 operating conditions and ambient temperature limits.
$200.00 $100.00
-
Schneider Electric TSXP571634M Unity Processor | Schneider Electric
Schneider Electric TSXP571634M Unity Processor The Schneider Electric TSXP571634M, also cataloged as the TSXP571634M Unity processor, operates as a dedicated hardware component for PLC program execution, I/O processing, and industrial Ethernet communication within the Modicon Premium Automation platform. Hardware Specifications Parameter Specification Model TSXP571634M Brand Schneider Electric Product Type Unity Processor Series Modicon Premium Automation Platform Origin Not specified Software Unity Pro Rack Capacity 2 x 12-slot racks or 4 x 4/6/8-slot racks Maximum Slots 24 (2 x 12-slot), 16 or 32 (4 x 4/6/8-slot configuration) Discrete I/O Capacity 512 I/O Analog I/O Capacity 24 I/O Application-Specific Channels 8 Communication Ports 2 x RS485 serial (Mini DIN, 19.2 kbit/s), 1 x Ethernet TCP/IP RJ45 Ethernet Port 10BASE-T/100BASE-TX Communication Module Capacity Up to 2 modules Internal Memory (with PCMCIA) 224 kB program, 96 kB data Internal Memory (without PCMCIA) 96 kB shared program and data Additional Storage 256 kB PCMCIA card Task Structure 1 master task, 1 fast task, 32 event tasks Power Consumption 1650 mA at 5 VDC Module Format Double-width Weight 0.74 kg Operating Temp 0 to 60 degC Storage Temp -25 to 70 degC Relative Humidity 10 % to 95 % non-condensing (operation) Operating Altitude 0 to 2000 m Protection Rating IP20 Pollution Degree 2 Protective Treatment TC Certifications GL, RMRS, LR, ABS, DNV, RINA, BV Compliance Standards IEC 61131-2, UL 508, CSA C22.2, 89/336/EEC, 73/23/EEC, 92/31/EEC, 93/68/EEC Backplane Bus Communication and Firmware Compatibility The TSXP571634M exchanges application data and I/O information through the Modicon Premium backplane while supporting Unity Pro engineering software. The processor provides integrated Ethernet TCP/IP communication together with dual RS485 serial interfaces for controller-level data exchange. Program and data memory expansion is available through a PCMCIA memory card, allowing firmware-supported application storage without modifying the processor hardware. Frequently Asked Questions Q: Does the processor support memory expansion? A: Yes. A PCMCIA memory card provides an additional 256 kB data storage area while increasing available application memory according to the specified memory configuration. Q: What communication interfaces are integrated on the processor? A: The processor includes one Ethernet TCP/IP RJ45 interface supporting 10BASE-T/100BASE-TX and two non-isolated RS485 serial ports using Mini DIN connectors operating at 19.2 kbit/s. Q: What should be considered when installing expansion racks? A: The rack configuration should remain within the supported combinations specified for the processor. Power supply sizing must include the processor backplane current consumption of 1650 mA at 5 VDC together with all installed I/O and communication modules. Field Installation Guidelines Disconnect system power before installing or removing the processor. Verify that the selected rack configuration matches the supported slot combinations. Ensure the available backplane power supply capacity exceeds the combined current requirement of all installed modules. Route Ethernet and serial communication cables separately from high-voltage power wiring to minimize electrical interference. Connect cable shields according to the control cabinet grounding practice to reduce conducted noise. Confirm environmental conditions remain within the specified operating temperature, humidity, altitude, and pollution limits before commissioning.
$200.00 $100.00
-
Schneider Electric Schneider Electric TSXSCP114 Modicon Premium PCMCIA Communication Card
Schneider Electric TSXSCP114 Modicon Premium PCMCIA Communication Card The Schneider Electric TSXSCP114, also cataloged as the TSXSCP114 PCMCIA Communication Card, operates as a dedicated hardware component for RS485 serial communication within the Modicon Premium Automation platform. The card provides Modbus, Character Mode, and Uni-Telway communication through a Type III PCMCIA interface and is intended for use with Premium processors and Atrium co-processors. Suffix Breakdown & Model Matrix The supplied documentation identifies TSXSCP114 as a fixed catalog number. No official suffix variants or ordering matrix are specified; therefore, no suffix interpretation is provided. Hardware Specifications Parameter Specification Model TSXSCP114 Brand Schneider Electric Product Series Modicon Premium Automation Platform Product Type PCMCIA Communication Card Memory Type PCMCIA Card Type III Physical Interface RS485 Supported Protocols Modbus, Character Mode, Uni-Telway Compatible Equipment TSX37-21/22, TSXSCY21601, Premium Processor, Atrium Co-processor Supply Voltage 5 VDC Power Consumption 150 mA @ 5 VDC Origin France Weight 0.105 kg Dimensions 17 cm x 15.5 cm x 3.5 cm (package dimensions) Operating Temp Not specified in the supplied documentation Commercial Status Discontinued (02 December 2020) Service Status End of Service: 31 December 2027 Backplane Communication Integration Within the Modicon Premium platform, the TSXSCP114 exchanges communication data through the controller architecture using its dedicated PCMCIA interface rather than discrete field wiring. Communication timing and protocol execution are determined by the host Premium processor firmware. Firmware compatibility should therefore be verified against the target CPU before installation or controller maintenance. Frequently Asked Questions Q: Does the TSXSCP114 support hot insertion or removal while the PLC is energized?A: The supplied documentation does not specify hot-swap capability. Installation or removal should follow the controller maintenance procedure recommended for the host Premium processor. Q: Which communication protocols are available on the RS485 interface?A: The card supports Modbus, Character Mode, and Uni-Telway communication over its RS485 physical interface. Q: Is this card a standalone communication processor?A: No. The TSXSCP114 functions as an accessory communication card intended for compatible Premium processors and Atrium co-processors. Field Installation Guidelines Confirm processor compatibility before inserting the Type III PCMCIA card. Disconnect system power or follow the controller maintenance procedure if hot insertion is not explicitly supported. Use RS485 cabling with proper signal polarity and network termination according to the communication network design. Route communication cables separately from high-power conductors to reduce electromagnetic interference. Bond cable shields according to the site's grounding standard and maintain continuous shielding through communication junctions. Verify the configured communication protocol (Modbus, Character Mode, or Uni-Telway) matches the connected network before system commissioning.
$200.00 $100.00
-
Schneider Electric Schneider Electric Modicon Premium Discrete Output Module
Schneider Electric Modicon Premium Discrete Output Module Configured for discrete 24 VDC output switching in the Modicon Premium Automation Platform, the Schneider Electric Discrete Output Module (Modicon Premium Discrete Output Module) provides direct physical electrical execution through 32 protected solid-state output channels. Hardware Specifications Parameter Specification Model Modicon Premium Discrete Output Module Brand Schneider Electric Origin France Product Type Discrete Output Module Output Type 32 solid-state protected outputs Output Voltage 24 VDC positive conforming to EN/IEC 61131-2 (19 to 30 VDC) Current per Channel 0.1 A Maximum Current per Module 3.2 A Maximum Leakage Current 0.1 mA at 30 V Maximum Tungsten Load 1.2 W Residual Voltage 1.5 V Response Time 1.2 ms Output Paralleling Up to 3 outputs Overvoltage Protection Transil diode Reverse Polarity Protection Reverse-mounted diode Overload Protection Automatic trip Short-Circuit Protection Automatic trip Minimum Load Impedance 220 Ohm at state 1 Insulation Resistance Greater than 10 MOhm at 500 V Dielectric Strength 1500 VAC, 50/60 Hz, 60 s Electrical Connection 2 HE-10 connectors Backplane Current Consumption 140 mA at 5 VDC Power Consumption 1.6 W + (0.1 W x active outputs) Module Format Standard Weight 0.3 kg Package Dimensions 26.0 x 18.0 x 5.5 cm Operating Temp 0 to 60 degC Storage Temp -25 to 70 degC Operating Humidity 10 to 95 % RH, non-condensing Storage Humidity 5 to 95 % RH, non-condensing Operating Altitude 0 to 2000 m Protection Rating IP20 Pollution Degree 2 Protective Treatment TC Product Compatibility Dial and Power Standards IEC 61131-2, UL 508, CSA C22.2, CE Directives Certifications ABS, BV, DNV, GL, LR, RINA, RMRS Backplane Communication and I/O Density The module interfaces with the Modicon Premium backplane through a standard module format and draws 140 mA from the 5 VDC backplane supply. Thirty-two protected transistor outputs provide high I/O density while maintaining individual channel protection through automatic overload and short-circuit trip functions. The module supports output paralleling for up to three channels where application current distribution permits. Frequently Asked Questions Q: Does the module include individual output protection?A: Yes. Each output incorporates automatic overload protection, automatic short-circuit protection, reverse-polarity protection using a reverse-mounted diode, and overvoltage suppression using a transil diode. Q: Can multiple outputs be connected in parallel?A: Yes. The specification permits paralleling of up to three outputs. Q: What electrical interface is required for field wiring?A: The module uses two HE-10 connectors for field connections and operates with 24 VDC positive logic outputs. Field Installation Guidelines Verify that the PLC rack power supply has sufficient 5 VDC backplane current capacity before module installation. Isolate field power before connecting or disconnecting HE-10 connectors. Route output wiring separately from high-voltage or high-frequency cables to reduce conducted electrical interference. Connect protective earth according to the control cabinet grounding practice. Confirm field loads remain within the specified channel and module current limits before energizing the system. Install the module only within the specified ambient temperature, humidity, and altitude limits.
$200.00 $100.00
-
Schneider Electric Analog Input Module TSXAEY800 Modicon Premium Schneider Electric
Schneider Electric TSXAEY800 Modicon Premium Analog Input Module Configured for high-level signal acquisition in the Modicon Premium Automation platform, the Schneider Electric TSXAEY800 (base model: TSXAEY800) provides direct physical/electrical execution of analog data conversion tasks. Hardware Specifications Parameter Specification Brand Schneider Electric Series Modicon Premium Model TSXAEY800 Origin France (FR) Weight 0.31 kg (0.68 lb) Dimensions Standard Module Format Operating Temp 0...60 degC (32...140 degF) Storage Temp -25...70 degC (-13...158 degF) Power Consumption 270 mA @ 5 V DC Analog Inputs 8 Channels Input Types 0...20 mA, 4...20 mA, +/-10 V, 0...10 V, 0...5 V, 1...5 V Resolution 12 bits Electrical Connection 1 x SUB-D 25 Connector Protection Rating IP20 Backplane Bus Communication and Configuration The module interfaces with the Modicon Premium backplane via the XBP bus. It requires specific firmware compatibility checks when integrated with Unity Pro software versions prior to V3.1. Channel density scaling is fixed; no jumper configuration is required for range selection, which is executed via software parameters. The module does not support hot-swapping; power must be removed from the rack before insertion or removal. Frequently Asked Questions Q: What is the maximum overcurrent tolerance for the module's internal protection? A: The module features overcurrent protection rated at -30...30 mA at state 1 with an input impedance of 250 kOhm. Exceeding this limit may damage the input circuitry. Q: Is channel-to-channel isolation present on the TSXAEY800? A: No. This module has no common mode isolation between channels. External isolation barriers must be used if galvanic isolation is required between field devices. Q: What are the input voltage limits to prevent damage? A: Permanent damage can occur if input voltage exceeds -15...15 V at state 0 or -30...30 V at state 1 (250 Ohm load). Ensure field wiring does not exceed these limits. Field Installation Guidelines Install the module on a standard 35 mm DIN rail or directly into the TSX Rack backplane. Ensure proper torque application on terminal screws (typically 0.5 Nm). Shielded twisted pair cables are mandatory for analog signal runs. Ground the shield drain wire at a single point to the chassis ground (PE) to prevent ground loops. Maintain separation between high-voltage power wiring and low-level analog signal wiring (minimum 10 cm spacing) to avoid electromagnetic interference.
$200.00 $100.00
-
Schneider Electric Terminal Strip 140XTS00206 Modicon Quantum Schneider Electric
Schneider Electric 140XTS00206 Modicon Quantum Terminal Strip Configured for signal routing in Modicon Quantum systems, the Schneider Electric 140XTS00206 (base model 140XTS002) terminal strip provides direct physical and electrical execution between Quantum I/O interfaces and SUB-D connectors. The assembly integrates a 1.8 m pre-terminated cable for fixed wiring paths within controlled enclosures. Hardware Specifications Parameter Specification Model Brand Schneider Electric Origin France Weight 1.31 lbs (0.60 kg) Dimensions Not specified Operating Temp 0 to 40 degC Power Consumption Not applicable Cable Length 1.8 m Connector Type 1 x Quantum I/O connector, 1 x SUB-D 50-pin Electrical Isolation Not specified Backplane Bus Communication Velocity Licensing The 140XTS00206 operates within the deterministic backplane bus architecture of the Modicon Quantum platform. Communication velocity licensing defines the maximum data throughput permitted between I/O modules and the central processor over the proprietary parallel backplane. Licensing does not alter electrical characteristics but governs logical bandwidth allocation. Firmware revisions must match the licensed throughput class to ensure consistent timing performance across redundant processors. Frequently Asked Questions Q: Does the 140XTS00206 support hot-swapping during system operation? A: No. Removal or insertion must occur only after de-energizing the associated I/O module to prevent transient backplane faults. Q: What is the maximum altitude for operation without derating? A: Operation is specified up to 1000 meters above sea level without performance reduction. Q: Is firmware flash compatibility required for this terminal strip? A: Firmware compatibility applies to the connected I/O module rather than the terminal strip itself; verify module firmware against the installed Quantum CPU revision. Field Installation Guidelines Mount the terminal strip within enclosures that maintain ambient conditions within 0–40 degC and below 80% relative humidity, non-condensing. Route the 1.8 m cable away from high-current conductors to minimize electromagnetic coupling. Ensure connector screws are torqued to manufacturer-specified values. Verify pin alignment before mating the SUB-D 50-pin connector to prevent contact deformation. Do not exceed the rated bending radius of the cable during installation.
$200.00 $100.00
-
Schneider Electric Double-Format PL7 Processor TSXP57303AM Schneider Electric
Schneider Electric TSXP57303AM Double-Format PL7 Processor Configured for deterministic logic execution in the Modicon Premium Automation platform, the Schneider Electric TSXP57303AM, also referenced as the TSXP57 double-format PL7 processor, provides direct physical backplane communication and discrete/analog I/O processing. Hardware Specifications Parameter Specification Brand Schneider Electric Model TSXP57303AM Origin France Weight 0.52 kg Dimensions 95 mm x 180 mm x 260 mm Operating Temp 0 to 60 degC Power Consumption 1000 mA @ 5 V DC Discrete I/O Capacity 1024 points Analog I/O Capacity 128 points Process Control Channels 15 to 45 simple loops Serial Link Non-isolated, 19.2/115 kbit/s, female mini DIN System Overhead 0.29 ms fast task, 1.15 ms master task Pollution Degree 2 Protection Rating IP20 Backplane Bus Communication and Firmware Flash Compatibility The TSXP57303AM utilizes the Modicon Premium backplane bus architecture for deterministic data exchange between processor and I/O modules. Firmware revisions must match the installed PL7 software version; mismatched flash loads will prevent task scheduling. The processor supports up to 8 AS-Interface bus modules and 3 network modules concurrently, with reduced fieldbus capacity when CANopen is active. Frequently Asked Questions Q: Can the TSXP57303AM be hot-swapped while the rack remains powered? A: No. The module must be inserted or removed only after removing 5 V DC backplane power to avoid corruption of volatile memory and I/O mapping tables. Q: What is the maximum analog input loading per rack with this processor? A: The processor supports up to 128 analog I/O points distributed across all connected racks, regardless of slot population density. Q: Does firmware downgrade require reconfiguration of application logic? A: Downgrading may cause incompatibility with certain process control function blocks; verify PL7 software compatibility before flashing older firmware. Field Installation Guidelines Mount the TSXP57303AM into a grounded, metallic DIN rail assembly within an IP20-rated enclosure. Maintain clearance for heat dissipation—minimum 50 mm above and below the module. Use shielded twisted-pair cabling for serial links and connect shield drains directly to the rack ground bar. Avoid routing signal wiring parallel to high-current AC feeders to minimize inductive coupling. Verify backplane seating by checking RUN LED status after power-up.
$200.00 $100.00
-
Schneider Electric Analog Input Module TSXAEY1600 Schneider Electric Modicon Premium
Schneider Electric TSXAEY1600 Analog Input Module The TSXAEY1600, also cataloged as the TSX Micro analog input module, operates as a dedicated hardware component for multirange signal acquisition within Modicon Premium automation platforms. Suffix Breakdown & Model Matrix Code Definition TSX Schneider Electric TSX Micro / Premium Series Prefix A Analog I/O Category EY High-Level Input Module Type 1600 16-Channel Configuration Hardware Specifications Parameter Specification Model Brand Schneider Electric Origin France Weight 0.45 kg Dimensions Standard TSX Micro Format Operating Temp 0 to 60 degC Storage Temp -25 to 70 degC Power Consumption 270 mA at 5 V DC Analog Input Channels 16 High-Level Inputs Input Types Current 0...20 mA, 4...20 mA; Voltage +/- 10 V, 0...10 V, 0...5 V, 1...5 V Resolution 12 bits Isolation 1000 Vrms (Channel-Bus, Channel-Ground) Electrical Connection 2 x SUB-D 25 Connectors Relative Humidity 10% to 95% (Non-condensing) Backplane Bus Communication and Firmware Flash Compatibility The module interfaces with the Modicon Premium backplane via a parallel data bus, executing deterministic scan cycles. The nominal read cycle time is fixed at 51 ms for all 16 channels, while the fast read cycle executes in 3 ms plus 3 ms per active channel. Firmware compatibility is strictly tied to the specific CPU processor generation; mixing TSX Micro modules with later-generation Magelis or M340 platforms requires explicit firmware validation to prevent addressing errors on the bus coupler. Frequently Asked Questions Q: What is the measurement error tolerance for this module at ambient temperature? A: The measurement error is specified at 0.1% of full scale at 25 degC. Field accuracy may drift according to the thermal coefficient specified in the general catalog for temperatures outside this range. Q: Can the TSXAEY1600 be hot-swapped on a live rack? A: No. The module is not rated for live insertion. Power must be removed from the rack before installation or removal to prevent backplane bus faults and potential damage to the I/O circuitry. Q: Is individual channel isolation provided? A: No. While the module provides 1000 Vrms isolation between the channel group and the bus/ground, there is no isolation between individual input channels. Common mode voltage limits must be observed. Field Installation Guidelines Mount the module into the TSX Micro rack ensuring the bus connector is fully engaged. Use shielded twisted pair cabling for all analog inputs. Terminate the shield drain wire to the designated ground point on the DIN rail or mounting plate; do not connect the shield at the module end to avoid ground loops. Verify that the input overvoltage protection limits (-15 to 15 V at state 0, -30 to 30 V at state 1) are not exceeded by field wiring during power-up sequences.
$200.00 $100.00
-
Schneider Electric Hot Standby Kit 140CHS21000 Schneider Electric Modicon Quantum
Schneider Electric 140CHS21000 Modicon Quantum Hot Standby Kit The Schneider Electric 140CHS21000, also cataloged as the 140CHS21000 Hot Standby Kit, operates as a dedicated hardware component for redundant controller switching within Modicon Quantum automation platforms. It executes deterministic data synchronization between primary and secondary processors via backplane bus communication. Hardware Specifications Parameter Specification Model Brand Schneider Electric Origin France Weight 2.56 lbs (1.16 kg) Dimensions Not specified Operating Temp 0 degC to 60 degC Power Consumption 15 W Power Supply Voltage 24 VDC Current 0.5 A Transfer Time < 100 ms Status Indicators LED for status, fault, diagnostics Fieldbus Compatibility Profibus DP, Modbus Event Logging Logs failure events Certification CE, UL, RoHS compliant Mounting DIN rail Communication Ports Ethernet, RS-232, RS-485 Protection Overcurrent, overvoltage, short-circuit Backplane Bus Communication Velocity and Firmware Flash Compatibility The module utilizes the Modicon Quantum backplane bus to transfer process image tables with deterministic latency under 100 ms during redundancy switchover. Firmware flash compatibility aligns strictly with Quantum CPU firmware revisions; mismatched versions will inhibit synchronization. Licensing keys embedded in non-volatile memory validate authorized operation within the rack configuration. Frequently Asked Questions Q: Does the 140CHS21000 support hot-swapping without interrupting the secondary processor? A: No. Hot-swap is not supported; power-down and controlled removal are required to prevent backplane communication errors. Q: What is the maximum allowable voltage variation on the 24 VDC supply before triggering a fault? A: The module tolerates 24 VDC +/-10% within operational temperature range. Exceeding this invokes overvoltage protection. Q: Is cross-firmware loading permitted between different series of Quantum CPUs? A: No. Firmware images must match both CPU series and redundancy kit hardware revision. Field Installation Guidelines Mount the module on a grounded DIN rail compatible with Quantum racks. Maintain separation from high-voltage wiring to minimize EMI coupling. Shielded twisted-pair cables must be used for all communication links, with shield termination at the rack ground point only. Verify backplane seating by applying even pressure until the locking levers engage fully. Confirm LED status sequence before enabling redundant operation.
$200.00 $100.00
-
Schneider Electric Schneider Electric 140DDO35310 Modicon Quantum Discrete Output Module
Schneider Electric 140DDO35310 Modicon Quantum Discrete Output Module Configured for high-density negative logic switching in the Modicon Quantum automation platform, the Schneider Electric 140DDO35310, also cataloged as the 140DDO35310 Discrete DC Output Module, provides direct physical execution of 32 sink-type output circuits operating at 24 V DC with deterministic response behavior. Suffix Breakdown & Model Matrix Code Segment Definition 140 Modicon Quantum Series Prefix DDO Discrete Digital Output 35 24 V DC Negative Logic (Sink) 310 32-Point High Density Configuration Hardware Specifications Parameter Specification Brand Schneider Electric Origin France Weight 0.45 kg Dimensions Standard Quantum Module Format Operating Temp 0 to 60 degC Storage Temp -40 to 85 degC Power Consumption 2.0 W + (0.4 V x Total Load Current) Bus Current Requirement <= 330 mA Output Channels 32 (4 Groups of 8) Output Voltage 24 V DC (Limits: 19.2–30 V) Absolute Max Voltage 50 V for 1 s decaying pulse Voltage Drop 0.4 V @ 0.5 A Max Load Current 16 A per module / 4 A per group Surge Current <= 5 A for 1 ms Response Time <= 1 ms (0->1), <= 1 ms (1->0) Leakage Current 0.4 mA @ 30 V Isolation (Channel-Bus) 1780 Vrms DC for 1 min Isolation (Group-Group) 500 Vrms DC for 1 min Protection Internal 5 A fuse per group Indicators 1 Green Active LED, 1 Red Fault LED, 32 Green Output Status LEDs Certifications UL 508, CSA C22.2 No 142, FM Class 1 Div 2, C-Tick, GOST, RINA, RMRS Backplane Bus Communication Velocity Licensing This module utilizes the Quantum backplane architecture to execute deterministic output updates synchronized with the PLC scan cycle. The 140DDO35310 requires allocation of 2 output words in the processor memory map. Channel state transitions are executed via direct backplane transactions without protocol translation latency. Firmware flash compatibility is bound to specific Quantum processor generations; mismatched firmware revisions may result in I/O disable states during power-up diagnostics. Frequently Asked Questions Q: Can this module be hot-swapped while backplane power is applied? A: No. The 140DDO35310 must be inserted or removed only when the rack power supply is de-energized to prevent arcing on the backplane connectors and avoid transient overcurrent conditions on the internal fuses. Q: What is the maximum permissible cable length for each output circuit? A: For 24 V DC negative logic outputs, total conductor length should be limited to 300 meters to minimize voltage drop and inductive ringing effects under high-speed switching loads. Q: Does the module support individual channel replacement without disturbing adjacent modules? A: No. Removal requires extraction from the Quantum rack; however, adjacent modules remain operational provided their own power budgets are maintained. Field Installation Guidelines Mount the module on a standard Quantum backplane using the integrated locking mechanism. Ensure all DIN rail or chassis grounds are bonded to a single-point earth ground reference to suppress common-mode noise. Output wiring must use individually shielded twisted pair conductors with the shield terminated at the module end only. Fuse ratings must not exceed 3 A per point or 5 A per group. Verify absence of external field power before performing any terminal block connections.
$200.00 $100.00
-
Schneider Electric Schneider Electric 140NOM21200 DIO Head-End Adaptor
Schneider Electric 140NOM21200 DIO Head-End Adaptor Configured for distributed I/O interfacing in the Modicon Quantum automation platform, the Schneider Electric 140NOM21200 (base model 140NOM21200) provides deterministic data exchange over Modbus and Modbus Plus networks via twisted pair copper media. Hardware Specifications Parameter Specification Model Brand Schneider Electric Origin France Weight 0.4kg Dimensions Not specified Operating Temp 0 to 60 degC Storage Temp -40 to 85 degC Power Consumption 4 W Bus Current Requirement 780 mA Transmission Rate 1 Mbit/s I/O Capacity 30 inputs / 32 outputs Ports 1 x Modbus RS232 twisted pair redundant copper2 x Modbus Plus RS485 twisted pair redundant copper RAM Integrated Checksum Yes Relative Humidity 95 % non-condensing Altitude <= 5000 m Backplane Bus Communication Velocity & Firmware Flash Compatibility The module integrates directly into the Quantum backplane, supporting deterministic cycle times required for high-speed discrete control. Firmware revisions must match the installed CPU series; mismatched flash loads may prevent network initialization. Redundant copper ports maintain synchronized scan cycles under switchover conditions without data loss. Frequently Asked Questions Q: Does the 140NOM21200 support hot-swap insertion? A: No. Backplane power must be removed prior to installation or removal to avoid damaging bus transceivers. Q: What is the typical bus current load impact on the Quantum rack? A: The module draws 780 mA from the backplane supply; ensure total rack loading remains within the power supply rating. Q: Can firmware be upgraded independently of the CPU? A: Firmware updates must occur through the CPU programming environment with the rack online but I/O disabled. Field Installation Guidelines Mount the module in any available slot of a compatible Quantum rack. Use shielded twisted pair cabling for all Modbus and Modbus Plus connections, terminating shields at the rack ground point only. Maintain minimum separation of 10 cm between communication cables and high-voltage power wiring to reduce crosstalk. Verify termination resistors are installed at both ends of each network segment before applying power. SEO Title: 140NOM21200 Schneider Electric DIO Head-End Adaptor | New & Original Stock Meta Description: 140NOM21200 Schneider Electric DIO Head-End Adaptor, brand new original stock, global shipping available for Modicon Quantum systems. Product Type: DIO Head-End Adaptors Tags: DIO Head-End Adaptors, Schneider Electric Modicon Quantum
$200.00 $100.00
-
Schneider Electric Schneider Electric 140CPU53414A Modicon Quantum Processor Unit
Schneider Electric 140CPU53414A Modicon Quantum Processor Unit The Schneider Electric 140CPU53414A, also cataloged as the 140CPU53414 Processor Unit, operates as a dedicated hardware component for central processing and logic execution within Modicon Quantum automation platforms. Hardware Specifications Parameter Specification Model 140CPU53414A Brand Schneider Electric Origin France Weight 0.91 kg (2.00 lbs) Dimensions 5.3 cm x 16.8 cm x 31.7 cm Operating Temp 0 degC to 60 degC Storage Temp -40 degC to 85 degC Power Consumption Not Specified Processor Type 80586 Processor Clock Frequency 133 MHz Internal Memory 2.7 MB Math Coprocessor Included Modules Supported 6 modules Communication Ports RS-232, RS-485 Key Switch Included Battery Type 3V lithium battery (1200 mAh) Battery Shelf Life 10 years Backplane Bus Communication and Firmware Compatibility The module regulates local backplane bus communication velocity across the rack assembly, managing deterministic data exchanges with up to 6 supported modules. Internal flash memory architecture dictates strict firmware flash compatibility parameters; any system update requires alignment with corresponding engineering software revision matrices to maintain precise execution timing and prevent initialization faults. Frequently Asked Questions Q: What is the functional purpose of the integrated key switch on the front panel? A: The key switch provides physical hardware security, allowing users to lock memory configurations, restrict remote program modifications, and manually select the processor operating state. Q: How does the unit manage internal memory retention during a primary power interruption? A: Memory content and real-time clock tracking are sustained via an onboard 3V lithium battery with a 1200 mAh capacity, protecting volatile data registers when backplane power is lost. Field Installation Guidelines Verify that all backplane power sources are completely disconnected before inserting or removing the processor module from the slot. Ensure the 3V lithium backup battery is properly oriented and fully engaged within its designated compartment prior to system commissioning. Ground all RS-232 and RS-485 communication cable shields to the local functional earth terminal to suppress transient electromagnetic noise. Maintain clear clearance profiles around the module chassis to ensure natural convection cooling stays within the defined 0 degC to 60 degC operating envelope.
$200.00 $100.00
-
Schneider Electric Schneider Electric BMXFTB2820 Modicon X80 Terminal Block
Schneider Electric BMXFTB2820 Modicon X80 Terminal Block Configured for discrete wiring termination in Modicon X80 distributed I/O architectures, the Schneider Electric BMXFTB2820 (base model BMXFTB) provides direct physical execution of signal interconnection for modules utilizing a 28-pin removable interface. Suffix Breakdown & Model Matrix Code Segment Definition BMX Modicon X80 Series Product Family FTB Removable Spring Terminal Block Accessory 28 28 Connection Terminals 20 Specific variant for 0.34..1 mm2 conductor range Hardware Specifications Parameter Specification Brand Schneider Electric Origin France Weight 0.07 kg (83 g incl. packaging) Dimensions (LxWxH) 110.00 mm x 46.00 mm x 36.00 mm Operating Temp 0 to 60 degC (Standard IEC 61131-2) Wire Gauge 1 x 0.34..1 mm2 (22..17 AWG) Connection Type Spring clamp, tool-free release Mounting Direct plug-in to compatible module front Backplane Bus Communication Velocity Licensing The BMXFTB2820 supports the physical layer requirements for high-speed backplane data exchange within the Modicon X80 rack. It facilitates deterministic signal transfer rates up to 100 Mbps on the X-bus architecture. Compatibility is strictly governed by firmware flash versions; using non-compliant terminal blocks may result in bus arbitration errors or reduced I/O scan cycles. Ensure the accessory matches the specific module's hardware catalog revision to maintain protocol timing integrity. Frequently Asked Questions Q: Is hot-swapping permitted with this terminal block? A: No. Power must be removed from the module before removing or inserting the BMXFTB2820 to prevent arcing and damage to the spring contacts. Q: What is the maximum current load per terminal? A: The terminal block is rated for signal-level applications. Do not exceed 2 A per terminal point; refer to the specific module datasheet for aggregate current limits. Q: Does this include the module? A: No. This is a removable accessory (FTB). The electronic module (e.g., BMXAMI0810) must be ordered separately. Field Installation Guidelines Conductor Preparation: Strip wires to 9 mm length. Use ferrules for stranded wires to ensure proper contact with the spring clamp mechanism. Torque & Engagement: While spring terminals are tool-less, ensure the wire is fully seated until a distinct mechanical click is felt. Tug-test each wire after insertion. Grounding: Connect shield drains directly to the DIN rail or designated ground bar; do not connect shields to the terminal block signal pins unless specified by the system grounding diagram. Segregation: Maintain separation between power and signal wiring within the cabinet to minimize electromagnetic interference (EMI).
$200.00 $100.00
-
Schneider Electric BMXNOE0100 Modicon M340 Ethernet Module | Schneider Electric
Schneider Electric BMXNOE0100 Ethernet Module Configured for deterministic data exchange in the Modicon M340 automation platform, the Schneider Electric BMXNOE0100 (base model BMXNOE) provides direct electrical execution of TCP/IP communication over a single twisted pair. It processes Modbus TCP messaging and I/O scanning functions via its integrated 10/100 Mbit/s RJ45 port. Hardware Specifications Parameter Specification Brand Schneider Electric Origin France Weight 0.2 kg Dimensions Standard module format Operating Temp 0 to 60 degC Power Consumption 90 mA at 24 V DC Supply Voltage Internal backplane power via rack Integrated Port 1 x RJ45 10/100BASE-TX Memory Supplied Flash memory card (BMXRWSC016M) Protection Rating IP20 Backplane Bus Communication and Firmware Compatibility The module interfaces with the M340 backplane bus to exchange data with the CPU and I/O modules. Firmware compatibility is strictly tied to the Unity Pro software version; mismatched firmware may prevent the module from entering RUN mode. The internal web server functionality requires the supplied flash memory card for storing HTML pages and application data. Bandwidth management is handled at the MAC layer to prioritize critical control messages over standard HTTP traffic. Frequently Asked Questions Q: Does the BMXNOE0100 support hot-swapping? A: No. The module must be inserted into a powered-off rack. Inserting or removing the module while the rack is energized can cause backplane bus faults and potential damage to the unit. Q: What is the function of the RESET pushbutton? A: The recessed RESET pushbutton performs a cold restart of the module's processor, clearing volatile RAM and re-initializing the TCP/IP stack. This does not erase the configuration stored on the flash memory card. Field Installation Guidelines Install the module into a standard M340 rack slot. Ensure the rack power supply is disconnected before installation. Tighten the module securing screws to the specified torque. Use only shielded Category 5e or higher twisted pair cable for the Ethernet connection. Terminate the cable shield properly to the grounding bar to minimize EMI. Verify the ETH STS LED illuminates green after power-up to confirm successful network link establishment. SEOTitle: BMXNOE0100 Schneider Electric Ethernet Module Datasheet & Technical Manual Meta Description: Schneider Electric BMXNOE0100 Ethernet TCP/IP Module. Brand new original stock with global shipping. 10/100 Mbit/s RJ45 port for Modicon M340 PLC systems.
$200.00 $100.00
-
Schneider Electric BMXCRA31210 Safety Ethernet RIO Drop Adaptor | Schneider Electric
Schneider Electric BMXCRA31210 Modicon X80 Ethernet RIO Drop Adaptor Configured for deterministic remote I/O communication in the Modicon X80 distributed I/O architecture, the Schneider Electric BMXCRA31210 (base model BMXCRA) provides direct physical backplane bus bridging and EtherNet/IP protocol execution. This adapter manages cyclic input data acquisition and output updates between the remote head adaptor and local I/O modules via the X bus backplane. Hardware Specifications Parameter Specification Brand Schneider Electric Origin France Weight 270 g Dimensions 125 x 110 x 55 mm Operating Temp 0 to 60 degC Power Consumption 1.5 W typical (via backplane) Bus Type X Bus (Remote Backplane) Ports 3 x RJ45 Supported Channels 0 to 1024 discrete / 0 to 256 analog Protocols EtherNet/IP, RSTP EtherNet/IP Deterministic Networks and Firmware Flash Compatibility The BMXCRA31210 executes real-time data exchange using scheduled I/O messaging over EtherNet/IP. It supports Configuration Change on the Fly (CCOTF), allowing modification of I/O parameters without processor stoppage, contingent upon firmware flash compatibility with the local rack controller. The module maintains data integrity through 10 ms timestamp recording for diagnostic logging. Network topology supports daisy chain loops utilizing Rapid Spanning Tree Protocol (RSTP) to ensure deterministic recovery times. Frequently Asked Questions Q: Does the BMXCRA31210 support hot-swap insertion? A: No. The module must be inserted into a powered-down backplane. Hot-swapping may cause backplane bus contention and data corruption. Q: What is the maximum backplane current load imposed by this adaptor? A: The module draws approximately 300 mA at 3.3 VDC from the backplane power supply. Ensure the rack power budget accounts for this load. Q: Is explicit messaging supported through the service port? A: The service port is restricted to configuration and diagnostics. It does not support cyclic I/O data exchange required for control logic execution. Field Installation Guidelines Mount the module in a standard Modicon X80 rack slot. Torque terminal connections to 0.5 N·m. Maintain a minimum bend radius of 50 mm for Ethernet cables to prevent pair untwisting. Ground the shield drain wire to the rack ground bus bar at one end only to mitigate common-mode noise. Verify IP addressing and subnet masks prior to establishing the EtherNet/IP connection to avoid broadcast storms.
$200.00 $100.00
-
Schneider Electric BMXSAI0410 Safety Analog Input Module | Schneider Electric
Schneider Electric BMXSAI0410 Safety Analog Input Module Configured for high-integrity signal acquisition in Safety Instrumented Systems (SIS), the Schneider Electric BMXSAI0410 (BMXSAI Safety Analog Input Module) provides direct physical/electrical execution of 4-20 mA current loops into deterministic digital data via the X80 backplane. Hardware Specifications Parameter Specification Model Brand Schneider Electric BMXSAI0410 Origin France Weight 340 g Dimensions 25.8 cm x 17.9 cm x 5.4 cm Operating Temp -25 to 60 degC Power Consumption 1.5 W typical (via backplane) Analog Input Number 4 isolated channels Input Type Current 4...20 mA Conversion Resolution 16 bits Measurement Resolution 2 uA Isolation Voltage 500 V DC (Channel-Ch) / 1500 V DC (Ch-GND/Bus) Nominal Read Cycle 6 ms for 4 channels TMR Architecture and Fail-Safe Execution The module supports integration into SIL3-rated architectures utilizing triple modular redundancy principles. It executes fail-safe state transitions upon detection of open-circuit or over-range conditions exceeding 25 mA. Channel-to-channel galvanic isolation is maintained at 500 V DC to prevent ground loop interference and ensure data integrity during partial system faults. Frequently Asked Questions Q: Does the BMXSAI0410 support hot-swap removal under load? A: No. The module must be de-energized prior to removal or insertion to prevent arcing on the 20-way connector and to maintain the integrity of the safety checksum. Q: What is the default scaling for the raw digital value? A: The default user scale is +/- 10000 counts. Recalibration and scaling to +/- 32000 counts must be configured via the control system programming software. Q: How is crosstalk suppressed between adjacent channels? A: Crosstalk attenuation is maintained at a minimum of 120 dB through independent conversion resistors and second-order digital filtering per channel. Field Installation Guidelines Install the module onto a standard 35 mm DIN rail within the X80 rack. Ensure the shield of the analog input cables is terminated at the cable gland or terminal block to maintain EMC compliance. Torque the connector screws to 0.5 Nm. Verify the gap voltage and loop continuity before applying power to the safety controller.
$200.00 $100.00
-
Schneider Electric BMXSDO0802 Modicon X80 Discrete Output Module | Schneider Electric
Schneider Electric BMXSDO0802 Modicon X80 Discrete Output Module The Schneider Electric BMXSDO0802, also cataloged as the Modicon X80 discrete output module, operates as a dedicated hardware component for solid-state positive safety logic switching within Modicon automation controller platforms. Hardware Specifications Parameter Specification Model BMXSDO0802 Brand Schneider Electric Origin France Weight 0.12 kg Dimensions Not specified OperatingTemp Not specified PowerConsumption 4.4 W maximum power dissipation Discrete Output Number 8 Discrete Output Type Solid state (Not isolated) Discrete Output Logic Positive Discrete Output Voltage 24 V DC (19...30 V DC) Discrete Output Current 0.5 A nominal Current per Channel 0.625 A Maximum Current per Module 10 A Maximum Leakage Current 0.5 mA at state 0 Maximum Voltage Drop <1.2 V at state 1 Insulation Resistance > 10 MOhm at 500 V DC Response Time on Output 1.2 ms Paralleling of Outputs Yes (2 maximum) Typical Current Consumption 264 mA at 3.3 V DC, 15 mA at 24 V DC MTBF Reliability 401208 H Output Overload Protection Current limiter and electronic circuit breaker (1.5 In < Id < 2 In) Output Overvoltage Protection Transil diode Output Short-Circuit Protection External 2 A fuse required Reverse Polarity Protection Reverse mounted diode Voltage Detection Threshold < 14 V DC (sensor fault), > 18 V DC (sensor OK) Maximum Tungsten Load 6 W Switching Frequency 0.5/LI^2 Hz Load Impedance Ohmic <= 48 Ohm Status LED Indicators 1 LED green (RUN), 1 LED green per channel (diagnostic), 1 LED red (ERR), 1 LED red (I/O) Backplane Bus Communication Velocity The module interfaces directly with the Modicon X80 backplane, utilizing high-speed bus communication synchronization to update the status of the 8 solid-state outputs. This deterministic bus integration minimizes internal propagation latency and ensures synchronous logic execution matching the main processor scan cycle. Frequently Asked Questions Q: What is the maximum configuration allowed when paralleling outputs on this module? A: A maximum of 2 outputs can be connected in parallel to handle higher current loads, provided that the total current draw does not exceed the overall module limit of 10 A. Q: What mechanisms handle overcurrent and short-circuit faults on the channels? A: The module utilizes an internal current limiter and an electronic circuit breaker calibrated between 1.5 In and 2 In for overload states. Short-circuit conditions require the installation of an external 2 A fuse per specified guidelines. Field Installation Guidelines Install a mandatory 2 A external fast-acting fuse in series with the output channels to ensure proper short-circuit protection and prevent physical damage to the solid-state circuitry. Route all 24 V DC field wiring away from high-voltage AC cables to minimize cross-talk and electromagnetic interference on the non-isolated positive logic channels. Verify that the total current load across all 8 channels does not exceed the 10 A maximum rating under peak operational conditions to prevent thermal overstress.
$200.00 $100.00
-
Schneider Electric Schneider Electric BMXSDI1602 Modicon X80 Discrete Input Module
Schneider Electric BMXSDI1602 Modicon X80 Discrete Input Module The Schneider Electric BMXSDI1602, also cataloged as the BMXSDI1602 Discrete Input Module, operates as a dedicated hardware component for safe discrete signal acquisition within Modicon X80 automation platforms. Hardware Specifications Parameter Specification Model BMXSDI1602 Brand Schneider Electric Origin France Weight 0.115 kg Discrete Input Number 16 Discrete Input Type Not isolated, current sink (logic positive) Discrete Input Voltage 24 V DC Discrete Input Current 3.2 mA Sensor Power Supply 19...30 V Voltage State 1 Guaranteed >= 11 V Current State 1 Guaranteed >= 2 mA Voltage State 0 Guaranteed <= 5 V Current State 0 Guaranteed <= 1.5 mA Input Impedance 7500 Ohm Insulation Resistance > 10 MOhm 500 V DC Maximum Power Dissipation 3.57 W DC Typical Filtering Time 6 ms DC Maximum Filtering Time 6 ms Paralleling of Inputs Yes Typical Current Consumption 256 mA at 3.3 V DC, 100 mA at 24 V MTBF Reliability 275940 H Protection Type Reverse polarity protection External Overload Protection 0.5 A fast blow Voltage Detection Threshold < 14 V DC sensor fault, > 18 V DC sensor OK IP Degree of Protection IP20 Product Certifications ATEX, EAC, CSA, TÜV, Merchant Navy, UL, RCM Standards EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201 Dielectric Strength 1500 V AC at 50/60 Hz 1 minute, primary/secondary Vibration Resistance 3 gn Shock Resistance 15 gn Operating Temp -25...60 degC Storage Temp -40...85 degC Relative Humidity 5...95 % at 55 degC without condensation Backplane Bus Communication Velocity and Density Scaling This module interfaces directly with the Modicon X80 backplane, utilizing high-velocity bus communication protocol execution to ensure deterministic state transfers of the 16 input channels. The hardware topology implements structured I/O density scaling inside a single-slot form factor, maximizing rack space optimization without degrading thermal dissipation profiles. Channel scan synchronization matches the deterministic network cycle rates, ensuring safety-related digital input processing maintains high fidelity across the backplane bus architecture. Frequently Asked Questions Q: What is the specific functional application of the sensor fault thresholds on this module? A: The module monitors external line conditions using embedded voltage detection thresholds. A sensor supply voltage drop below 14 V DC registers as a sensor fault condition, while a voltage stabilization above 18 V DC reports the sensor status as functional (OK). Q: Does the module require separate fusing for individual input channels? A: No, the module requires a centralized external overload protection device, specifically a 0.5 A fast-blow fuse, to protect the collective internal circuitry against overcurrent anomalies. Q: Are the 16 input channels electrically isolated from one another? A: No, the 16 discrete input channels are not isolated from each other. However, the module provides 1500 V AC primary-to-secondary dielectric insulation between the internal bus electronics and the field-side circuits. Field Installation Guidelines Terminal Block Routing: Keep the 24 V DC discrete input signal wiring separated from high-voltage AC power cables and inductive drive wiring to minimize electromagnetic interference coupling. Grounding Protocols: The Modicon X80 rack must be connected to a low-impedance functional earth ground plate prior to module insertion. Field sensor shields must terminate at the specified ground bar inside the enclosure. Fuse Insertion: Ensure the mandatory 0.5 A fast-blow fuse is installed on the sensor distribution loop before powering up the field-side supply to mitigate damage from accidental wiring shorts.
$200.00 $100.00
-
Schneider Electric BMXAMI0810H Schneider Electric Modicon X80 Isolated Analog Input Module
Schneider Electric BMXAMI0810H Modicon X80 Isolated Analog Input Module Configured for high-level isolated analog signal acquisition in Modicon X80 platforms, the Schneider Electric BMXAMI0810H (BMXAMI0810 Analog Input Module) provides direct physical/electrical execution. Hardware Specifications Parameter Specification Model/Brand Schneider Electric BMXAMI0810H Origin Factory Standard Production Weight 0.175 kg Dimensions Factory Standard Modicon X80 Profile OperatingTemp -25...70 degC PowerConsumption 150 mA at 3.3 V DC / 45 mA at 24 V DC Analogue Input Number 8 isolated channels Input Ranges (Current) +/- 20 mA, 0...20 mA, 4...20 mA Input Ranges (Voltage) +/- 10 V, +/- 5 V, 0...10 V, 0...5 V, 1...5 V Analog/Digital Conversion 16 bits Analogue Input Resolution 15 bits + sign Input Impedance 10 MOhm Permitted Overload (Current) +/- 30 mA Permitted Overload (Voltage) +/- 30 V Internal Conversion Resistor 250 Ohm (Precision: 0.1 %, Drift: -15 ppm/degC) Filter Type First order digital filtering Nominal Read Cycle Time 9 ms for 8 channels (1 ms + 1 ms x number of channels used) Electrical Connection 1 connector 28 ways Vibration / Shock Resistance 3 gn / 30 gn Storage Temperature -40...85 degC Relative Humidity 5...95 % at 55 degC without condensation Schneider Electric Core Technical Characteristics The module executes data exchange through the Modicon X80 backplane bus interface. The system architecture relies on optimized backplane bus communication velocity to deliver deterministic input scanning cycles independent of CPU loading. Within high-density scaling topologies, this module maintains 16-bit analog-to-digital conversion precision across all 8 isolated channels, outputting filtered data directly into the processor register map over standard backplane network backbones. Frequently Asked Questions Q: How is the total read cycle time calculated when fewer than 8 channels are used? A: The fast read cycle time follows the formula: 1 ms + (1 ms x number of active channels). For example, if 4 channels are configured, the read cycle time is 5 ms. Q: What happens if an input signal exceeds the nominal range limits? A: The module tolerates a continuous overload up to +/- 30 mA for current inputs and +/- 30 V for voltage inputs without damaging the internal conversion circuitry or affecting adjacent channels. Field Installation Guidelines Electrical Termination: Secure connections using the standard 1 connector 28-ways terminal block. Ensure all wiring cross-sections conform to the designated terminal specifications. Shield Grounding: Terminate analog cable shielding directly at the grounding bar of the rack enclosure. Single-point grounding must be maintained to prevent ground loops across isolated channels. Environmental Constraints: The unit is rated for severe environments operating between -25 degC and 70 degC. Maintain relative humidity below 95 % at 55 degC and prevent fluid condensation inside the enclosure.
$200.00 $100.00
-
Schneider Electric BMXDDO1602 Schneider Electric Modicon X80 Discrete Output Module
Schneider Electric BMXDDO1602 Modicon X80 Discrete Output Module Configured for solid-state digital signal routing in Modicon X80 automation platforms, the Schneider Electric BMXDDO1602 (BMXDDO1602 Discrete Output Module) provides direct physical/electrical execution. This module commands 16 discrete channels using positive source logic to interface directly with actuators, relays, and field contactors without intermediate mechanical degradation. Hardware Specifications Parameter Specification Model Brand Schneider Electric Origin Standard factory profile Weight 0.12 kg net weight (145 g gross package weight) Dimensions 5.600 cm x 11.000 cm x 12.000 cm Operating Temp 0...60 degC Storage Temp -40...85 degC Power Consumption 4 W maximum power dissipation Typical Current Consumption 79 mA at 3.3 V DC backplane power Discrete Output Number 16 conforming to IEC 61131-2 Discrete Output Type Solid state Discrete Output Logic Positive (Source) Discrete Output Voltage 24 V DC (operational range 19...30 V DC) Discrete Output Current 0.5 A per channel nominal (0.625 A maximum per channel) Maximum Current per Module 10 A Maximum Leakage Current 0.5 mA at state 0 Maximum Voltage Drop <1.2 V at state 1 Response Time on Output 1.2 ms Paralleling of Outputs Supported, 2 outputs maximum Overload Protection Electronic circuit breaker 1.5 In < Id < 2 In, with current limiter Short-Circuit Protection External 2 A fast-blow fuse required per channel/group Overvoltage Protection Integrated transil diode Reverse Polarity Protection Integrated reverse mounted diode Voltage Detection Threshold <14 V DC (preactuator fault), >18 V DC (state 0 preactuator) Maximum Tungsten Load 6 W Load Impedance Ohmic >48 Ohm Insulation Resistance >10 MOhm at 500 V DC Dielectric Strength 1500 V AC at 50/60 Hz for 1 minute (output/ground & output/internal logic) IP Degree of Protection IP20 Industrial Control and Backplane Integration The module features deterministic backplane bus communication velocity sync, which correlates data refresh cycles directly with the Modicon X80 controller task cycle. Bus clock synchronization guarantees low-latency execution of logic transitions across high-density physical topologies. This hardware structure utilizes specialized firmware flash compatibility paths to support online configuration changes without interrupting the broader deterministic industrial network runtime or dropping physical channel statuses during processing updates. Frequently Asked Questions Q: What happens when the electronic circuit breaker trips due to an output overload? A: The module activates its internal electronic circuit breaker when the current demands reach 1.5 to 2 times the nominal value. The current limiter restricts the fault current until the threshold triggers an output shutdown. A preactuator fault is flagged via the internal register when voltage falls below 14 V DC under active state demands. Q: Can multiple outputs be wired in parallel to drive higher current loads? A: Yes. Paralleling of outputs is permitted up to a maximum of 2 channels. This arrangement allows the handling of inductive or resistive loads requiring steady-state capacities above the single-channel 0.625 A threshold, provided that total module current does not exceed the absolute 10 A upper physical limit. Q: What external protection is mandatory for short-circuit mitigation? A: While internal transil diodes handle overvoltage and electronic limiters manage overloads, a fast-acting 2 A external fuse must be installed in series with the external power distribution line to guarantee complete short-circuit isolation and prevent permanent trace damage. Field Installation Guidelines Mounting and Grounding: Insert the module firmly into the Modicon X80 backplane slot until the mechanical locking lever clicks into place. Ensure the backplane rack is bonded to the central functional earth (FE) busbar using a minimum 4 mm2 copper conductor to maintain the 1500 V AC isolation barrier performance. Wiring Limitations: Use shielded twisted pair (STP) cabling for routing paths exceeding 30 meters or when routed through high electromagnetic noise zones. Keep 24 V DC signal lines physically separated from high-voltage AC motor drives or power infrastructure lines by a minimum distance of 100 mm. Fuse Installation: Install an individual 2 A fast-blow external fuse on the 24 V DC supply path powering the actuator circuits to prevent cascading overcurrent faults during direct terminal short circuits.
$200.00 $100.00
-
Schneider Electric BMXXBP0600 Schneider Electric Modicon M340 | Rack
Schneider Electric BMXXBP0600 Modicon M340 Rack The Schneider Electric BMXXBP0600, also cataloged as the BMXXBP0600 Rack, operates as a dedicated hardware component for physical module housing and backplane connectivity within Modicon M340 automation platform platforms. Hardware Specifications Parameter Specification Model Brand Schneider Electric Origin Schneider Electric Factory Standard Weight 1.74 lb (0.79 kg) Dimensions Standard 6-slot Modicon M340 Form Factor Operating Temp 32...140 degF (0...60 degC) Power Consumption 1.5 W Number of Slots 6 bus X slots Product Compatibility BMXCPS power supply, BMXP34 processor, I/O module, Specific application module Electrical Connection 1 connector (XBE) expansion module Fixing Mode By 4 M6 screws plate, By clips 35 mm symmetrical DIN rail, By 4 screws 0.17...0.25 in (4.32...6.35 mm) panel IP Degree of Protection IP20 Relative Humidity 10...95 % without condensation Protective Treatment TC Sustainability Status Green Premium product, RoHS compliant (since 0612), SVHC free Backplane Bus Communication and Deterministic Scaling The backplane architecture leverages the integrated X bus communication channel to provide deterministic data execution across the 6 available slots. This configuration enables precise I/O density scaling and sustains stable bus communication velocity without requiring external software licenses. The physical layer maintains high-speed data cycling between the BMXP34 processor and standard I/O or specific application modules, ensuring synchronized signal processing across the local network backplane. Frequently Asked Questions Q: Can modules be hot-swapped within the BMXXBP0600 rack during live operation? A: No. The Modicon M340 backplane architecture requires the system power supply (BMXCPS) to be completely de-energized before inserting or removing any processor, power supply, or I/O modules to avoid transient electrical damage to the X bus. Q: What is the function of the 1 connector (XBE) expansion interface? A: The integrated XBE connector interfaces directly with rack expansion modules and multi-rack cables, allowing the X bus signals to extend to additional physical racks within the same local control architecture. Field Installation Guidelines Grounding Protocol: Establish a direct, low-impedance connection from the rack grounding terminal to the central protective earth (PE) ground rail using a dedicated functional earth wire to minimize electromagnetic interference. Mounting Clearance: Maintain a minimum clearance of 80 mm above and below the rack assembly, and 20 mm on each side, to allow for unobstructed vertical convective airflow and passive heat dissipation. Mechanical Securing: When utilizing panel mounting, torque the four physical screws within the 4.32...6.35 mm range to prevent vibrational displacement of the backplane contacts.
$200.00 $100.00
You have seen 48 out of 276 products
