DescriptionThe Bently Nevada 330106-05-30-20-02-CN is a high-performance 3300 XL 8 mm reverse mount proximity probe. Designed for critical machinery protection and condition monitoring, this sensor utilizes the eddy current principle to provide precise, non-contact measurements of shaft vibration and position. The reverse mount configuration is specifically engineered for applications where the probe must be mounted through the machine casing to observe the target surface.Features
8 mm probe tip diameter for standard 3300 XL system compatibility.
Reverse mount design suitable for space-constrained installations.
M10 x 1 threading for secure mechanical mounting.
Equipped with a Miniature ClickLoc coaxial connector for reliable signal transmission.
Agency Approvals: CSA, ATEX, and IECEx for hazardous area operation.
Integrated 2.0-meter cable length.
Applications
Gas and steam turbine vibration monitoring.
Centrifugal and reciprocating compressor shaft position analysis.
Large pump sets and motor-generator sets.
Hydroelectric power generation unit thrust bearing wear monitoring.
Rolling mill bearing and paper mill cylinder support monitoring.
Technical Specifications
Model
330106-05-30-20-02-CN
Probe Type
3300 XL 8 mm Reverse Mount
Thread Size
M10 x 1
Cable Length
2.0 meters
Connector Type
Miniature ClickLoc
Output Resistance
50 Ohm
Agency Approvals
CSA, ATEX, IECEx
Installation Guidelines
Ensure the probe is installed in a location free from excessive mechanical stress.
Use appropriate mounting brackets to maintain the required air gap between the probe tip and the target surface.
Route coaxial cables away from high-voltage lines or sources of electromagnetic interference (EMI) to prevent signal noise.
Always power down the monitoring system before connecting or disconnecting the probe cable.
Ensure the connector is fully seated and the ClickLoc mechanism is engaged to maintain environmental integrity.
Verify that the probe tip is not in contact with the target surface during operation to avoid sensor damage.
FAQsWhat is the Bently Nevada 330106-05-30-20-02-CN?It is a 3300 XL 8 mm reverse mount proximity probe used for monitoring vibration and position in rotating machinery.What is a 330106-05-30-20-02-CN Reverse Mount probe?It is designed for mounting on the surface of a machine to measure the shaft’s vibration or position, often used when there is limited space behind the machine casing.How does the 330106-05-30-20-02-CN sensor work?It operates on the eddy current principle, using a Proximitor sensor to measure the gap between the probe tip and the observed conductive surface.What is the probe case material?The probe case is constructed from high-grade stainless steel (AISI 303/304) for durability in industrial environments.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Bently Nevada 330106-05-30-05-02-CN is a high-performance 3300 XL 8 mm reverse mount proximity probe designed for precise vibration and position monitoring in industrial rotating machinery. As part of the 3300 XL series, this probe is engineered to work seamlessly with the Bently Nevada Proximitor sensor system, providing reliable gap, amplitude, and position data for critical assets such as turbines, compressors, and pumps.Features
Reverse mount configuration for installation in space-constrained environments.
M10 x 1 thread design for secure mounting.
Fully interchangeable with 3300 XL 8 mm and 5 mm system components.
Equipped with a miniature ClickLoc coaxial connector for reliable signal transmission.
Includes hazardous area agency approvals (CN/NEPSI).
Applications
Oil and Gas: Monitoring pumps, compressors, and turbines in refineries and extraction facilities.
Power Generation: Integrated into 3500 series protection systems for large-scale turbine monitoring.
Petrochemical: Precision monitoring of high-speed rotating equipment.
Heavy Manufacturing: Used in rolling mills and smelters to monitor shaft vibration and position.
Technical Specifications
Model
330106-05-30-05-02-CN
Probe Type
3300 XL 8 mm Reverse Mount
Thread Size
M10 x 1
Total Length
0.5 meter (1.6 feet)
Connector Type
Miniature ClickLoc coaxial
Agency Approvals
CN (NEPSI)
Output Resistance
50 Ohm
Cable Capacitance
69.9 pF/m (21.3 pF/ft) typical
Weight
0.05 kg
Installation Guidelines
Ensure the probe is installed in a location free from excessive mechanical stress on the cable.
Use caution when handling the probe tip to prevent damage to the sensing element.
Ensure the connector is clean and free of debris before mating with the extension cable.
Maintain the minimum permissible cable bend radius to avoid signal degradation or cable damage.
Always power down the associated Proximitor sensor before connecting or disconnecting the probe.
Ensure proper grounding of the monitoring system to prevent EMI interference.
FAQWhat is the primary function of this probe?This probe measures the distance between the probe tip and the observed target (e.g., a machine shaft), providing essential data for vibration and position analysis in the 3300 XL monitoring system.What does the CN suffix indicate?The CN suffix signifies that this specific unit is certified for use in hazardous areas according to Chinese (NEPSI) standards.Is this probe compatible with older 3300 systems?Yes, 3300 XL 8 mm components are electrically and physically interchangeable with non-XL 3300 5 mm and 8 mm components, provided the mounting requirements are met.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Bently Nevada 330180-X1-CN is a high-performance 3300 XL Proximitor Sensor designed for use in industrial vibration monitoring systems. This sensor is a critical component of the Bently Nevada proximity transducer system, providing accurate, non-contact measurement of shaft position and vibration in rotating machinery. It is engineered to deliver precise signal conditioning for eddy current probes, ensuring reliable data acquisition for machinery protection and condition monitoring applications.Features
Standard measurement range: 0 to 500 mils.
High sensitivity: 200 mV/mil for precise signal output.
Extended range options: Capable of up to 1,000 mils.
Linearity: +/- 1% of full scale.
Robust design for harsh industrial environments with a wide operating temperature range.
Technical Specifications
Model
330180-X1-CN (MOD: 145004-141)
Sensitivity
200 mV/mil
Linearity
+/- 1% of full scale
Operating Voltage
-18 V to -24 V DC
Signal Output Range
-2 V to -18 V DC
Operating Temperature
-52 degC to +100 degC
Storage Temperature
-52 degC to +105 degC
Installation Guidelines
Ensure the Proximitor sensor is mounted in a protected, dry location, ideally within a weatherproof housing or control cabinet.
Use high-quality, shielded coaxial cabling to connect the sensor to the probe and the monitoring system to minimize EMI/RFI interference.
Verify that the power supply is stable and within the specified -18 V to -24 V DC range before connecting.
Maintain proper grounding practices to prevent ground loops, which can affect the accuracy of the proximity measurement.
Always power down the monitoring system before installing or removing the sensor module to prevent electrical damage.
FAQWhat is the primary function of the 330180-X1-CN?This module acts as a signal conditioner for eddy current probes, converting the probe's signal into a proportional voltage output used by Bently Nevada monitoring systems to track shaft vibration and position.Can this sensor be used in extreme temperatures?Yes, the unit is rated for operation between -52 degC and +100 degC, making it suitable for most industrial rotating machinery environments.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Bently Nevada 330103-00-12-10-02-CN is a high-performance 3300 XL 8 mm proximity probe designed for critical machinery protection. As part of the industry-standard 3300 XL transducer system, this probe provides precise, non-contact measurement of shaft displacement, vibration, and position. The 330103 model is engineered for reliability in demanding industrial environments, ensuring compatibility with the 3300 XL Proximitor sensor series without the need for individual bench calibration.Features
Eddy Current Technology: Provides accurate, non-contact measurement of radial vibration, axial thrust, and speed.
System Interchangeability: Fully compatible with 3300 XL series components, allowing for seamless replacement of probes, extension cables, and sensors.
Robust Construction: Features an M10 x 1 thread configuration with a 120 mm case length, designed for durable mounting in industrial housings.
ClickLoc Connector: Equipped with a miniature coaxial ClickLoc connector for secure, reliable signal transmission.
Regional Compliance: This specific -CN model includes NEPSI certification for use in China.
Applications
Steam and Gas Turbines: Monitoring radial vibration and axial thrust to ensure safe operation.
Centrifugal and Axial Compressors: Preventing shaft-to-bearing contact through precise gap measurement.
Industrial Pumps and Fans: Tracking equipment health and detecting early signs of mechanical wear.
Generators and Motors: Providing stable, continuous monitoring for large rotating electrical assets.
Gearboxes: Detecting misalignment and bearing degradation via shaft vibration analysis.
Technical Specifications
Model Number
330103-00-12-10-02-CN
Probe Diameter
8 mm
Thread Configuration
M10 x 1
Case Length
120 mm
Unthreaded Length
0 mm
Cable Length
1.0 meter (3.3 feet)
Connector Type
Miniature coaxial ClickLoc
Armor
None
Agency Approval
NEPSI (China)
Installation Guidelines
Handling: Proximity probes are precision instruments. Handle with care to avoid damaging the probe tip or the coaxial cable.
Mounting: Ensure the probe is installed in a rigid, vibration-free bracket to prevent false readings. Use the provided lock nuts to secure the probe at the required gap distance.
Wiring: Route coaxial cables away from high-voltage power lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
System Integration: This probe must be paired with a compatible 3300 XL Proximitor sensor. Ensure all connections are clean and tightened to the manufacturer's specified torque.
Power Down: Always disconnect power to the monitoring system before installing or removing probe components to prevent electrical damage.
FAQWhat is the difference between the -CN and -05 models?The 330103-00-12-10-02-CN and 330103-00-12-10-02-05 are physically and electrically identical. The primary difference is the regional safety certification: the -CN model is NEPSI-certified for use in China, while the -05 model carries global approvals such as CSA, ATEX, and IECEx.Does this probe include the Proximitor sensor?No, the 330103 part number refers to the probe and integrated cable only. A compatible 3300 XL Proximitor sensor is required to complete the transducer system.What is the measurement range of this probe?The 3300 XL 8 mm system typically provides a linear measurement range of 0 to 80 mils (0 to 2.0 mm), suitable for most standard vibration and position monitoring applications.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Bently Nevada 330101-00-28-20-02-CN is an 8 mm proximity probe from the 3300 XL series. Designed for use within the 3300 XL Proximity Transducer System, this probe provides high-accuracy, non-contact measurement of shaft vibration and position in rotating machinery. It is fully compliant with API 670 standards for mechanical configuration, linear range, and temperature stability, ensuring reliable performance in demanding industrial environments.Features
8 mm probe diameter for standard eddy current sensing applications.
Miniature coaxial ClickLoc connector for secure, reliable signal transmission.
Full interchangeability with other 3300 XL system components, eliminating the need for individual component bench calibration.
Designed for high immunity to radio frequency interference (RFI) and electromagnetic interference (EMI).
Hazardous area approvals including CSA, ATEX, and IECEx.
Applications
Gas & Steam Turbines: Monitoring radial vibration and axial thrust to prevent rotor-stator contact.
Centrifugal & Axial Compressors: Ensuring precise shaft stability for process gas and refrigeration systems.
Large Industrial Pumps: Monitoring boiler feed pumps and high-pressure fluid systems.
Electric Motors & Generators: Supporting large sleeve-bearing units in power generation.
Gearboxes: Monitoring shaft eccentricity and misalignment in high-speed gear assemblies.
Technical Specifications
Model Number
330101-00-28-20-02-CN
Probe Diameter
8 mm
Thread Size
3/8-24 UNF
Unthreaded Length
0.0 in
Case Length
2.8 in
Cable Length
2.0 meters (6.6 feet)
Connector Type
Miniature coaxial ClickLoc
Agency Approvals
CSA, ATEX, IECEx
Operating Temperature
-51 degC to +177 degC
Installation Guidelines
Mounting: Thread the probe into the mounting bracket or machine housing until the tip lightly touches the target surface.
Gapping: Retract the probe to the required gap. A standard radial vibration gap is approximately 1.27 mm (50 mils), typically corresponding to a -9 Vdc output.
Locking: Once the gap is set, tighten the lock nut to a recommended torque of 68 N·m (50 ft·lb). Do not exceed 163 N·m (120 ft·lb).
Handling: Ensure the coaxial cable is routed away from high-voltage lines to minimize noise interference. Handle the probe tip with care to avoid damage to the sensing surface.
FAQWhat are the main applications for this probe?This probe is primarily used for vibration and position monitoring on fluid-film bearing machines such as turbines, pumps, and compressors to facilitate fault diagnosis and condition monitoring.How does the 3300 XL system handle electrical interference?The system is engineered with high immunity to RFI and EMI, allowing it to be installed in non-metallic housings without the requirement for additional specialized shielding.Is this probe compatible with older 3300 series components?Yes, each 3300 XL transducer system component is backward compatible and interchangeable with other non-XL 3300 series 5 mm and 8 mm transducer system components.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Bently Nevada 330103-00-04-10-02-CN is a high-performance 3300 XL 8 mm proximity probe designed for precise vibration and position monitoring in rotating machinery. As a core component of the Bently Nevada 3300 XL transducer system, this probe provides accurate, non-contact measurement of shaft displacement, position, and speed in industrial environments.Features
Standard 8 mm probe tip diameter for reliable sensing.
M10 x 1 thread configuration for secure mounting.
Equipped with a miniature coaxial ClickLoc connector for robust signal integrity.
Standard cable construction without armor.
Designed for hazardous area compliance with CSA, ATEX, and IECEx certifications.
Technical Specifications
Model Number
330103-00-04-10-02-CN
Probe Diameter
8 mm
Thread Size
M10 x 1
Unthreaded Length
0 mm
Case Length
40 mm
Cable Length
1.0 meter (3.3 feet)
Connector Type
Miniature coaxial ClickLoc
Approvals
CSA, ATEX, IECEx
Installation Guidelines
Ensure the probe is installed in a rigid, vibration-free mounting bracket to prevent false readings.
Maintain proper gap distance as specified by the machine monitoring system configuration.
Handle the probe tip with care; avoid physical impact or scratching of the sensing surface.
Route coaxial cables away from high-voltage power lines and sources of electromagnetic interference (EMI) to ensure signal accuracy.
Ensure that all connections are fully seated and the ClickLoc connector is properly secured.
Verify that the installation environment complies with the specific hazardous area ratings (CSA, ATEX, IECEx) indicated for this unit.
FAQWhat is the primary function of the 330103-00-04-10-02-CN probe?This probe is used to measure static and dynamic distances between the probe tip and the observed conductive surface, typically a machine shaft, to monitor vibration and axial position.Is this probe suitable for hazardous areas?Yes, this specific model (CN suffix) is manufactured with CSA, ATEX, and IECEx approvals, making it suitable for use in designated hazardous locations.Can this probe be used with other Bently Nevada systems?The 3300 XL 8 mm probe is designed to be compatible with Bently Nevada 3300 XL proximity transducer systems. Always verify system compatibility before installation.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Bently Nevada 330101 3300 XL 8 mm Proximity Probe is a critical component of the 3300 XL Proximity Transducer System. Designed for non-contact vibration and position measurement in industrial rotating machinery, this probe provides highly accurate gap measurements between the probe tip and the observed target. The 3300 XL system is engineered to meet the requirements of API 670 standards for machinery protection.Features
8 mm probe tip diameter for high-resolution sensing.
3/8-24 UNF thread configuration for standard mounting.
Miniature coaxial ClickLoc connector for secure, reliable signal transmission.
Standard cable construction without protective armor.
Designed for compatibility with 3300 XL extension cables and proximity sensors.
Hazardous area approvals including CSA, ATEX, and IECEx.
Technical Specifications
Model
330101-00-00-10-02-05 MOD147773-00-12
Probe Diameter
8 mm
Thread Size
3/8-24 UNF
Cable Length
1.0 meter (3.3 feet)
Connector
Miniature coaxial ClickLoc
Armor
None
Agency Approvals
CSA, ATEX, IECEx
Installation Guidelines
Ensure the probe is mounted in a rigid bracket to prevent mechanical resonance.
Handle the probe tip with care; damage to the tip surface can affect measurement accuracy.
When installing, ensure the probe is not over-tightened to avoid stripping the threads.
Route the coaxial cable away from high-voltage power lines or sources of electromagnetic interference (EMI) to maintain signal integrity.
Verify that the probe gap is set according to the specific machinery monitoring configuration requirements.
Ensure the ClickLoc connector is fully seated and locked to prevent intermittent signal loss.
FAQWhat is the purpose of the 3300 XL 8 mm probe?This probe is used to measure radial vibration, axial position, and speed on rotating shafts in industrial environments, providing essential data for machinery protection and condition monitoring.Is this probe compatible with older 3300 series systems?The 3300 XL system is generally backward compatible with 3300 series components, but it is recommended to verify the system compatibility and calibration requirements for your specific installation.Does this probe require special handling?Yes, the probe tip is sensitive. Avoid physical impact or exposure to harsh chemicals that could degrade the probe material. Always ensure the system is powered down before disconnecting or connecting the probe cable.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Description
The Foxboro AD916AE is a high-performance analog input extension cable engineered for the Foxboro I/A Series distributed control system. This component is designed to facilitate reliable signal transmission between Fieldbus Modules (FBM) and termination assemblies (TA) within complex industrial control environments. By ensuring high-fidelity data transfer, the AD916AE helps maintain signal integrity for sensitive process variables, minimizing electromagnetic interference (EMI) and preventing data loss in critical applications.
Features
High-Fidelity Signal Transmission: Multi-core, shielded twisted pair (STP) construction optimized for low-level analog signal integrity.
Robust Construction: Features a flame-retardant outer jacket designed to withstand industrial chemical exposure and thermal stress.
Reliable Connectivity: High-density connectors equipped with gold-plated contacts to prevent oxidation and ensure long-term electrical conductivity.
System Compatibility: Supports redundant signal paths when utilized with compatible redundant FBM architectures.
EMC Compliance: Calibrated to meet Foxboro stringent electromagnetic compatibility standards.
Applications
The AD916AE is suitable for use in demanding industrial sectors, including:
Petrochemical refineries
Offshore oil and gas platforms
Heavy mining operations
Large-scale distributed control system (DCS) installations
Technical Specifications
Model
AD916AE
Brand
Foxboro (Schneider Electric)
Cable Type
Analog Input Extension Cable
Signal Support
4-20 mA, 0-5 VDC, 0-10 VDC
Shielding
Overall foil and braided shield (100% coverage)
Operating Temperature
-20 to +70 deg C
Storage Temperature
-40 to +85 deg C
Jacket Material
PVC
Installation Guidelines
Handling: Ensure the cable is not subjected to excessive tension or sharp bends during installation to maintain the integrity of the internal shielding.
EMI Mitigation: Route signal cables away from high-voltage power lines and high-EMI sources to prevent signal noise.
Grounding: Ensure proper termination of the cable shield at the designated grounding points on the termination assembly to maintain effective EMI protection.
Environment: Verify that the installation area remains within the specified temperature range of -20 to +70 deg C.
Power Down: Always ensure the associated I/O modules and power supplies are de-energized before connecting or disconnecting the cable from the FBM or TA.
FAQ
Q: Is this cable compatible with all Foxboro I/A Series FBMs?A: The AD916AE is designed for specific I/A Series applications. Please verify your FBM and termination assembly part numbers to ensure compatibility with this specific cable interface.
Q: Can this cable be used in outdoor environments?A: The cable features a flame-retardant jacket suitable for industrial environments; however, it should be installed within appropriate conduit or cable trays to protect it from direct environmental hazards and mechanical damage.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-22-10-02-05 3300 XL 8 mm Proximity Probe
Configured for non-contact shaft displacement measurement in the Bently Nevada 3300 XL Proximity Transducer System, the Bently Nevada 330104-00-22-10-02-05 (330104 3300 XL 8 mm Proximity Probe) provides direct eddy-current sensing for vibration and axial position monitoring.
Hardware Specifications
Parameter
Specification
Model
330104-00-22-10-02-05
Brand
Bently Nevada
Product Type
3300 XL 8 mm Eddy Current Proximity Probe
Origin
USA
Weight
Approx. 0.16 kg
Dimensions
Case length: 220 mm; total length: 1.0 m
Operating Temp
-52 deg C to +177 deg C
Power Consumption
Supplied by compatible 3300 XL Proximitor Sensor system
Probe Diameter
8 mm
Thread Type
M10 x 1 metric thread
Armor Type
Stainless steel flexible armor
Cable Type
75 ohm triaxial FEP insulated probe cable
Connector Type
Miniature coaxial ClickLoc connector
Tip Material
Polyphenylene sulfide (PPS)
Case Material
AISI 303/304 stainless steel
Linear Range
2.0 mm (80 mils), operating range from 0.25 mm to 2.25 mm
Scale Factor
7.87 V/mm (200 mV/mil) nominal
Target Material
AISI 4140 steel
Pressure Seal
Viton O-ring between probe tip and case
Eddy-Current Measurement and Rotor Dynamics Characteristics
The 330104-00-22-10-02-05 uses an eddy-current sensing principle to convert shaft displacement into electrical signals. The probe maintains a nominal scale factor of 7.87 V/mm and operates with compatible 3300 XL Proximitor Sensors for vibration and position measurements.
The probe design supports rotor dynamics analysis by providing proportional displacement feedback from rotating shafts. Therefore, the system can evaluate radial vibration, axial position, and shaft movement behavior through continuous gap measurement.
The probe output depends on the physical gap between the probe tip and the conductive target. During installation, technicians validate the probe gap voltage to confirm the measurement position, with typical Bently Nevada systems using -10 VDC as the target reference condition for proper operating gap verification.
The armored construction reduces mechanical damage risk in industrial installations, while the ClickLoc connector provides consistent electrical connection between the probe cable and monitoring electronics.
Frequently Asked Questions
Q: What measurement signals does the Bently Nevada 330104-00-22-10-02-05 provide?A: The probe provides non-contact displacement signals used for shaft vibration, radial position, axial position, and rotor movement monitoring through a compatible 3300 XL Proximitor Sensor.
Q: Does this probe require special calibration before operation?A: No. The probe uses the standard 3300 XL 8 mm probe scaling and operates with compatible Bently Nevada Proximitor Sensors without custom bench calibration when installed with the specified target material.
Q: How should the probe gap be verified during installation?A: Technicians verify the operating gap through the Proximitor Sensor output voltage. Bently Nevada installations commonly use -10 VDC as the reference target for correct probe gap positioning.
Field Installation Guidelines
Install the probe with the M10 x 1 threaded section fully engaged according to the mechanical assembly requirements.
Maintain proper probe tip alignment with the rotating shaft surface to prevent measurement errors caused by angular offset.
Route the armored cable away from high-current power conductors to reduce electrical interference.
Connect the cable shield and grounding path according to the Bently Nevada monitoring system installation requirements.
Verify the probe gap voltage after mechanical installation before commissioning the vibration monitoring channel.
Confirm that the shaft material matches the calibration target requirements, typically AISI 4140 steel or an equivalent conductive target.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-22-10-01-05 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-22-10-01-05, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated eddy-current measurement component for shaft displacement and vibration monitoring within Bently Nevada TSI monitoring systems.
Hardware Specifications
Parameter
Specification
Model
330104-00-22-10-01-05
Brand
Bently Nevada
Product Series
3300 XL 8 mm Proximity Probe
Origin
USA
Dimensions
Probe tip diameter: 8 mm; case length: 220 mm; total length: 1.0 meter
Operating Temp
Probe and cable: -51 deg C to +177 deg C
Power Consumption
Powered by Proximitor sensor system; input voltage: -17.5 VDC to -26 VDC
Measurement Principle
Eddy-current non-contact displacement measurement
Thread Type
M10 x 1 metric thread
Unthreaded Length
0 mm
Cable Protection
Flexible AISI 302 stainless steel armored cable
Connector Type
Miniature coaxial ClickLoc connector with connector protector
Probe Tip Material
Polyphenylene sulfide (PPS)
Probe Case Material
AISI 304 stainless steel
Linear Range
2.0 mm (80 mils)
Scale Factor
7.87 V/mm (200 mV/mil), +/-5% typical
Field Wiring Distance
Up to 305 meters between Proximitor sensor and monitoring system using recommended triad shielded cable
Hazardous Area Approval
CSA, ATEX, IECEx
Eddy-Current Probe Scaling and Rotor Dynamics Monitoring
The 330104-00-22-10-01-05 uses eddy-current sensing technology to convert shaft displacement into proportional electrical signals. The probe provides a scale factor of 7.87 V/mm for dynamic vibration and static position measurements.
Furthermore, the system requires gap voltage validation during commissioning to confirm the probe operating point. Bently Nevada proximity systems typically use approximately -10 VDC gap voltage targets to verify correct probe-to-shaft positioning.
The probe supports rotor dynamics analysis by measuring radial vibration, axial shaft position, speed references, and Keyphasor related signals. Therefore, engineers can evaluate shaft movement behavior through compatible TSI monitoring modules.
The armored cable construction reduces mechanical damage risks in industrial installations. Additionally, the miniature coaxial ClickLoc connector maintains signal continuity between the probe and the associated Proximitor sensor.
Frequently Asked Questions
Q: What measurement principle does the 330104-00-22-10-01-05 use?A: The probe uses eddy-current technology to measure shaft displacement without physical contact between the probe tip and rotating shaft surface.
Q: What is the required operating voltage range for this proximity probe system?A: The connected Proximitor sensor system operates with an input voltage range of -17.5 VDC to -26 VDC.
Q: What installation factors affect measurement accuracy?A: Proper probe gap adjustment, shielded cable routing, correct grounding practice, and avoidance of electromagnetic interference affect signal accuracy.
Field Installation Guidelines
Install the probe with the specified M10 x 1 metric thread engagement and verify mechanical alignment before operation.
Maintain correct probe gap adjustment according to the monitoring system commissioning procedure.
Connect the cable shield according to the TSI system grounding requirements to reduce electrical interference.
Avoid routing proximity probe cables parallel to high-current power conductors.
Inspect the armored cable and ClickLoc connector before installation to confirm mechanical integrity.
Verify the gap voltage output after installation to confirm proper probe positioning and signal operation.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-20-05-02-00 3300 XL 8 mm Proximity Probe
Configured for shaft displacement measurement in the Bently Nevada 3300 XL Proximity Transducer System, the Bently Nevada 330104-00-20-05-02-00 (330104 3300 XL 8 mm Proximity Probe) provides direct eddy-current signal conversion for vibration, position, and Keyphasor monitoring circuits.
Hardware Specifications
Parameter
Specification
Model
330104-00-20-05-02-00
Brand
Bently Nevada
Product Type
Eddy Current Proximity Sensors
Series
3300 XL 8 mm Proximity Probe
Origin
USA
Dimensions
200 mm case length, 0.5 meter probe cable length
Operating Temp
-35 deg C to +177 deg C
Power Consumption
12 mA max at -17.5 VDC to -26 VDC supply
Thread Type
M10 x 1 metric thread
Probe Construction
Armored cable configuration with AISI 304 stainless steel case
Cable Armor
Flexible AISI 302 stainless steel with FEP outer jacket
Connector Type
Miniature coaxial ClickLoc connector
Probe Tip Material
Polyphenylene sulfide (PPS)
Measurement Principle
Eddy current non-contact displacement measurement
System Linear Range
2.0 mm (80 mils)
Scale Factor
7.87 V/mm (200 mV/mil), +/-6.5 percent typical
Frequency Response
0 Hz to 10 kHz (+0, -3 dB)
Output Resistance
50 ohm from Proximitor Sensor
Target Material
AISI 4140 steel calibration target
API Compliance
API 670 compliant for 5 meter and 9 meter systems
Eddy Current Probe Scaling and Rotor Dynamics Monitoring
The 3300 XL 8 mm proximity probe uses an eddy-current measurement circuit to convert shaft motion into proportional electrical output. Therefore, the probe provides linear displacement feedback for rotor vibration analysis and axial position monitoring.
The 7.87 V/mm scale factor supports Proximitor Sensor signal conditioning, while the DC response allows static shaft position measurement and dynamic vibration detection within the same measurement loop.
Additionally, the system supports gap voltage validation procedures. Field technicians normally verify probe operating condition through gap voltage measurements, with -10 VDC commonly used as the nominal target for Bently Nevada proximity systems.
The probe design reduces measurement errors caused by mechanical movement and maintains signal integrity through armored cable protection. As a result, the device supports rotor dynamics evaluation in rotating equipment monitoring applications.
Frequently Asked Questions
Q: What measurement function does the 330104-00-20-05-02-00 provide?A: The probe measures shaft displacement through an eddy-current sensing principle and outputs proportional vibration and position signals through the compatible Proximitor Sensor.
Q: Does this model support armored cable installation?A: Yes. The 330104-00-20-05-02-00 includes an armored cable construction using flexible stainless steel armor with an FEP protective jacket.
Q: What power supply does the connected proximity system require?A: The connected Proximitor Sensor requires a -17.5 VDC to -26 VDC supply and operates with a maximum current consumption of 12 mA.
Field Installation Guidelines
Install the probe with the specified M10 x 1 metric thread engagement and maintain correct mechanical alignment with the monitored shaft surface.
Verify the probe tip clearance before equipment operation to ensure the measurement range remains within the calibrated displacement area.
Use shielded signal routing practices and separate probe cables from high-current power wiring to reduce electrical interference.
Connect cable shielding according to the monitoring system grounding design and avoid multiple unintended grounding paths.
Confirm gap voltage after installation and validate the signal output before commissioning the machinery monitoring loop.
Protect the ClickLoc connector area from mechanical stress, contamination, and excessive bending during cable routing.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-18-10-02-05 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-18-10-02-05, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for eddy-current displacement measurement and vibration monitoring within the 3300 XL Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-18-10-02-05
Brand
Bently Nevada
Product Type
Eddy Current Proximity Sensors
Series
3300 XL 8 mm Proximity Probe
Origin
USA
Weight
0.16 kg
Dimensions
Probe case length 180 mm; overall length configuration 1.0 m
Probe Tip Diameter
8 mm
Thread Type
M10 x 1 metric thread
Cable Type
Standard coaxial cable with flexible protective armor
Connector Type
Miniature coaxial ClickLoc connector
Probe Tip Material
Polyphenylene sulfide (PPS)
Probe Case Material
AISI 303 or 304 stainless steel
Linear Measurement Range
2.0 mm
Linearity Range
0.25 mm to 2.25 mm
System Output Scale Factor
7.87 V/mm (200 mV/mil)
Operating Temp
Probe and cable: -52 deg C to +177 deg C; connector: -52 deg C to +105 deg C
Power Consumption
Supplied by Proximitor Sensor, -17.5 VDC to -26 VDC operating supply
Hazardous Area Approval
CSA, ATEX, IECEx Class I Div 1 / Zone 0 and Zone 1 applications
Eddy-Current Measurement and Rotor Dynamics Characteristics
The 330104-00-18-10-02-05 uses an eddy-current sensing principle to convert shaft displacement into an electrical output signal. The probe operates with a defined scaling factor of 7.87 V/mm, allowing the connected Proximitor Sensor to process shaft position and vibration signals.
Furthermore, the probe supports gap voltage validation through standard Bently Nevada monitoring practices. Field technicians typically verify probe installation by checking gap voltage targets near -10 VDC to confirm correct probe-to-shaft spacing.
The 3300 XL 8 mm design supports rotor dynamics analysis by providing continuous shaft movement data. Therefore, the system can monitor radial vibration, axial position, and mechanical displacement changes in rotating equipment.
The probe construction also reduces signal interference through controlled cable design and shielded coaxial transmission. This configuration maintains measurement stability when installed near other vibration monitoring channels.
Frequently Asked Questions
Q: What measurement principle does the 330104-00-18-10-02-05 use?A: The probe uses eddy-current technology to measure the distance between the probe tip and conductive shaft surface. The Proximitor Sensor converts the electrical response into displacement data.
Q: What is the purpose of the ClickLoc coaxial connector on this probe?A: The miniature coaxial ClickLoc connector provides a mechanical connection between the probe cable and monitoring electronics while maintaining the required signal transmission characteristics.
Q: Can the probe operate in hazardous areas?A: Yes. This configuration includes CSA, ATEX, and IECEx approvals for specified hazardous area installations. The final installation must follow the applicable certification requirements.
Field Installation Guidelines
Install the probe with the specified M10 x 1 mounting thread and maintain correct probe-to-shaft clearance before system calibration.
Connect the coaxial cable using the ClickLoc connector and verify that the connector remains mechanically secured during equipment operation.
Route the probe cable away from high-current power conductors and strong electromagnetic interference sources. Maintain proper cable separation to reduce unwanted electrical noise.
Connect cable shielding according to the monitoring system grounding requirements. Avoid creating additional ground loops between the probe system and external equipment.
After mechanical installation, verify the Proximitor Sensor output and confirm gap voltage values before placing the machinery into service.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-17-05-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-17-05-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within the Bently Nevada 3300 XL Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-17-05-02-00
Brand
Bently Nevada
Product Type
Eddy Current Proximity Sensors
Series
3300 XL 8 mm Proximity Probe
Origin
USA
Weight
0.16 kg
Dimensions
170 mm case length, 8 mm probe diameter, 0.5 m cable length
Operating Temp
-52 deg C to +177 deg C
Power Consumption
Passive probe device; powered by compatible 3300 XL Proximitor Sensor
Measurement Principle
Eddy current non-contact displacement measurement
Linear Range
2.0 mm (80 mils)
Scale Factor
7.87 V/mm (200 mV/mil) with matching 3300 XL Proximitor Sensor
Target Material
Calibrated for AISI 4140 steel
Thread Type
M10 x 1 metric thread
Probe Diameter
8 mm
Case Length
170 mm
Cable Length
0.5 m
Connector Type
Miniature coaxial ClickLoc connector
Probe Tip Material
Polyphenylene Sulfide (PPS) molded TipLoc probe tip
Agency Approval
Standard version without agency approval
Eddy Current Measurement and Rotor Dynamics Features
The 330104-00-17-05-02-00 uses an eddy-current sensing principle to convert shaft position changes into proportional electrical signals. The 3300 XL system applies a defined scaling relationship between probe displacement and output voltage, allowing the Proximitor Sensor to process radial vibration and axial position signals.
The probe operates with a calibrated gap voltage range controlled by the connected Proximitor Sensor. During installation, technicians validate the electrical gap condition and typically verify the -10 VDC target reference used in Bently Nevada proximity measurement systems.
Furthermore, the probe supports rotor dynamics analysis by providing displacement signals required for shaft vibration monitoring, phase reference measurements, and machinery protection logic.
Frequently Asked Questions
Q: Does the 330104-00-17-05-02-00 require field calibration after replacement?A: No. The 3300 XL system supports interchangeable probe, extension cable, and Proximitor Sensor combinations without bench calibration when technicians use matched system components.
Q: What type of signal does this proximity probe generate?A: The probe provides an eddy-current measurement signal that the connected Proximitor Sensor converts into a proportional voltage output for vibration and position monitoring.
Q: Can this probe measure shaft vibration and axial position simultaneously?A: The probe measures shaft displacement. System configuration determines whether the signal is applied for radial vibration, axial position, speed sensing, or Keyphasor phase measurement.
Field Installation Guidelines
Install the probe using the M10 x 1 metric thread connection and maintain correct mechanical alignment with the target shaft surface.
Keep the probe tip surface free from contamination because oil deposits or foreign material can affect eddy-current measurement accuracy.
Route the coaxial cable away from high-current power conductors to reduce electrical interference.
Connect the ClickLoc connector securely and maintain proper shielding practices according to the 3300 XL installation requirements.
Verify the probe gap voltage through the connected Proximitor Sensor before placing the machinery protection channel into service.
Confirm the target material condition because calibration characteristics depend on the specified conductive shaft material.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-15-10-02-05 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-15-10-02-05, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated eddy-current measurement component for shaft position and vibration signal acquisition within the 3300 XL Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-15-10-02-05
Brand
Bently Nevada
Product Type
3300 XL 8 mm Eddy Current Proximity Probe
Origin
USA
Dimensions
Overall case length: 150 mm; Total length: 1.0 m
Operating Temp
-51 deg C to +177 deg C
Power Consumption
Passive probe element; powered through connected Proximitor sensor
Thread Type
M10 x 1 metric thread
Probe Diameter
8 mm
Measurement Technology
Eddy current non-contact displacement measurement
Target Material
AISI 4140 steel standard target
Linear Range
2 mm (80 mils) starting at approximately 0.25 mm (10 mils) gap
Average Scale Factor
7.87 V/mm (200 mV/mil) nominal
Frequency Response
0 to 10 kHz (+0, -3 dB)
Probe Tip Material
Polyphenylene sulfide (PPS)
Probe Case Material
AISI 304 stainless steel
Cable Type
75 ohm triaxial cable, FEP insulated
Connector Type
Miniature coaxial ClickLoc connector
Agency Approval
CSA, ATEX, IECEx multiple approvals
Eddy Current Scaling and Rotor Dynamics Monitoring
The 330104-00-15-10-02-05 applies eddy-current probe scaling to convert shaft displacement changes into proportional electrical output signals. The probe provides a nominal scale factor of 7.87 V/mm for connection with compatible Bently Nevada Proximitor sensors.
Furthermore, the probe supports rotor dynamics analysis by measuring radial vibration and shaft position changes without mechanical contact. The 3300 XL system evaluates gap voltage conditions, with typical installation validation referencing a -10 VDC target gap voltage from the Proximitor sensor output.
The probe structure uses TipLoc molding technology to secure the probe tip assembly. In addition, the ClickLoc connector uses gold-plated brass contacts to maintain electrical connection integrity under rotating machinery operating conditions.
Frequently Asked Questions
Q: What measurement signals can the 330104-00-15-10-02-05 detect?A: The probe detects non-contact shaft displacement signals, including dynamic vibration movement and static shaft position changes.
Q: Can the probe operate independently without a Proximitor sensor?A: No. The probe requires connection to a compatible Bently Nevada Proximitor sensor, which provides excitation and converts the eddy-current signal into monitoring outputs.
Q: What installation factor affects measurement accuracy?A: Probe gap setting, target material condition, cable routing, and proper electrical connection affect the accuracy of displacement measurements.
Field Installation Guidelines
Install the 330104-00-15-10-02-05 probe with the sensing tip aligned perpendicular to the rotating shaft surface. Verify that the target material matches the calibrated application requirement, such as AISI 4140 steel.
Route the triaxial cable away from high-current power conductors and electromagnetic interference sources. Maintain proper shielding practices by connecting the cable shield according to the applicable Bently Nevada system installation requirements.
Before commissioning, check the probe gap voltage through the connected Proximitor sensor. Confirm that the mechanical mounting provides stable clearance and prevents contact between the probe tip and rotating components.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-15-05-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-15-05-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for shaft displacement measurement within the Bently Nevada 3300 XL Eddy Current Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-15-05-02-00
Brand
Bently Nevada
Product Type
3300 XL 8 mm Proximity Probe
Origin
United States
Dimensions
150 mm overall case length, 0 mm unthreaded length
Operating Temp
-52 deg C to +177 deg C
Power Consumption
Passive eddy-current probe element, powered by compatible driver module
Thread Type
M10 x 1 metric thread
Probe Diameter
8 mm
Cable Length
0.5 m
Cable Type
Standard non-armored coaxial cable
Connector Type
Miniature coaxial ClickLoc connector
Linear Range
2.0 mm (80 mils)
Armor Configuration
Without armor
Measurement Principle
Eddy-current non-contact displacement sensing
Application Signals
Shaft radial vibration, axial position, speed, Keyphasor reference
Eddy-Current Probe Scaling and Rotor Dynamics
The Bently Nevada 330104 series applies eddy-current probe scaling to convert shaft surface displacement into proportional electrical signals through compatible proximity driver modules. The probe generates a magnetic field at the sensing tip, and the system evaluates impedance changes caused by shaft movement.
Furthermore, the probe supports rotor dynamics monitoring by providing displacement data required for vibration analysis, shaft orbit evaluation, and axial position verification. The system uses gap voltage validation with typical -10 VDC target values during field calibration to confirm correct probe positioning and measurement range.
The miniature coaxial ClickLoc connector maintains signal transmission integrity between the probe and extension system. In addition, the non-armored coaxial cable configuration requires controlled routing to minimize mechanical stress and external electrical interference.
Frequently Asked Questions
Q: What measurement principle does the 330104-00-15-05-02-00 use?A: The probe uses an eddy-current sensing principle to measure shaft displacement without physical contact with the rotating surface.
Q: Can this probe directly connect to a monitoring system input channel?A: No. The probe requires a compatible Bently Nevada proximity driver module to provide excitation power, signal conditioning, and output scaling.
Q: What installation factor affects measurement accuracy?A: Correct probe gap adjustment, target material compatibility, cable routing, and proper grounding practices affect signal stability and measurement accuracy.
Field Installation Guidelines
Install the probe with the M10 x 1 metric thread connection according to the mechanical mounting requirements of the machine housing.
Verify the probe gap voltage after installation and confirm the expected -10 VDC calibration target through the connected driver module.
Route the coaxial cable away from high-current power conductors, switching devices, and sources of electromagnetic interference.
Avoid sharp cable bends and mechanical loading near the miniature coaxial ClickLoc connector.
Connect cable shielding according to the monitoring system grounding requirements to reduce electrical noise coupling.
Confirm the shaft target surface condition and material compatibility before commissioning vibration or position measurements.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-14-10-02-05 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-14-10-02-05, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as an eddy-current measurement component for shaft displacement and vibration monitoring within Bently Nevada TSI monitoring systems.
Hardware Specifications
Parameter
Specification
Model
330104-00-14-10-02-05
Brand
Bently Nevada
Product Series
3300 XL 8 mm Proximity Probe
Product Type
Eddy Current Proximity Sensor
Origin
USA
Weight
0.16 kg
Dimensions
109 x 1.8 x 1.5 cm estimated shipping size
Operating Temp
Not specified in provided data
Power Consumption
Supplied through compatible Bently Nevada Proximitor sensor system
Thread Type
M10 x 1 metric thread
Probe Diameter
8 mm
Armor Protection
Included
Unthreaded Length
0 mm
Overall Case Length
140 mm
Total Length
1.0 meter (3.3 feet)
Cable Type
Miniature coaxial ClickLoc connector standard cable
Approvals
CSA, ATEX, IECEx approvals
Tariff Code
8537101190
Shipment Location
Xiamen, China
Eddy-Current Measurement and Rotor Dynamics
The 3300 XL 8 mm proximity probe uses eddy-current sensing technology to measure shaft displacement without mechanical contact. Therefore, the probe converts the variation between the probe tip and conductive target surface into an electrical signal for vibration and position analysis.
The probe operates with Bently Nevada Proximitor signal conditioners to maintain calibrated displacement measurement. Additionally, the system supports rotor dynamics evaluation through radial vibration, axial position, and shaft motion monitoring.
Gap voltage validation remains a standard commissioning procedure for Bently Nevada proximity systems. Engineers typically verify probe gap conditions against the expected -10 VDC target range to confirm correct mechanical positioning and electrical response.
The miniature coaxial ClickLoc connector cable design reduces installation complexity while maintaining signal transmission stability. Moreover, the armored construction provides additional mechanical protection for cable routing in industrial machinery environments.
Frequently Asked Questions
Q: What measurement principle does the 330104-00-14-10-02-05 probe use?A: The probe uses eddy-current sensing to measure the distance between the probe tip and the rotating shaft target without physical contact.
Q: Does this probe require a separate signal conditioner?A: Yes. The 330104 probe operates as part of the 3300 XL Proximity Transducer System and requires a compatible Bently Nevada Proximitor interface.
Q: What installation checks should be completed before operation?A: Technicians should verify probe mounting position, cable routing, connector engagement, and electrical gap voltage conditions before system operation.
Field Installation Guidelines
Install the probe using the specified M10 x 1 threaded mounting interface and maintain correct probe alignment with the monitored shaft surface.
Route the armored cable away from high-current power cables and strong electromagnetic interference sources. Use proper cable separation practices to reduce measurement noise.
Connect the miniature coaxial ClickLoc connector securely to the compatible monitoring electronics. Verify that the cable shield and grounding arrangement follow the system installation requirements.
Before commissioning, confirm the mechanical gap setting and validate the probe electrical output through the associated Bently Nevada monitoring channel.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-14-05-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-14-05-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for eddy-current displacement measurement within the 3300 XL Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-14-05-02-00
Brand
Bently Nevada
Product Type
3300 XL 8 mm Eddy Current Proximity Probe
Origin
USA
Dimensions
140 mm case length, 0.5 m cable length
Operating Temp
-52 deg C to +177 deg C
Power Consumption
Passive probe, powered by compatible 3300 XL Proximitor Sensor
Thread Size
M10 x 1 metric thread
Probe Tip Diameter
8 mm
Case Material
AISI 303 / 304 stainless steel
Tip Material
Polyphenylene Sulfide (PPS)
Cable Protection
Flexible AISI 302 stainless steel armor
Connector Type
Gold-plated miniature coaxial ClickLoc connector
Maximum Rated Torque
33.9 N m (300 in lbf)
Recommended Installation Torque
11.2 N m (100 in lbf)
Linear Measuring Range
2.0 mm (80 mils)
Incremental Scale Factor
7.87 V/mm (200 mV/mil) +/-5%
Output Voltage Range
Approx. -1 VDC to -17 VDC
Target Material
Magnetic steel, AISI 4140 calibration target
Probe Resistance
7.45 +/-0.50 ohm for 0.5 m cable length
Eddy-Current Scaling and Rotor Dynamics Monitoring
The 3300 XL 8 mm proximity probe generates displacement signals through eddy-current measurement between the probe tip and conductive shaft target. Therefore, the probe maintains a defined incremental scale factor of 7.87 V/mm for compatible Bently Nevada Proximitor Sensor configurations.
The measurement output represents shaft position changes and dynamic vibration movement. Furthermore, the probe supports rotor dynamics analysis by providing displacement data for radial vibration, axial position, and speed-related monitoring functions.
Gap voltage validation is performed through the Proximitor Sensor interface. In standard Bently Nevada installations, technicians verify probe operating conditions by checking the DC gap voltage, with approximately -10 VDC commonly used as a nominal center operating target.
The armored cable construction improves mechanical protection in machine casings. Additionally, the miniature coaxial ClickLoc connector maintains signal continuity while reducing connection-related measurement disturbances.
Frequently Asked Questions
Q: What measurement principle does the 330104-00-14-05-02-00 use?A: The probe uses eddy-current sensing technology to measure shaft displacement without physical contact between the probe tip and the rotating target.
Q: What is the function of the -10 VDC gap voltage reference?A: The -10 VDC value is commonly used as a probe operating position reference during installation checks and gap voltage validation.
Q: Can this probe connect directly to a PLC analog input channel?A: No. The probe requires a compatible Bently Nevada Proximitor Sensor to convert the eddy-current signal into a standard monitoring output.
Field Installation Guidelines
Install the probe with the M10 x 1 threaded body fully engaged into the machine mounting location according to the equipment drawing. Apply the recommended installation torque to prevent mechanical loosening while avoiding thread damage.
Route the armored cable away from high-current power conductors and strong electromagnetic interference sources. Maintain proper cable separation and avoid sharp bending that may affect signal stability.
Connect the ClickLoc coaxial connector securely to the compatible Proximitor Sensor. Verify cable shielding continuity and ensure the instrumentation grounding method follows the machine monitoring system installation requirements.
After mechanical installation, check the probe gap voltage through the associated monitoring electronics. Confirm that the operating voltage remains within the expected measurement range before placing the machine into service.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-13-05-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-13-05-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated eddy-current measurement component for shaft displacement and vibration monitoring within the 3300 XL Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-13-05-02-00
Brand
Bently Nevada
Product Series
3300 XL 8 mm Proximity Probe
Origin
USA
Dimensions
8 mm probe tip diameter; 130 mm case length; 0.5 m cable length
Operating Temp
-51 deg C to +177 deg C
Power Consumption
Supplied by compatible 3300 XL Proximitor Sensor
Measurement Type
Non-contact eddy-current displacement measurement
Target Material
AISI 4140 steel calibration target
Linear Measurement Range
2.0 mm (80 mils)
Scale Factor
7.87 V/mm (200 mV/mil) with 3300 XL Proximitor Sensor
Frequency Response
0 Hz to 10 kHz
Probe Thread
M10 x 1 metric thread
Unthreaded Length
0 mm
Connector Type
Miniature coaxial ClickLoc connector
Cable Type
Standard coaxial cable
Agency Approval
Standard version without hazardous area approval
Compliance
API 670 compliant
Eddy-Current Signal Scaling and Rotor Dynamics Monitoring
The 330104-00-13-05-02-00 probe uses eddy-current technology to convert shaft displacement into electrical signals. Therefore, the connected 3300 XL Proximitor Sensor can process gap distance variations for vibration and position analysis.
The probe system uses a defined scale factor of 7.87 V/mm, which allows the monitoring system to correlate voltage changes with mechanical shaft movement. In addition, proper gap voltage validation supports installation verification, with Bently Nevada systems typically using -10 VDC target gap settings for measurement calibration.
Furthermore, the probe supports rotor dynamics analysis by providing continuous shaft vibration and axial position data. The miniature coaxial ClickLoc connector design maintains signal integrity while reducing installation complexity in TSI monitoring applications.
Frequently Asked Questions
Q: What measurement signals does the 330104-00-13-05-02-00 provide?A: The probe provides non-contact displacement signals for radial shaft vibration, axial position, and rotational reference measurements when connected to a compatible 3300 XL Proximitor Sensor.
Q: Can the probe operate without a Proximitor Sensor?A: No. The 330104 probe requires a compatible Bently Nevada Proximitor Sensor to generate and condition the eddy-current measurement signal.
Q: What installation factors affect measurement accuracy?A: Installation accuracy depends on correct probe gap adjustment, proper thread engagement, target surface condition, cable routing, and correct shielding practices.
Field Installation Guidelines
Install the probe with the specified M10 x 1 mounting thread and maintain mechanical alignment with the monitored shaft surface.
Verify the probe gap voltage after installation using the connected Proximitor Sensor. Confirm that the measured gap remains within the expected operating range.
Route the coaxial cable away from high-current power conductors, switching devices, and electromagnetic interference sources.
Maintain proper cable shielding and grounding practices according to the vibration monitoring system installation requirements.
Inspect the probe tip and shaft target surface before commissioning. Remove contamination, excessive oxidation, or mechanical damage that may affect eddy-current signal stability.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-12-10-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-12-10-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated eddy-current measurement component for shaft displacement and vibration monitoring within Bently Nevada TSI monitoring systems.
Hardware Specifications
Parameter
Specification
Model
330104-00-12-10-02-00
Brand
Bently Nevada
Product Type
3300 XL 8 mm Proximity Probe
Origin
USA
Weight
0.18 kg
Dimensions
1.8 x 1.5 x 123 cm estimated shipping size
Power Consumption
Passive eddy-current probe, powered by compatible proximity transducer system
Probe Diameter
8 mm
Thread Type
M10 x 1 metric thread
Armor Protection
Included
Unthreaded Length
0 mm
Overall Case Length
120 mm
Total Length
1.0 meter (3.3 feet)
Cable Type
Miniature coaxial ClickLoc connector standard cable
Connector Type
ClickLoc miniature coaxial connector
Agency Approval
Not required
Tariff Code
8537101190
Eddy-Current Probe Scaling and Rotor Dynamics Monitoring
The 3300 XL 8 mm proximity probe uses an eddy-current sensing principle to convert shaft displacement into electrical signals. Therefore, the probe provides non-contact measurement of radial vibration, axial position, and rotational shaft movement when connected with a compatible Bently Nevada proximity signal conditioner.
The probe maintains calibrated eddy-current probe scaling characteristics through the complete measurement chain. In addition, the system evaluates gap voltage behavior to maintain proper probe positioning, with typical Bently Nevada installations referencing -10 VDC gap voltage targets for installation validation.
The 330104 series supports rotor dynamics analysis by providing accurate shaft motion data for vibration monitoring applications. Furthermore, the miniature coaxial ClickLoc cable design reduces connection errors and maintains signal integrity between the probe and monitoring electronics.
Frequently Asked Questions
Q: What measurement principle does the 330104-00-12-10-02-00 use?A: The probe uses an eddy-current measurement principle to detect shaft displacement without physical contact.
Q: Does this probe require a separate proximity transducer interface?A: Yes. The probe operates as part of a complete Bently Nevada proximity transducer system and requires compatible driver electronics.
Q: What is the function of the armor protection on this probe?A: The armor protection provides mechanical protection for the probe cable in industrial installation environments and helps reduce cable damage risks.
Field Installation Guidelines
Install the probe with the specified M10 x 1 thread connection and verify mechanical alignment before operation.
Maintain proper probe-to-shaft clearance according to the applicable Bently Nevada installation procedure.
Verify gap voltage after installation to confirm correct probe positioning and signal range.
Route the miniature coaxial cable away from high-current power conductors to reduce electrical interference.
Maintain proper cable shielding and grounding practices according to the monitoring system installation requirements.
Avoid sharp cable bending near the ClickLoc connector area to prevent mechanical stress on the connection point.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-10-90-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-10-90-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for eddy-current shaft displacement measurement within the 3300 XL Transducer System. The probe converts the gap distance between the probe tip and conductive shaft target into proportional DC voltage signals for vibration and position monitoring.
Hardware Specifications
Parameter
Specification
Model
330104-00-10-90-02-00
Brand
Bently Nevada
Product Type
3300 XL 8 mm Eddy-Current Proximity Probe
Origin
USA
Dimensions
100 mm probe case length; M10 x 1 metric mounting thread
Operating Temp
-52 deg C to +177 deg C
Power Consumption
Passive sensing element; powered by compatible proximity system driver
Measurement Principle
Eddy-current non-contact displacement measurement
Linear Range
2.0 mm (80 mils), typically 0.25 mm to 2.25 mm gap range
Scale Factor
7.87 V/mm (200 mV/mil), +/- 6.5%
Output Range
-1 VDC to -17 VDC
Frequency Response
0 Hz to 10 kHz (+0, -3 dB)
Target Material Calibration
AISI 4140 steel
Probe Tip Material
Polyphenylene sulfide (PPS)
Probe Body Material
AISI 303/304 stainless steel
Cable Protection
Flexible AISI 302 stainless steel armor with FEP outer jacket
Cable Length
9.0 m
Connector Type
Gold-plated brass ClickLoc miniature coaxial connector
Agency Approval
Standard configuration, no additional approval
Eddy-Current Measurement and Rotor Dynamics
The 330104-00-10-90-02-00 uses eddy-current probe scaling to provide proportional voltage output according to shaft-to-tip gap variation. Therefore, the connected monitoring system can evaluate radial vibration, axial displacement, and rotor position changes through continuous electrical measurement.
The probe system uses gap voltage validation with typical -10 VDC target calibration conditions to verify the correct operating position between the probe tip and shaft surface. In addition, the stable linear response supports rotor dynamics analysis by providing displacement data for vibration waveform processing and phase reference evaluation.
The probe construction incorporates a hermetically sealed sensing tip and shielded coaxial connection design. As a result, the system reduces measurement interference caused by oil environments, mechanical movement, and electrical noise sources.
Frequently Asked Questions
Q: What measurement signals does the 330104-00-10-90-02-00 provide?A: The probe provides a DC voltage output proportional to the shaft gap distance. The connected proximity transducer system converts this signal into vibration and position monitoring data.
Q: Can the probe measure both vibration and shaft position?A: Yes. The eddy-current sensing principle allows the probe to measure dynamic shaft vibration signals and static shaft displacement positions.
Q: What installation factors affect measurement accuracy?A: Correct probe gap setting, target material compatibility, cable routing, and proper shielding practices affect signal accuracy and system performance.
Field Installation Guidelines
Install the probe using the M10 x 1 metric mounting thread and maintain correct mechanical alignment with the monitored shaft surface.
Adjust the probe gap according to the compatible proximity system requirements. Verify the gap voltage before commissioning, with approximately -10 VDC commonly used as the reference operating point.
Route the armored cable away from high-current power cables, variable frequency drive outputs, and strong electromagnetic interference sources.
Connect the ClickLoc miniature coaxial connector securely and maintain clean contact surfaces during installation.
Ground cable shields according to the monitoring system installation manual to minimize electrical noise and signal interference.
Confirm the probe target surface condition before operation. The sensing target should match the calibrated material specification, typically AISI 4140 steel.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-10-10-02-CN 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-10-10-02-CN, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for eddy-current shaft displacement measurement within Bently Nevada 3300 XL proximity monitoring systems. It provides non-contact measurement of vibration, position, and speed through electromagnetic field variation between the probe tip and conductive targets.
Hardware Specifications
Parameter
Specification
Model
330104-00-10-10-02-CN
Brand
Bently Nevada
Product Series
3300 XL 8 mm Proximity Probe
Origin
USA
Dimensions
100 mm overall case length, 1.0 m probe cable length
Operating Temp
Probe: -51 deg C to +177 deg C; Connector: -51 deg C to +105 deg C
Power Consumption
Passive probe device; powered by compatible Proximitor sensor system
Probe Type
Eddy-current proximity probe
Thread Type
M10 x 1 metric thread
Unthreaded Length
0 mm
Cable Type
Standard coaxial cable, unarmored
Connector Type
Miniature coaxial ClickLoc connector
Probe Tip Material
Polyphenylene sulfide (PPS)
Probe Case Material
303 stainless steel
Target Material
AISI 4140 steel standard calibration target
Linear Range
2.0 mm (80 mils)
Measurement Range
Typically 0.25 mm to 2.25 mm (10 mils to 90 mils)
Scale Factor
7.87 V/mm (200 mV/mil) nominal
Non-linearity
Within +/-22.9 um (+/-0.9 mils) over linear range
Probe DC Resistance
7.5 ohm to 9.5 ohm for 1.0 m probe
Environmental Protection
IP68 when properly sealed; NEMA 4X
Eddy-Current Probe Scaling and Rotor Dynamics Measurement
The 330104-00-10-10-02-CN uses an eddy-current sensing circuit to convert shaft displacement into proportional electrical signals. The probe works with compatible Proximitor sensors to provide a calibrated output scale of 7.87 V/mm (200 mV/mil). Therefore, the system can evaluate dynamic vibration movement and static shaft position without physical contact.
Additionally, the 3300 XL 8 mm system supports rotor dynamics analysis by maintaining consistent probe interchangeability among compatible probes, extension cables, and signal conditioners. The installation requires correct gap voltage adjustment to maintain measurement accuracy, and Bently Nevada systems commonly validate probe operation around the -10 VDC gap voltage target.
Frequently Asked Questions
Q: Does the 330104-00-10-10-02-CN require individual bench calibration before replacement installation?A: No. The 3300 XL 8 mm proximity probe supports interchangeability with compatible extension cables and Proximitor sensors when the complete system configuration matches the specified requirements.
Q: What measurement principle does this proximity probe use?A: The probe uses an eddy-current measurement principle. It generates an electromagnetic field and detects changes caused by the distance variation between the probe tip and the conductive shaft surface.
Q: Can this probe measure both vibration and shaft position?A: Yes. The probe measures both dynamic displacement changes for vibration monitoring and static displacement changes for shaft position monitoring.
Field Installation Guidelines
Install the probe with the specified M10 x 1 mounting thread and maintain mechanical alignment with the rotating target surface.
Verify that the probe tip faces the conductive shaft material within the specified linear measurement range.
Maintain proper cable routing to reduce mechanical stress and avoid sharp bending near the ClickLoc connector.
Connect the cable shield according to the monitoring system grounding requirements to minimize electrical interference.
Confirm the probe gap voltage after installation. Bently Nevada proximity systems typically use a -10 VDC gap voltage target for standard operating adjustment.
Avoid installation locations with excessive contamination, direct impact, or mechanical damage risk to the probe tip and cable assembly.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-10-10-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-10-10-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within the 3300 XL Proximity Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-10-10-02-00
Brand
Bently Nevada
Product Type
Proximity Sensors
Series
3300 XL 8 mm Proximity Transducer System
Origin
USA
Weight
0.2kg
Dimensions
8 mm probe tip, 100 mm case length, 1.0 m cable length
Operating Temp
-51 deg C to +177 deg C
Power Consumption
Supplied by compatible 3300 XL Proximitor Sensor, value not specified
Probe Type
Eddy-current non-contact proximity probe
Thread Size
M10 x 1 metric thread
Armor Protection
Flexible stainless steel armored cable
Probe Tip Material
Polyphenylene sulfide (PPS)
Case Material
AISI 304 stainless steel
Connector Type
Miniature coaxial ClickLoc connector
Linear Measurement Range
2.0 mm (80 mils)
Scale Factor
7.87 V/mm (200 mV/mil) nominal
Frequency Response
0 to 10 kHz (+0, -3 dB typical)
Target Material
Standard AISI 4140 steel target
System Compatibility
3300 XL Proximitor Sensors and Extension Cables
Eddy-Current Measurement and Rotor Dynamics Monitoring
The 330104-00-10-10-02-00 uses an eddy-current sensing principle to detect shaft displacement without mechanical contact. Therefore, the probe provides dynamic vibration and static position signals required by turbine supervisory instrumentation (TSI) systems.
The probe maintains a nominal scale factor of 7.87 V/mm, which allows the connected Proximitor Sensor to convert gap changes into proportional voltage outputs. In addition, correct gap voltage validation supports accurate probe installation, with typical Bently Nevada systems using approximately -10 VDC gap voltage targets for normal operating alignment.
The probe geometry supports rotor dynamics analysis by measuring radial shaft movement, axial position changes, and vibration response. Furthermore, the armored cable construction reduces mechanical damage risks in industrial installation environments while maintaining signal transmission integrity.
Frequently Asked Questions
Q: What type of signal does the 330104-00-10-10-02-00 generate?A: The probe generates an eddy-current displacement signal through a compatible 3300 XL Proximitor Sensor. The system converts probe impedance changes into proportional vibration and position voltage outputs.
Q: Can this probe operate with other 3300 XL system components?A: Yes. The 330104-00-10-10-02-00 is designed for compatibility with 3300 XL Proximitor Sensors and matching extension cable assemblies.
Q: What installation factor affects measurement accuracy?A: Probe gap setting directly affects measurement accuracy. Technicians should verify the installation gap voltage and maintain correct probe alignment according to Bently Nevada system requirements.
Field Installation Guidelines
Install the probe with the M10 x 1 threaded section secured according to the mechanical drawing requirements.
Maintain proper probe tip clearance from the shaft target surface before system calibration.
Verify the gap voltage after installation to confirm the probe operates within the expected measurement range.
Route the armored cable away from high-current power conductors and strong electromagnetic interference sources.
Connect the ClickLoc connector securely and inspect the cable armor for mechanical damage before commissioning.
Confirm the target surface material matches the specified AISI 4140 steel calibration condition or apply the required system calibration procedure.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-09-10-02-00 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-09-10-02-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration measurement within the 3300 XL Proximity Transducer System.
Hardware Specifications
Parameter
Specification
Model
330104-00-09-10-02-00
Brand
Bently Nevada
Product Type
Eddy Current Proximity Probe
Series
3300 XL 8 mm Proximity Transducer System
Origin
USA
Weight
0.2kg
Dimensions
90 mm case length; 1.0 meter cable length
Operating Temp
Probe tip and cable: -51 deg C to +177 deg C
Power Consumption
Passive probe element; powered by compatible Proximitor sensor
Probe Diameter
8 mm
Thread Type
M10 x 1 metric thread
Unthreaded Length
0 mm
Armor Construction
Flexible stainless steel armor with FEP outer jacket
Connector Type
Miniature coaxial ClickLoc connector
Linear Measurement Range
2.0 mm (80 mils)
Scale Factor
7.87 V/mm (200 mV/mil) nominal
Cable Length
1.0 meter (3.3 feet)
System Compatibility
3300 XL 8 mm extension cables and Proximitor sensors
Eddy Current Scaling and Rotor Dynamics Measurement
The 330104-00-09-10-02-00 uses an eddy-current sensing principle to convert shaft displacement into an electrical signal through the compatible Proximitor sensor. Therefore, the probe maintains a defined scale factor of 7.87 V/mm for dynamic vibration and static position measurements.
The probe supports rotor dynamics monitoring by providing non-contact measurements of shaft motion. Additionally, the M10 x 1 threaded housing and armored cable design maintain mechanical positioning stability in rotating machinery installations.
The 3300 XL 8 mm system uses gap voltage validation methods to confirm probe operating position. During commissioning, technicians typically verify the Proximitor output gap voltage and target a nominal -10 VDC operating point for correct measurement range.
Frequently Asked Questions
Q: Does the 330104-00-09-10-02-00 require individual calibration with a 3300 XL system?
A: No. The probe is designed for interchangeability with compatible 3300 XL 8 mm extension cables and Proximitor sensors without individual calibration.
Q: What measurement signals does this proximity probe provide?
A: The probe provides eddy-current displacement signals representing shaft vibration and static position when connected to a compatible Proximitor sensor.
Q: What installation factors affect measurement accuracy?
A: Proper thread installation, probe gap adjustment, cable routing, and electrical shielding practices affect signal stability and measurement accuracy.
Field Installation Guidelines
Install the M10 x 1 threaded probe housing according to the mechanical mounting requirements of the monitored machine.
Maintain correct probe tip clearance from the shaft target surface before operation. Verify the Proximitor gap voltage during commissioning.
Route the armored cable away from high-current power conductors and sources of electromagnetic interference.
Connect the miniature coaxial ClickLoc connector securely to maintain signal continuity.
Ground cable shielding according to the monitoring system installation manual and site grounding practices.
Inspect the armor and FEP outer jacket for mechanical damage before final commissioning.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Bently Nevada 330104-00-09-05-11-05 3300 XL 8 mm Proximity Probe
The Bently Nevada 330104-00-09-05-11-05, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within the Bently Nevada 3300 XL monitoring system.
Hardware Specifications
Parameter
Specification
Model
330104-00-09-05-11-05
Brand
Bently Nevada
Product Type
Eddy Current Proximity Sensors
Series
3300 XL 8 mm Proximity Probe
Origin
USA
Dimensions
8 mm probe tip diameter; 90 mm case length; 0.5 m total length
Operating Temp
-52 deg C to +177 deg C
Power Consumption
Passive probe element; powered through connected Proximitor Sensor
Measurement Principle
Eddy current non-contact displacement measurement
Thread Type
M10 x 1 metric thread
Case Material
AISI 303 or 304 stainless steel
Tip Material
Polyphenylene Sulfide (PPS)
Cable Type
Coaxial cable with stainless steel flexible armor
Connector Type
ClickLoc miniature coaxial connector with protective shroud
Linear Range
2.0 mm (80 mils), from 0.25 mm to 2.25 mm (10 to 90 mils)
Scale Factor
7.87 V/mm (200 mV/mil) nominal with 3300 XL Proximitor Sensor
Cable Protection
FluidLoc armored cable structure
Hazardous Area Approval
CSA, ATEX, IECEx certifications
Eddy Current Measurement and Rotor Dynamics Monitoring
The 330104-00-09-05-11-05 uses an eddy current sensing circuit to convert shaft displacement into proportional electrical signals. Therefore, the connected 3300 XL Proximitor Sensor can process radial vibration, axial position, and speed-related shaft movement data.
The probe maintains a nominal scale factor of 7.87 V/mm when paired with the matching Proximitor Sensor. In addition, the system supports gap voltage validation, where field technicians verify probe operating conditions against typical -10 VDC gap voltage targets during commissioning.
The 3300 XL probe design supports rotor dynamics analysis by providing stable displacement measurements for vibration trending, shaft orbit analysis, and machinery protection functions. Furthermore, the armored FluidLoc cable reduces signal variation caused by mechanical damage or oil penetration.
Frequently Asked Questions
Q: Can the 330104-00-09-05-11-05 operate independently without a Proximitor Sensor?A: No. The probe requires a compatible 3300 XL Proximitor Sensor to generate and condition the eddy current measurement signal.
Q: What installation factor affects measurement accuracy?A: Probe mounting position, target shaft material, mechanical clearance, cable routing, and correct gap voltage adjustment directly affect measurement performance.
Q: Does this probe require individual calibration after replacement?A: No. The 3300 XL system supports interchangeable probe components when matched with compatible extension cables and Proximitor Sensors.
Field Installation Guidelines
Install the probe with the specified M10 x 1 threaded mounting interface and maintain correct mechanical alignment with the rotating shaft target.
Route the armored cable away from high-current power wiring to reduce electromagnetic interference.
Connect the ClickLoc coaxial connector fully and verify the locking mechanism before machine operation.
Maintain proper shielding and grounding practices at the monitoring system connection point.
Verify probe gap voltage after installation and confirm signal output before enabling machinery protection functions.
Avoid excessive cable bending or mechanical stress near the connector and probe body.
