DescriptionThe Allen-Bradley 1756-IH16I is a high-performance digital input module designed for the ControlLogix platform. This module provides 16 individually isolated input points, offering robust signal processing for industrial applications requiring 125V DC inputs. Its isolated design ensures enhanced noise immunity and protection against ground loops between field devices and the backplane, making it a reliable choice for complex automation environments.Features
Isolated Inputs: Features 16 individually isolated points for superior signal integrity.
Voltage Compatibility: Designed for 125V DC sink/source input applications.
Operating Range: Supports a wide operating voltage range of 90 to 146V DC.
Configurable Filtering: Includes a base input delay of 6 milliseconds, which can be extended via user-selectable filter times to suit specific process requirements.
ControlLogix Integration: Fully compatible with the Allen-Bradley ControlLogix chassis and backplane communication protocols.
Technical Specifications
Model Number
1756-IH16I
Manufacturer
Allen-Bradley
Input Count
16 (Individually Isolated)
Nominal Input Voltage
125V DC
Operating Voltage Range
90 - 146V DC
Input Delay Time
6 ms + selected filter time
Module Type
Digital Input Module
Installation Guidelines
Power Status: Always disconnect power from the ControlLogix chassis before installing or removing the module.
ESD Protection: Use a grounded wrist strap or similar ESD protection when handling the module to prevent damage to sensitive internal circuitry.
Seating: Ensure the module is properly aligned with the chassis slot guides and firmly seated into the backplane connector.
Wiring: Use appropriate shielded cabling for field inputs to minimize EMI interference. Ensure all terminal connections are secure and properly torqued.
Ventilation: Maintain adequate clearance around the chassis to ensure sufficient airflow for cooling, as per the ControlLogix thermal management guidelines.
FAQQ: Is the 1756-IH16I compatible with standard ControlLogix chassis?A: Yes, this module is designed for use in any standard Allen-Bradley ControlLogix I/O chassis.Q: What does "individually isolated" mean for this module?A: Each of the 16 input points is electrically isolated from the others and from the backplane, which helps prevent electrical noise or faults on one channel from affecting the others.Q: Can I use this module for 24V DC signals?A: No, the 1756-IH16I is specifically rated for 125V DC operation. Attempting to use it with lower voltage levels may result in improper operation or failure to detect the signal.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-IG16 is a high-performance digital DC input module designed for integration within the ControlLogix platform. This module features 16 input points, organized with nine points per common, specifically engineered to interface with 5V DC TTL source signals. It provides reliable signal acquisition for industrial automation systems requiring low-voltage digital input monitoring.Features
16-point digital DC input density for efficient I/O allocation.
Optimized for 5V DC TTL source applications.
Configurable input filter times for noise immunity and signal debouncing.
Low power dissipation of 1.4 Watts at 60 degC.
Compact ControlLogix form factor for chassis-based mounting.
Technical Specifications
Module Type
Digital DC Input Module
Input Points
16 (9 per common)
Operating Voltage
4.5V to 5.5V DC
Input Delay Time
0.25 ms + selectable filter time
Max Off-State Current
4.1 mA
Backplane Current (5V)
110 mA
Power Dissipation
1.4 W at 60 degC
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent electrical damage.
The module should be seated firmly into the chassis slot and secured using the provided locking mechanism.
Use shielded cabling for input signals to minimize electromagnetic interference (EMI) in high-noise environments.
Maintain proper ventilation in the control cabinet to ensure operating temperatures do not exceed the rated limits.
Verify that the common wiring matches the module's 9-point grouping configuration during installation.
FAQWhat is the primary application for the 1756-IG16?This module is used for receiving 5V DC TTL signals from field devices into a ControlLogix controller system.Does this module require a specific chassis?Yes, it is designed for use with the standard Allen-Bradley ControlLogix I/O chassis.Can I adjust the input delay?Yes, the module supports selectable filter times that add to the base 0.25 ms input delay to help filter out transient noise.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-IH16ISOE is a high-performance digital isolated input module designed for the ControlLogix platform. This module provides 16 individually isolated inputs with Sequence of Events (SOE) recording capabilities, making it ideal for monitoring critical process states where timing and event logging are essential. It is engineered to handle 125V DC sink/source signals, offering robust performance in demanding industrial environments.Features
16 individually isolated input channels for enhanced electrical noise immunity.
Integrated Sequence of Events (SOE) functionality for precise timestamping of input state changes.
Supports a wide operating voltage range of 90-140V DC.
Low power dissipation of 5.5 Watts at 60 degC for efficient thermal management.
Compatible with standard ControlLogix chassis backplanes.
ApplicationsThis module is frequently utilized in large-scale automation systems, including power distribution monitoring, emergency shutdown systems, and complex process control applications where high-voltage digital inputs and accurate event sequencing are required.Technical Specifications
Module Type
Digital Isolated Input Module (SOE)
Input Channels
16 (Individually Isolated)
Input Voltage
125V DC (Sink/Source)
Operating Range
90-140V DC
Backplane Current (5V)
275 mA
Backplane Current (24V)
2 mA
Input Delay Time
75 microseconds + filter time
Min Operating Current
1.15 mA at 90V DC
Max Operating Current
1.85 mA at 140V DC
Max Off-State Current
0.3 mA
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent damage to the backplane or module circuitry.
Use appropriate shielded cabling to minimize EMI/RFI interference, especially when dealing with high-voltage DC signals.
Verify that the input voltage levels are within the specified 90-140V DC range to maintain signal integrity and module longevity.
Maintain proper ventilation in the control cabinet to keep the ambient temperature within the rated operating limits, ensuring the module stays below its maximum power dissipation threshold.
Follow standard ESD (Electrostatic Discharge) mitigation practices when handling the module to protect internal electronic components.
FAQWhat is the primary function of the SOE feature on this module?The Sequence of Events (SOE) capability allows the module to log the exact time a state change occurs on an input channel, which is critical for troubleshooting and analyzing complex industrial processes.Does this module support both sinking and sourcing configurations?Yes, the 1756-IH16ISOE is designed to support both sink and source input configurations, providing flexibility for various field device wiring requirements.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Ovation 5X00105G14 is a high-density electronics module engineered for seamless integration within the Ovation Distributed Control System (DCS). This module serves as a foundational component for managing complex industrial processes, providing the necessary computational power and signal processing required for large-scale infrastructure, including power generation facilities and petrochemical processing plants. By optimizing logic execution and data throughput, the 5X00105G14 helps maintain precise control over I/O operations, enhancing overall system stability and reducing the likelihood of operational interruptions.Features
Optimized for high-speed, deterministic logic execution within the Ovation control architecture.
Advanced PCB design incorporating robust signal buffering to ensure reliable data integrity.
Designed for electrical isolation, providing protection against transient voltage spikes and electromagnetic interference (EMI).
Modular form factor facilitates efficient maintenance and rapid replacement during scheduled system outages.
Supports scalable system expansion, allowing for flexible configuration in diverse industrial setups.
ApplicationsThis module is primarily utilized in mission-critical automation environments where high availability and process consistency are required. Typical deployments include thermal power generation, continuous manufacturing processes, and refinery control systems where the 5X00105G14 plays a vital role in data synchronization and real-time control.Technical Specifications
Model
5X00105G14
Brand
Ovation
Operating Temperature
0 to 60 degC
Power Supply
24 VDC (Backplane)
Mounting
Standard Ovation Control Rack
Weight
0.48 kg
Installation Guidelines
Ensure the Ovation rack is powered down before attempting to insert or remove the module to prevent electrical damage or bus errors.
Handle the module using proper electrostatic discharge (ESD) protection protocols to protect sensitive internal circuitry.
Verify that the module is fully seated within the rack slot to ensure reliable backplane connectivity.
Maintain adequate ventilation around the control rack to stay within the specified 0 to 60 degC operating range.
Check all backplane connections for signs of oxidation or physical damage prior to commissioning.
FAQIs the 5X00105G14 compatible with all Ovation systems?This module is designed specifically for the Ovation DCS platform. Compatibility depends on your specific cabinet revision and firmware version; please consult your system documentation or engineering drawings to verify the correct part match for your existing rack configuration.What is the primary function of this module?The 5X00105G14 acts as an electronics module for processing and managing I/O signals, ensuring deterministic communication and control within the Ovation backplane architecture.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Allen-Bradley 1756-BA1 is a dedicated lithium battery assembly engineered to provide reliable memory backup for ControlLogix and FlexLogix programmable automation controllers. This non-rechargeable 3.0V DC lithium manganese dioxide cell is essential for maintaining user programs, configuration data, and variable memory tables during power interruptions or system shutdowns. It ensures that volatile RAM contents are preserved, preventing the need for time-consuming system reprogramming upon power restoration.Features
Nominal voltage: 3.0V DC
Nominal capacity: 1800 mAh
Form factor: 2/3A cylindrical lithium cell
Integrated lead wire with dedicated connector for secure chassis interface
Designed for legacy ControlLogix and FlexLogix processor modules
Applications
Process & Manufacturing Automation: Safeguards critical process data and logic against unexpected power loss.
Safety Control Systems: Maintains configuration integrity for safety-rated controller chassis.
High-Availability Operations: Facilitates faster system recovery and uptime in redundant PLC configurations.
Motion Control: Retains position data and servo configuration parameters for Kinetix and related drive systems.
Technical Specifications
Product Model
1756-BA1
Battery Chemistry
Lithium Manganese Dioxide
Nominal Voltage
3.0V DC
Capacity
1800 mAh
Operating Temperature
Recommended storage near 30 degC
Weight
0.04 kg
Installation Guidelines
Power Status: Always ensure the controller is properly powered down or the battery replacement procedure is performed in accordance with the specific controller manual to avoid memory corruption.
Connector Seating: Ensure the lead wire connector is fully seated in the controller battery port. The 1756-BA1 uses a specific connector type; do not force or modify the connector.
Temperature Management: Battery life is significantly impacted by ambient temperature. In environments exceeding 30 degC, monitor battery health closely and plan for more frequent replacement cycles.
Storage: Store in a cool, dry environment. Avoid high-temperature areas to maximize shelf life prior to installation.
FAQWhat is the primary function of the 1756-BA1?The 1756-BA1 acts as a volatile memory backup power source. It ensures that user-programmed logic and configuration data are not lost when the main power to the controller is disconnected.Is the 1756-BA1 compatible with Series B ControlLogix processors?No. Series B and later controllers typically require the 1756-BA2 battery, which utilizes a different connector size. The 1756-BA1 connector is physically incompatible with newer hardware; do not attempt to modify cables to bypass this restriction.How long does the battery typically last?Under normal operating conditions, the life expectancy is approximately 2 years. However, this duration can decrease significantly if the controller is frequently power-cycled or stored for extended periods without backplane power.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-IB32/B is a high-density digital DC input module from the ControlLogix series, specifically a Series B hardware revision. Engineered for demanding industrial environments, this module provides 32 sinking-type inputs, allowing for the connection of a wide array of field devices including proximity sensors, limit switches, and pushbuttons within a single-slot footprint. It facilitates efficient communication between field instrumentation and the ControlLogix PAC backplane, ensuring reliable data acquisition for complex automation sequences.Features
High-Density Architecture: Manages 32 discrete 24V DC inputs in a single chassis slot to optimize space.
Sinking Input Configuration: Requires field devices to source positive voltage to the module terminal for input activation.
Group Isolation: Channels are organized into two electrically isolated groups of 16, enhancing system fault tolerance.
Optimized Signal Conditioning: Integrated optocouplers provide electrical isolation between field wiring and internal controller circuitry.
Flexible Compatibility: Designed for use with standard 1756-TBCH or 1756-TBS6H removable terminal blocks.
ApplicationsThis module is widely utilized in large-scale manufacturing, process control, and material handling systems where high-density digital I/O is required. Typical deployments include monitoring status signals from machine safety interlocks, conveyor sensors, and various discrete field-side input devices integrated into a ControlLogix rack.Technical Specifications
Model
1756-IB32/B
Input Points
32 (2 groups of 16)
Voltage Category
12/24V DC Sink
Operating Range
10 to 31.2V DC
On-State Current
4.8 mA to 5.5 mA
Backplane Power
120 mA @ 5.1V DC / 2 mA @ 24V DC
Power Dissipation
6.2 Watts (max)
Operating Temperature
0 to 60 degC
Weight
0.23 kg
Installation Guidelines
Power Status: Always disconnect chassis power before installing or removing the module to prevent electrical arcing or damage to backplane pins.
Terminal Blocks: Ensure the compatible 1756-TBCH or 1756-TBSH terminal block is fully seated and secured with the locking latch.
Wiring: Use shielded cabling for field inputs to minimize EMI; route signal wires separately from high-voltage power lines.
Grounding: Ensure the ControlLogix chassis is properly bonded to a low-impedance earth ground to maintain signal integrity.
Electronic Keying: Utilize the Studio 5000 / RSLogix 5000 software to configure electronic keying, ensuring the module matches the project definition for safety and operational consistency.
FAQIs this module compatible with Series A systems?The 1756-IB32/B is a Series B revision. While it is generally backward compatible with ControlLogix backplanes, always verify your specific project configuration in Studio 5000 to ensure the electronic keying settings match the hardware revision.What terminal blocks are required for this module?This module requires a 36-pin removable terminal block (RTB). Compatible models include the 1756-TBCH (cage clamp) or 1756-TBS6H/1756-TBSH (spring clamp).
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-DMA31 is a specialized ControlLogix module designed to facilitate high-speed communication between a ControlLogix controller and supported drive systems. This SynchLink Drive Interface Module serves as a critical bridge for motion control synchronization, ensuring reliable data exchange in demanding industrial automation environments.Features
Single-axis drive interface capabilities for precise motion control.
Integrated SynchLink technology for high-speed synchronization across the control architecture.
Supports a SynchLink data rate of 5 Mbps.
Drive communication data rate of up to 10 Mbps.
Optimized for use with 650 nm wavelength fiber optic connections.
Standard ControlLogix form factor for seamless integration into existing chassis systems.
Technical Specifications
Product Model
1756-DMA31
Manufacturer
Allen-Bradley
Current Draw
1.35 A at 5 VDC
SynchLink Data Rate
5 Mbps
Drive Comm. Data Rate
10 Mbps
Optimal Wavelength
650 nm
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-DMA31 module to prevent electrical damage.
Verify that the module is fully seated in the chassis slot and that the locking mechanism is engaged.
Use appropriate fiber optic cabling rated for 650 nm operation to maintain signal integrity.
Route communication cables away from high-voltage power lines and sources of electromagnetic interference (EMI) to ensure stable data transmission.
Maintain proper ventilation in the control cabinet to keep the module within its specified operating temperature range.
FAQWhat is the primary function of the 1756-DMA31?This module acts as a SynchLink interface, allowing for synchronized motion control and high-speed data communication between the ControlLogix controller and compatible drive hardware.What power requirements does this module have?The 1756-DMA31 consumes 1.35 A of current at a 5 VDC power supply level, which is drawn directly from the ControlLogix backplane.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Allen-Bradley 1756-IF8I is a high-performance analog input module designed for the ControlLogix platform. This module provides eight isolated input channels, allowing for flexible monitoring of various field devices. It supports both voltage and current signal modes, which can be configured per channel to suit diverse industrial measurement requirements. The module utilizes a Sigma-Delta conversion method to ensure precise and reliable data acquisition in demanding automation environments.Features
Eight isolated analog input channels for enhanced noise immunity and signal integrity.
Configurable input modes supporting both voltage (-10 to 10V, 0 to 10V, 0 to 5V) and current (0 to 20 mA) ranges.
High-resolution analog-to-digital conversion ranging from 16 to 21 bits.
Integrated power management with a backplane current draw of 200 mA at 5.1V.
Designed for seamless integration within the ControlLogix chassis system.
Technical Specifications
Model Number
1756-IF8I
Manufacturer
Allen-Bradley
Series
ControlLogix
Input Channels
8 Isolated
Conversion Method
Sigma-Delta
Voltage Ranges
-10 to 10V, 0 to 10V, 0 to 5V
Current Ranges
0 to 20 mA
Resolution
16-21 bits
Backplane Current (5.1V)
200 mA
Current Draw (24V)
150 mA or 400 mA
Enclosure Type
Open
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-IF8I module to prevent electrical damage.
The module should be installed in an open-type enclosure suitable for the specific application environment.
Use shielded twisted-pair cabling for all analog input signals to minimize electromagnetic interference (EMI).
Ensure proper grounding of the cable shields at the signal source or the module end, depending on system design requirements.
Verify that the module is fully seated in the chassis slot and that the locking mechanism is engaged.
FAQWhat are the primary input modes for the 1756-IF8I?This module supports multiple voltage ranges including -10 to 10V, 0 to 10V, and 0 to 5V, as well as a 0 to 20 mA current input mode. These can be configured independently for each of the eight channels.Is this module isolated?Yes, the 1756-IF8I features eight isolated channels, which helps protect the module and the controller from ground loops and common-mode noise.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Allen-Bradley 1756-IB16 is a high-performance digital input module designed for the ControlLogix platform. This module provides 16 input points, supporting a voltage range of 12V to 24V DC. Engineered for industrial reliability, it features sink input operation and electronic keying to ensure correct module insertion and configuration within the chassis.Features
16 isolated digital input channels for versatile signal monitoring.
Operating voltage range of 10V to 31.2V DC to accommodate varying power supply fluctuations.
Electronic keying support to prevent incorrect module installation in the ControlLogix backplane.
Compact design optimized for high-density I/O configurations in industrial control cabinets.
Low power dissipation of 5.1 W at 60 degC for efficient thermal management.
ApplicationsThis module is widely used in factory automation, process control systems, and machinery management where reliable 12/24V DC signal acquisition is required. It is compatible with standard ControlLogix chassis and integrates seamlessly into complex automation architectures requiring high-speed digital input processing.Technical Specifications
Model Number
1756-IB16
Input Type
12/24V DC Sink
Operating Voltage
10-31.2V DC
Input Points
16
Power Dissipation
5.1 W @ 60 degC
Current Draw
10 mA @ 31.2V DC / 2 mA @ 10V DC
Manufacturer
Allen-Bradley
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-IB16 module.
Verify that the slot is configured correctly for the module type before applying power.
Use appropriate shielded cabling for input signals to minimize electromagnetic interference (EMI) in high-noise environments.
Maintain adequate ventilation within the cabinet to ensure the module operates within its specified temperature range.
Follow local electrical codes and standard grounding procedures for all I/O wiring.
FAQIs the 1756-IB16 compatible with all ControlLogix chassis?Yes, this module is designed for use in any standard ControlLogix chassis, provided the slot is correctly configured and the power supply can support the module's current draw.What does the electronic keying feature do?Electronic keying allows the system to verify that the physical module matches the software configuration, preventing operational errors caused by installing the wrong module type in a specific slot.
The Allen-Bradley 1756-IF8 is a high-performance analog input module designed for the ControlLogix automation platform. It provides eight input channels capable of processing both voltage and current signals, facilitating the integration of diverse field devices such as pressure transducers, flow meters, and temperature transmitters into your control architecture.Features
Eight-channel input configuration supporting single-ended, differential, and high-speed differential modes.
Flexible signal range support including +/-10V, 0-10V, 0-5V, and 0-20mA (including 4-20mA).
High-resolution 16-bit data conversion using Sigma-Delta technology for precise process monitoring.
Integrated digital filtering to mitigate signal noise and improve measurement stability.
Efficient power consumption with low backplane current draw.
Applications
Dosing and metering systems requiring accurate flow feedback.
Filtration monitoring using differential pressure sensors.
Industrial hydraulic and pneumatic stamping press force control.
Injection molding process control for temperature and pressure monitoring.
Water treatment and environmental monitoring skids for pH and turbidity tracking.
Technical Specifications
Manufacturer
Allen-Bradley
Model
1756-IF8
Module Type
Analog Input
Input Channels
8 (Single-ended) / 4 (Differential)
Conversion Method
Sigma-Delta
Backplane Current (5V)
150 mA
Backplane Current (24V)
40 mA
Power Dissipation (Voltage Mode)
1.73 W
Power Dissipation (Current Mode)
2.33 W
Installation Guidelines
Enclosure Requirements: This is open-type equipment and must be installed within a suitable NEMA or IEC-rated enclosure to prevent accidental contact with live electrical components.
RIUP Caution: While the module supports Removal and Insertion Under Power (RIUP), ensure field-side power is disconnected before removing the Removable Terminal Block (RTB) to prevent electrical arcing.
Grounding: Ensure the chassis is properly grounded in accordance with local electrical codes to minimize EMI and ensure signal integrity.
Handling: Use standard ESD-safe handling procedures when installing or removing the module from the ControlLogix rack.
FAQWhat is the primary function of the 1756-IF8?The 1756-IF8 acts as an interface between field analog sensors and the ControlLogix processor, converting continuous voltage or current signals into digital data for control logic.Is this module isolated?The 1756-IF8 is a non-isolated module. If your application requires channel-to-channel isolation, please consider the 1756-IF8I model.How are the input channels configured?The module supports 8 single-ended inputs or 4 differential inputs depending on your wiring and configuration settings in the Studio 5000 software.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-EN3TR is a high-performance communication interface module designed for the ControlLogix platform. This EtherNet/IP bridge module features an integrated dual-port switch, allowing for seamless connectivity and support for Device Level Ring (DLR) topologies. It is engineered to facilitate efficient data exchange across industrial networks while supporting demanding applications, including advanced motion control systems with up to 128 axes.Features
Integrated dual-port switch for linear or ring network topologies.
Supports EtherNet/IP communication protocols for robust industrial data transfer.
High-capacity motion control support, capable of handling up to 128 axes.
Designed for seamless integration into standard ControlLogix chassis environments.
USB configuration port with a 12 Mbps data transfer rate for local maintenance and diagnostics.
ApplicationsThis module is widely utilized in complex automation systems requiring high-speed communication between controllers and distributed I/O. It is particularly well-suited for motion control applications, large-scale process automation, and integrated manufacturing environments where high-bandwidth, reliable Ethernet connectivity is essential.Technical Specifications
Product Model
1756-EN3TR
Communication Port
EtherNet/IP (Copper)
Backplane Current (5V)
1.0 A
Backplane Current (24V)
3 mA
Power Consumption
5.1 W
Insulation Voltage
30 V (Continuous)
USB Rate
12 Mbps
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-EN3TR module to prevent electrical damage.
Properly seat the module into the designated slot and secure it using the top and bottom latching mechanisms.
Use shielded Ethernet cabling for all network connections to minimize electromagnetic interference (EMI) in industrial environments.
Maintain adequate spacing within the cabinet to allow for proper airflow and cooling, as the module consumes 5.1 Watts during operation.
Verify that the network topology is correctly configured for either linear or DLR mode prior to commissioning.
FAQQ: Does the 1756-EN3TR support Device Level Ring (DLR)?A: Yes, this module features an embedded switch that supports DLR, allowing for fault-tolerant network rings.Q: Is this module compatible with all ControlLogix chassis?A: The 1756-EN3TR is designed for use with standard 1756 ControlLogix chassis. Ensure your firmware version is compatible with your specific controller requirements.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-EN2TRXT is a ruggedized EtherNet/IP communication bridge module within the ControlLogix-XT series, specifically developed for deployment in harsh industrial conditions. This module incorporates dual-port embedded switch technology to support advanced network topologies, including Device Level Ring (DLR), linear, and star configurations, while maintaining high-speed communication in demanding environments.Features
Ruggedized Design: Engineered with specialized protective coatings to withstand corrosive gases, high humidity, salt spray, and extreme temperature fluctuations.
Dual-Port Embedded Switch: Facilitates seamless integration into DLR networks, providing rapid recovery times in the event of a media fault.
Extended Environmental Range: Rated for reliable operation between -25 and 70 degC.
High-Performance Connectivity: Supports up to 256 CIP connections and 128 TCP/IP connections for robust data exchange.
Local Configuration: Includes a dedicated USB 1.1 port for efficient local diagnostics and module programming.
Technical Specifications
Model
1756-EN2TRXT
Brand
Allen-Bradley / Rockwell Automation
Product Series
ControlLogix-XT
Communication Rate
10/100 Mbps (Auto-negotiating)
Operating Temperature
-25 to 70 degC
CIP Connections
256
TCP/IP Connections
128
Backplane Power
1.0 A at 5.1 VDC
Slot Width
1 Slot
Installation Guidelines
Ensure the ControlLogix-XT chassis is properly grounded before installing the module.
Always power down the chassis backplane before inserting or removing the 1756-EN2TRXT to prevent electrical arcing or damage to the backplane pins.
Use shielded twisted-pair cabling for all Ethernet connections to minimize EMI interference in high-noise environments.
Maintain adequate clearance around the module to ensure proper airflow and heat dissipation, especially when operating at the upper limits of the temperature range.
Handle the module with care to avoid damaging the conformal coating that provides environmental protection.
FAQIs this module compatible with standard ControlLogix chassis? Yes, the 1756-EN2TRXT is physically compatible with any standard ControlLogix chassis, though it is intended for use in ControlLogix-XT environments to take full advantage of its ruggedized features.Does this module require an external switch for DLR? No, the integrated dual-port switch allows the module to function as part of a Device Level Ring (DLR) without the need for an external managed industrial switch.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Allen-Bradley 1756-EN2TSC is a high-performance communication module designed for the ControlLogix platform. This module functions as an EtherNet/IP bridge, providing secure connectivity through integrated VPN capabilities. It is engineered to facilitate robust communication within industrial automation environments, supporting high-speed data exchange and reliable network integration for complex control systems.Features
Single-port EtherNet/IP interface for streamlined network connectivity.
Integrated VPN support for secure remote communication and data protection.
High-performance processing designed for demanding ControlLogix applications.
Supports up to 128 TCP/IP connections, enabling extensive device integration.
Operates at 10/100 Mbps data rates to suit standard industrial Ethernet requirements.
ApplicationsThis module is typically deployed in manufacturing and process control environments where secure, high-bandwidth communication between the ControlLogix controller and remote devices or supervisory systems is required. It is suitable for applications involving distributed I/O, remote diagnostics, and secure plant-floor network management.Technical Specifications
Model Number
1756-EN2TSC
Product Type
EtherNet/IP Communication Bridge
Communication Port
Single Port
Network Speed
10/100 Mbps
TCP/IP Connections
Up to 128
VPN Capability
Integrated Secure Communication
Weight
0.24 kg
Installation Guidelines
Ensure the ControlLogix chassis is powered down before installing or removing the 1756-EN2TSC module to prevent electrical damage.
Slide the module into the designated slot in the chassis, ensuring it is properly aligned with the backplane connector.
Secure the module using the top and bottom locking latches to maintain a solid connection and proper grounding.
Use shielded Ethernet cabling for all connections to minimize electromagnetic interference (EMI) in industrial environments.
Maintain proper ventilation in the control cabinet to ensure the module operates within its specified temperature range.
Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect sensitive internal components.
FAQWhat is the primary function of the 1756-EN2TSC?The 1756-EN2TSC is a ControlLogix communication module that provides EtherNet/IP connectivity with added VPN security features for secure remote access and data transfer.How many TCP/IP connections can this module handle?This module supports up to 128 concurrent TCP/IP connections, allowing for significant scalability in network communication.Does this module require a specific chassis?Yes, it is designed for use within the Allen-Bradley ControlLogix chassis system.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Allen-Bradley 1746-QV is a dedicated motion control module engineered for the SLC 500 automation platform. This module specializes in open-loop velocity control, providing a reliable method for managing the speed and positioning of hydraulic or pneumatic actuators. By integrating feedback from a Linear Displacement Transducer (LDT) and processing motion instructions directly from the SLC processor, the 1746-QV enables smooth, profiled motion in systems that do not necessitate complex closed-loop servo synchronization.Features
Single-axis motion control capability for SLC 500 systems.
Supports integration with Linear Displacement Transducers (LDT) for precise position feedback.
Programmable motion profiles allowing for up to seven distinct voltage levels to manage acceleration and deceleration.
Analog output range of -10V to +10V DC for versatile actuator drive control.
Optimized for reducing mechanical stress and pressure spikes in hydraulic applications.
Fast update time of 2 ms for responsive motion execution.
ApplicationsThe 1746-QV is particularly well-suited for industrial machinery requiring controlled, non-CNC motion, including hydraulic presses, industrial welders, and die casting equipment. Its ability to profile motion cycles helps in achieving consistent cycle times and extending the lifespan of mechanical components.Technical Specifications
Brand
Allen-Bradley
Product Series
SLC 500
Module Type
Open-Loop Velocity Control
Axes Controlled
1
Analog Output Range
-10 to +10V DC
Update Time
2 ms
Backplane Current (5V DC)
215 mA
Operating Temperature
0 to 60 degC (32 to 140 degF)
Storage Temperature
-40 to 85 degC (-40 to 185 degF)
Humidity
5% to 95% (non-condensing)
Installation Guidelines
Ensure the SLC 500 chassis power is disconnected before installing or removing the 1746-QV module.
Handle the module using proper ESD (electrostatic discharge) precautions to prevent damage to internal circuitry.
Verify that the LDT feedback cable is properly shielded and routed away from high-voltage AC lines to minimize electromagnetic interference (EMI).
Ensure the module is fully seated in the SLC 500 backplane slot and secured with the integrated locking tabs.
Maintain adequate spacing within the enclosure to allow for proper ventilation and heat dissipation.
FAQWhat is the primary function of the 1746-QV?It is designed for open-loop velocity control of hydraulic or pneumatic actuators, allowing users to define acceleration and deceleration profiles via the SLC 500 processor.Does this module support closed-loop control?No, the 1746-QV is specifically designed for open-loop velocity applications where full servo-loop synchronization is not required.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
Product DescriptionThe Allen-Bradley 1756-CN2R/B is a high-performance, Series B ControlNet communication bridge module engineered for the ControlLogix platform. This module facilitates deterministic data exchange between controllers, remote I/O, drives, and other intelligent field devices. As a redundant bridge, it provides a robust communication backbone for critical control applications, ensuring high availability through dual-channel coaxial support.Features
Redundant Communication: Dual BNC ports allow for media redundancy, enabling the network to maintain operations seamlessly if one coaxial cable segment fails.
Deterministic Throughput: Operates at a consistent 5 Mbps speed, ensuring predictable data delivery across the ControlNet network.
High Capacity: Supports up to 99 nodes on the network with a maximum of 131 total connections, including 128 dedicated Logix connections.
Integrated USB Port: Includes a local USB port for convenient configuration and diagnostics.
Series B Reliability: Updated hardware revision for enhanced processing and improved stability in industrial environments.
ApplicationsThis module is typically deployed in large-scale manufacturing and process control environments where network reliability is paramount. It is commonly used for distributed I/O control, inter-controller messaging, and high-speed data synchronization in ControlLogix systems.Technical Specifications
Model
1756-CN2R/B
Series
Series B
Communication Rate
5 Mbps
USB Port Speed
12 Mbps
Max Nodes
99
Max Connections
131 (128 Logix)
Backplane Current (5.1V)
1300 mA
Backplane Current (24V)
3 mA
Max Power Dissipation
6.7 Watts
Operating Temperature
0 to 60 deg C
Enclosure Type
Open
Installation Guidelines
Handling: This module is sensitive to electrostatic discharge (ESD). Ensure proper grounding procedures are followed before handling or installing the card.
Mounting: Designed for installation in any standard 1756 ControlLogix chassis. Ensure the module is fully seated in the slot and the top/bottom retaining clips are secured.
Cabling: Use only 1786-RG6 quad-shield coaxial cable for ControlNet connections to maintain signal integrity.
Power: Always disconnect power from the ControlLogix chassis backplane before inserting or removing the communication module.
Environment: Maintain adequate clearance around the chassis to ensure proper ventilation and cooling, keeping the ambient temperature within the specified 0 to 60 deg C range.
FAQQ: Does this module support non-redundant configurations?A: While the 1756-CN2R/B is designed for redundant media applications, it can be used in non-redundant setups if only one BNC port is connected, though it is specifically built to provide the redundancy feature.Q: Is this module compatible with all ControlLogix chassis?A: It is compatible with standard 1756 series chassis, including the 1756-A4, A7, A10, A13, and A17 models.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-IA16 is a high-performance digital AC input module designed for the ControlLogix platform. This module provides 16 input points, organized into two groups of 8 points each, and is engineered for reliable operation in industrial environments requiring 120V AC signal monitoring.Features
Sixteen (16) isolated input points for flexible signal monitoring.
Compatible with 74-132V AC voltage ranges at 50/60 Hz frequencies.
Programmable input delay times of 9 or 18 milliseconds to filter signal noise.
Low power consumption with a backplane current draw of 100 mA at 5.1V DC.
Seamless integration with the Allen-Bradley ControlLogix backplane architecture.
Technical Specifications
Module Type
Digital AC Input
Number of Inputs
16 (8 points per group)
Operating Voltage
74-132V AC, 50/60 Hz
Min. ON-state Current
5 mA @ 79V AC
Backplane Current (5.1V)
100 mA
Total Backplane Power
0.58 W
Cyclic Update Time
200 microseconds to 750 milliseconds
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-IA16 module to prevent electrical damage.
The module must be seated firmly into the chassis slot; secure using the integrated latching mechanism.
Use appropriate shielded cabling for input signals to minimize electromagnetic interference (EMI) in high-noise environments.
Verify that the field-side AC power supply matches the module input voltage specifications before applying power.
Maintain proper ventilation around the chassis to ensure optimal operating temperatures.
FAQWhat is the primary function of the 1756-IA16?The 1756-IA16 is a digital input module used to interface 120V AC field signals with a ControlLogix controller, allowing the system to monitor the status of external devices like switches, sensors, or relays.Can the input delay be adjusted on this module?Yes, the input delay time is programmable and can be set to either 9 or 18 milliseconds depending on the specific application requirements for signal debouncing.Is this module compatible with other ControlLogix chassis?Yes, the 1756-IA16 is designed to fit into any standard ControlLogix I/O chassis, provided there is an available slot and the power supply can support the additional current draw.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1746-ITV16 is a 16-point fast response DC sourcing input module designed for the SLC 500 programmable logic controller system. This module provides high-speed signal processing capabilities, making it suitable for applications requiring rapid input state detection and reliable performance in industrial control environments.Features
16-point input density for efficient I/O management.
Fast response design for high-speed signal capture.
Sourcing input configuration for 24 VDC systems.
Compatible with standard SLC 500 rack backplanes.
Low power consumption for reduced heat dissipation in control cabinets.
Technical Specifications
Product Model
1746-ITV16
Input Type
Fast Response DC Sourcing
Number of Inputs
16
Nominal Input Voltage
24 VDC
Input Voltage Range
10-30 VDC
Off-state Voltage (Max)
5 VDC
Backplane Current (5 VDC)
0.085 A
Power Consumption
3.6 Watts
Input Current
8 mA
Installation Guidelines
Ensure the SLC 500 system power is disconnected before installing or removing the module from the chassis.
Verify that the module is properly seated in the rack slot and the locking tabs are engaged.
Use appropriate wire gauges for the terminal blocks and ensure all connections are tight to prevent intermittent signals.
Maintain proper clearance around the module to allow for adequate ventilation and cooling.
Follow standard ESD (Electrostatic Discharge) precautions during handling to protect internal components.
Route signal wiring away from high-voltage cables or sources of electromagnetic interference (EMI) to maintain signal integrity.
FAQWhat is the primary difference between a standard input module and the 1746-ITV16?The 1746-ITV16 is specifically engineered as a fast response module, meaning it is designed to minimize input delay, which is critical for high-speed machine control or rapid process monitoring applications.Does this module require external power for the inputs?Yes, the 1746-ITV16 is a sourcing input module that requires a 24 VDC supply within the 10-30 VDC range to operate the input circuits.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Allen-Bradley 1746-P5 is a dedicated DC power supply module designed for use within the SLC 500 programmable logic controller system. This unit provides the necessary power to the backplane of the SLC 500 chassis, ensuring stable operation of the CPU, I/O modules, and communication adapters. It is specifically engineered to operate in environments utilizing a 125V DC input source, making it suitable for specialized industrial power architectures.Features
Designed for seamless integration with the Allen-Bradley SLC 500 modular chassis system.
Input voltage rating of 125V DC.
Provides 5 Amp output current capacity to support diverse I/O configurations.
Robust rack-mount design for secure installation in industrial control cabinets.
Reliable power distribution for critical automation control tasks.
Technical Specifications
Manufacturer
Allen-Bradley
Model Number
1746-P5
Alternate/Spare Model
1746-P5/A
Product Type
DC Power Supply Module
Input Voltage
125V DC
Output Current
5A
Mounting Type
Rack Mount (SLC 500 Chassis)
Weight
0.64 kg
Installation Guidelines
Ensure the power source is fully disconnected before installing or removing the module from the chassis.
Verify that the input voltage matches the 125V DC specification to prevent internal damage.
Slide the module into the designated slot on the SLC 500 rack, ensuring it is properly aligned with the backplane connector.
Secure the module using the integrated mounting screws to ensure vibration resistance and proper grounding.
Maintain adequate clearance around the module to allow for proper airflow and heat dissipation.
Handle with care to prevent electrostatic discharge (ESD) damage to the internal circuitry.
FAQIs the 1746-P5 still in production?No, this model has been discontinued by the manufacturer. We provide this unit as a reliable spare part for legacy system maintenance.What is the primary function of this module?The 1746-P5 acts as the power source for the SLC 500 rack, converting 125V DC input into the required voltage levels for the backplane modules.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-EN2TR is a high-performance EtherNet/IP communication module designed for the ControlLogix platform. This dual-port interface module facilitates robust industrial network connectivity, supporting linear, star, and device-level ring (DLR) topologies to ensure network redundancy without the requirement for external switches.Features
Dual RJ45 Ethernet ports for media redundancy.
Supports 128 TCP connections and 256 CIP connections.
Integrated USB port for local, temporary configuration.
Compatible with 10/100 Mbps communication speeds.
Supports multicast tag limits up to 32.
Designed for seamless integration within ControlLogix chassis environments.
ApplicationsThis module is engineered for demanding industrial environments, including:
Automated assembly, welding, and painting lines in the automotive industry.
SCADA and remote monitoring systems for water treatment and power generation.
High-speed packaging and filling operations in food and beverage production.
Marine and offshore control systems, including dynamic positioning.
Technical Specifications
Model
1756-EN2TR
Communication Ports
2 x RJ45 (Ethernet), 1 x USB (Configuration)
Power Requirements
5.1V DC @ 1A
Power Dissipation
5.1 W
Thermal Dissipation
17.4 BTU/hr
Operating Temperature
0 to 60 degC
Relative Humidity
5 to 95% (non-condensing)
Vibration
2 g @ 10 to 500 Hz
Isolation Voltage
30V (continuous)
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the communication module.
The module must be seated firmly in the chassis backplane; verify that the locking tabs are fully engaged.
Use shielded Category 5 cabling for Ethernet connections to minimize EMI interference.
The USB port is restricted to temporary configuration use only; do not utilize this port in hazardous environment locations.
When mixing with legacy 1756-ENBT modules in the same chassis, avoid using "Rack Optimized" communication formats to prevent potential data conflicts.
FAQDoes the 1756-EN2TR support redundant network topologies?Yes, the dual-port design allows the module to function as a node in a device-level ring (DLR) network, providing media redundancy.What is the primary purpose of the onboard USB port?The USB port is intended strictly for local, temporary configuration and maintenance tasks. It is not designed for permanent network communication or use in hazardous zones.Are there specific firmware requirements for this module?Yes, Series C modules require firmware revision 10.007 or later for proper operation.
The Allen-Bradley 1746-IG16 is a high-speed, 16-channel digital input module specifically engineered for the SLC 500 controller platform. Designed for applications requiring TTL (Transistor-Transistor Logic) level compatibility, this module facilitates the direct interface of 5V DC signals, making it an essential component for systems utilizing microcontrollers, high-speed sensors, and BCD-based equipment.Features
Sixteen (16) individual current-sourcing input channels.
Optimized for low-latency performance with a signal delay of 0.25 ms (ON) and 0.5 ms (OFF).
Integrated electro-optical isolation rated at 1500V AC to protect the SLC 500 backplane from field-side electrical interference.
Engineered for 5V DC logic levels, supporting an input voltage range of 4.5 to 5.5V DC.
Compact SLC 500 form factor for efficient rack mounting.
ApplicationsThis module is ideally suited for industrial environments where high-speed electronic signal acquisition is required. It is frequently employed in systems interfacing with digital encoders, micro-processor-based controllers, and other 5V DC logic devices that cannot be serviced by standard 24V DC input modules.Technical Specifications
Brand
Allen-Bradley
Product Series
SLC 500
Input Type
5V DC TTL Sourcing
Channel Count
16
Operating Voltage
4.5 to 5.5V DC
Signal Delay (ON/OFF)
0.25 ms / 0.5 ms
Backplane Current (5V)
140 mA
Power Dissipation
1 Watt
Isolation
1500V AC
Operating Temperature
0 to 60 degC
Installation Guidelines
Ensure the SLC 500 chassis power is disconnected before installing or removing the module.
Verify that all field wiring is properly routed away from high-voltage AC lines to minimize EMI.
Use appropriate shielded cabling for high-speed signal inputs to maintain data integrity.
Ensure the module is fully seated in the chassis slot and secured with the integrated locking tabs.
Maintain adequate ventilation within the enclosure to ensure the ambient temperature does not exceed 60 degC.
FAQIs the 1746-IG16 compatible with 24V DC signals?No, this module is strictly designed for 5V DC TTL signals. Applying 24V DC to the inputs will cause permanent damage to the module.Does this module require external power?The module draws its required power from the SLC 500 backplane (140 mA at 5V DC). It does not require a separate external power supply for the logic circuitry.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
DescriptionThe Allen-Bradley 1746-A2 is a two-slot modular chassis designed for the SLC 500 control platform. This compact unit serves as an efficient solution for small-scale I/O expansion or remote rack applications. By providing the necessary backplane communication and power distribution, the 1746-A2 ensures seamless integration of SLC 500 modules into your industrial control network.Features
Two-slot configuration for flexible I/O density.
Compatible with SLC 500 processors or remote I/O adapters (e.g., 1747-ASB, 1747-ACN) in Slot 0.
Supports system expansion up to a maximum of 30 slots when daisy-chained with additional chassis.
Robust backplane design supporting high current capacity for demanding I/O requirements.
Panel-mount design for secure installation in enclosures.
ApplicationsThis chassis is frequently deployed in distributed control architectures where space is limited. It is ideal for local expansion of small machine control systems or as a secondary rack in remote I/O configurations, allowing for modular growth of the SLC 500 system.Technical Specifications
Brand
Allen-Bradley
Product Line
SLC 500
Slot Capacity
2 Slots
Max Backplane Current (5.1V DC)
10 Amps
Max Backplane Current (24V DC)
2.88 Amps
Mounting
Panel Mount
Operating Temperature
0 to 60 degC
Storage Temperature
-40 to 85 degC
Relative Humidity
5 to 95% (Non-condensing)
Installation Guidelines
Ensure the chassis is mounted to a clean, flat, and vibration-resistant surface within an industrial enclosure.
Verify that the power supply is disconnected before installing or removing any modules from the chassis slots.
Maintain adequate clearance around the chassis to facilitate proper ventilation and prevent overheating.
When using multiple chassis, ensure that interconnect cables are properly seated and secured to prevent intermittent backplane communication errors.
Maintain proper grounding practices to protect against electromagnetic interference (EMI) and electrostatic discharge (ESD).
FAQCan I use this chassis for a standalone processor? Yes, the 1746-A2 is designed to house an SLC 500 processor or an I/O adapter in the first slot (Slot 0).How many chassis can be connected together? You can interconnect up to three chassis in a single local system, providing a total capacity of up to 30 slots.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-BATA is a high-capacity, industrial-grade lithium battery assembly engineered specifically for use with the 1756-BATM externally mounted battery module. This component provides the necessary power backup for volatile memory retention in ControlLogix controller systems, particularly in applications where extended memory hold-up times or elevated operating temperatures are present.Features
Dual-Cell Configuration: Features two primary lithium cells connected in series to ensure reliable power delivery.
Extended Capacity: Provides a nominal capacity of 19,000 mAh (19 Ah), significantly outperforming standard internal controller batteries.
Stable Output: Delivers a consistent 3.6V DC operating voltage.
Robust Chemistry: Utilizes Lithium-Thionyl Chloride (Li-SOCl2) technology for superior energy density and low self-discharge characteristics.
Technical Specifications
Brand
Allen-Bradley
Part Number
1756-BATA
Chemistry
Lithium-Thionyl Chloride (Li-SOCl2)
Voltage
3.6V DC
Capacity
19,000 mAh (19 Ah)
Lithium Content
Approximately 10 grams total
Operating Temperature
0 to 60 degC (32 to 140 degF)
Installation Guidelines
Module Compatibility: This battery is designed exclusively for the 1756-BATM external battery module. Do not attempt to install directly into a processor faceplate.
Handling: Handle with care to prevent short-circuiting the terminals. Store in a cool, dry environment away from direct heat sources.
Safety: Follow facility hazardous materials protocols for disposal of lithium batteries. Do not incinerate, recharge, or disassemble.
Replacement: Ensure the 1756-BATM module is properly secured and the cable is correctly seated when performing a battery swap.
FAQIs the 1756-BATA compatible with standard ControlLogix processors?The 1756-BATA is designed specifically for the 1756-BATM external battery module. It is not intended to be installed directly into the battery slot of a standard ControlLogix processor faceplate.What is the primary benefit of using this high-capacity battery?The 1756-BATA provides a significantly larger energy reservoir compared to standard on-board batteries, making it ideal for systems with large memory requirements or those operating in environments where standard batteries may experience shortened service lives due to temperature.
نحن نقدم خدمة التوصيل في اليوم التالي من الاثنين إلى الجمعة إذا كان المنتج موجودًا في المخزون والاستثناءات في أيام العطلات.
عطلات نهاية الأسبوع
نحن لا نقدم أي تسليمات في عطلة نهاية الأسبوع.
دولي
نوفر خدمة التوصيل في اليوم التالي، حسب موقعك. تحقق من حالة طلبك عبر هذا الرابط.
The Allen-Bradley 1756-WS is a high-performance weigh scale interface module engineered for the ControlLogix platform. Developed through a partnership with Hardy Process Solutions, this module integrates directly into the ControlLogix chassis, enabling seamless communication between industrial load cells and the controller. By eliminating the necessity for external signal conditioners or transmitters, it streamlines system architecture and reduces wiring complexity in critical weighing operations.Features
Direct integration with ControlLogix backplane for high-speed data exchange.
Single-channel design capable of supporting up to four 350-Ohm load cells.
High-speed processing with an update rate of 50 updates per second for real-time monitoring.
Exceptional measurement precision featuring 0.0015% of full-scale non-linearity.
Supports advanced industrial weighing tasks including batching, filling, and vessel monitoring.
ApplicationsThis module is ideal for demanding industrial environments requiring precise force measurement and weight control. It is commonly utilized in automated batching systems, liquid filling lines, hopper and tank weighing, and general-purpose force measurement applications where high repeatability and accuracy are mandatory.Technical Specifications
Brand
Allen-Bradley (Hardy Process Solutions)
Platform
ControlLogix
Module Type
Weigh Scale / Load Cell Module
Channels
Single Channel
Load Cell Support
Up to four 350-Ohm load cells
Update Rate
50 updates per second
Non-Linearity
0.0015% of Full Scale
Excitation Voltage
5V DC
Common-Mode Voltage
2.5V DC maximum
Operating Temperature
0 to 60 degC (32 to 140 degF)
Storage Temperature
-40 to 85 degC (-40 to 185 degF)
Relative Humidity
0% to 90% non-condensing
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-WS module.
Install the module into any available slot within the ControlLogix I/O chassis.
Use shielded twisted-pair cabling for load cell connections to minimize electromagnetic interference (EMI).
Maintain proper grounding practices for the chassis backplane to ensure signal integrity.
Verify that the load cell wiring matches the terminal block pinout configuration to prevent excitation voltage errors.
FAQDoes this module require an external transmitter?No, the 1756-WS is designed to connect directly to load cells, acting as the interface to the ControlLogix backplane without external signal conditioning hardware.How many load cells can be connected?The module supports a single channel, which can accommodate up to four 350-Ohm load cells connected in parallel.
DescriptionThe Allen-Bradley 1756-CN2 is a high-performance communication module designed for the ControlLogix platform, specifically engineered to facilitate reliable data transfer over a ControlNet network. This module serves as a critical bridge for industrial automation systems, allowing for seamless integration and real-time communication between controllers, I/O, and other devices within the ControlLogix architecture.Features
Supports standard media for robust ControlNet connectivity.
Provides high-speed data transfer rates of 5 Mbps.
Supports up to 128 Logix connections for complex system configurations.
Capable of managing up to 99 nodes on a single network.
Designed for seamless integration within standard 1756 ControlLogix chassis.
Technical Specifications
Product Model
1756-CN2
Communication Type
ControlNet
Data Rate
5 Mbps
Logix Connections
128
Maximum Nodes
99
Manufacturer
Allen-Bradley
Installation Guidelines
Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-CN2 module to prevent electrical damage or system faults.
Verify that the module is fully seated in the chassis slot and the top and bottom latches are securely engaged.
Follow standard industrial grounding practices to minimize EMI and ensure signal integrity across the ControlNet network.
Use appropriate ControlNet cabling and ensure proper termination at both ends of the network trunk to maintain communication stability.
Handle the module using ESD-safe practices to protect sensitive internal circuitry.
FAQWhat is the primary function of the 1756-CN2?The 1756-CN2 is a communication interface module that allows a ControlLogix controller to communicate over a ControlNet network, supporting high-speed data exchange and multi-node connectivity.How many nodes can this module support?This specific model is capable of supporting up to 99 nodes on the ControlNet network.Is the 1756-CN2 compatible with all ControlLogix chassis?Yes, it is designed for standard 1756 ControlLogix chassis. Always ensure your firmware and project configuration are compatible with this specific hardware revision.
