Description
The Allen-Bradley 1756-EN2TSC is a high-performance communication module designed for the ControlLogix platform. This module functions as an EtherNet/IP bridge, providing secure connectivity through integrated VPN capabilities. It is engineered to facilitate robust communication within industrial automation environments, supporting high-speed data exchange and reliable network integration for complex control systems.
Features
- Single-port EtherNet/IP interface for streamlined network connectivity.
- Integrated VPN support for secure remote communication and data protection.
- High-performance processing designed for demanding ControlLogix applications.
- Supports up to 128 TCP/IP connections, enabling extensive device integration.
- Operates at 10/100 Mbps data rates to suit standard industrial Ethernet requirements.
Applications
This module is typically deployed in manufacturing and process control environments where secure, high-bandwidth communication between the ControlLogix controller and remote devices or supervisory systems is required. It is suitable for applications involving distributed I/O, remote diagnostics, and secure plant-floor network management.
Technical Specifications
| Model Number |
1756-EN2TSC |
| Product Type |
EtherNet/IP Communication Bridge |
| Communication Port |
Single Port |
| Network Speed |
10/100 Mbps |
| TCP/IP Connections |
Up to 128 |
| VPN Capability |
Integrated Secure Communication |
| Weight |
0.24 kg |
Installation Guidelines
- Ensure the ControlLogix chassis is powered down before installing or removing the 1756-EN2TSC module to prevent electrical damage.
- Slide the module into the designated slot in the chassis, ensuring it is properly aligned with the backplane connector.
- Secure the module using the top and bottom locking latches to maintain a solid connection and proper grounding.
- Use shielded Ethernet cabling for all connections to minimize electromagnetic interference (EMI) in industrial environments.
- Maintain proper ventilation in the control cabinet to ensure the module operates within its specified temperature range.
- Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect sensitive internal components.
FAQ
What is the primary function of the 1756-EN2TSC?
The 1756-EN2TSC is a ControlLogix communication module that provides EtherNet/IP connectivity with added VPN security features for secure remote access and data transfer.
How many TCP/IP connections can this module handle?
This module supports up to 128 concurrent TCP/IP connections, allowing for significant scalability in network communication.
Does this module require a specific chassis?
Yes, it is designed for use within the Allen-Bradley ControlLogix chassis system.
