Yokogawa S2BN1D-11130 N-IO Base Plate
The Yokogawa S2BN1D-11130, also cataloged as the S2BN1D base plate, operates as a dedicated hardware component for signal isolation and I/O module support within ProSafe-RS and CENTUM VP control networks.
Hardware Specifications
Parameter
Specification
ModelBrand
Yokogawa S2BN1D-11130
Origin
Japan
Weight
1.4 kg
Dimensions
Standard DIN rail / wall mount footprint
OperatingTemp
-40 degC to +70 degC
PowerConsumption
24 VDC, up to 11 A load
Total I/O Channels
16 per base plate
Module Support
Single or dual-redundant N-IO modules
Communication Interface
N-ESB Bus
Mounting
DIN rail or vertical wall mount
Withstanding Voltage
1500 VAC, 1 min between power input and ground
Field Wiring Connection
Pressure clamp terminals
Grounding Terminal
M3 screw
Process Control Network Features
Supports 4-20 mA HART loop protocol for analog modules.
Channel-to-channel isolation ensures signal integrity under dense module installations.
Cold junction compensation (CJC) maintained for all thermocouple inputs, allowing accurate temperature measurement without external adjustments.
Compatible with FOUNDATION Fieldbus and PROFIBUS PA connectivity for hybrid analog/digital configurations.
Frequently Asked Questions
Q: Can I hot-swap N-IO modules on this base plate? A: Yes, the integrated disconnecting terminals allow hot-swapping of individual I/O modules without interrupting adjacent circuits, provided field power is within rated limits.
Q: What is the maximum cumulative current for connected I/O modules? A: The base plate supports up to 11 A of total field load distributed across all channels.
Q: Is the base plate compatible with explosion-proof installations? A: Yes, it meets international hazardous area certifications, including ATEX and IECEx, for intrinsic safety.
Field Installation Guidelines
Mount DIN rail securely or use four M4 screws for vertical wall installation.
Connect field wiring to pressure clamp terminals, ensuring conductor ends are fully inserted.
Verify grounding via the M3 terminal before energizing the system.
Maintain separation between high-voltage and signal lines to prevent cross-talk.
Confirm the orientation of I/O modules according to the labeling to avoid bus misalignment.
