Honeywell TC-SMPD01 SIM FTA Power Adapter Module

Configured for SIM power distribution and serial interface support in Honeywell Experion PKS and TDC3000 platforms, the Honeywell TC-SMPD01 (TC-SMPD01 SIM FTA Power Adapter Module) provides direct physical power execution for System Interface Modules and Field Termination Assemblies.

Hardware Specifications

Parameter	Specification
Model	TC-SMPD01
Brand	Honeywell
Origin	USA
Product Type	SIM / FTA Power Adapter Modules
System Compatibility	Honeywell Experion PKS C200/C300, TDC3000
Functional Role	24 VDC regulated power distribution for SIM and FTA assemblies
Input Voltage	24 VDC nominal
Output Type	Regulated DC power supply output
Supported Interface	Honeywell SIM serial interface and FTA power connection
Compatible Modules	Honeywell Serial Interface Modules and Modbus-related FTAs
Ports	Dual serial interface support through FTA power adapter configuration
Weight	Approx. 0.35 kg to 1.0 kg including assembly packaging
Dimensions	Approx. 110 mm x 90 mm x 60 mm
Power Consumption	Dependent on connected SIM and FTA load requirements
Environmental Protection	Available conformal coated variant TK-SMPD01 for harsh environments

DCS Signal Interface and Power Distribution Characteristics

The TC-SMPD01 provides regulated 24 VDC power delivery for Honeywell SIM assemblies and associated Field Termination Assemblies. The module maintains electrical separation between the controller-side serial interface structure and field termination equipment.

For Honeywell process control architectures, the module supports integration with serial communication-based field interfaces. It is designed for connection with DCS I/O infrastructure where stable loop power distribution and controlled signal transmission are required.

The module architecture is compatible with Honeywell instrumentation environments using communication interfaces such as Modbus-based field connections. Channel-to-channel isolation practices and controlled wiring layouts are applied to reduce interference between field signal paths and power distribution circuits.

Frequently Asked Questions

Q: What is the primary electrical function of the Honeywell TC-SMPD01?
A: The TC-SMPD01 provides regulated 24 VDC power distribution for Honeywell SIM modules and connected FTA assemblies.

Q: Can the TC-SMPD01 directly replace a controller communication module?
A: No. The TC-SMPD01 functions as a SIM FTA power adapter and does not operate as a standalone controller communication processor.

Q: Is conformal coating available for this module family?
A: Yes. The TK-SMPD01 variant is identified as a conformally coated version intended for environments requiring additional board-level protection.

Field Installation Guidelines

• Install the TC-SMPD01 according to Honeywell system cabinet wiring documentation and approved chassis layout requirements.
• Verify 24 VDC supply polarity before connecting power terminals to prevent electrical damage.
• Separate DC power wiring from high-voltage AC circuits and high-noise equipment cabling.
• Use shielded communication cables where required by the installed SIM and FTA configuration.
• Connect cable shields according to the cabinet grounding design to minimize electromagnetic interference.
• Confirm connector seating and mechanical locking before system energization.
• Verify SIM and FTA power loads remain within the supported power distribution capacity of the installation.
