ABB SPS02 Power Supply Module

Configured for DC power conversion and control system supply regulation, the ABB SPS02 (SPS02 Power Supply Module) provides direct electrical conversion for ABB industrial control platforms. The module accepts AC or DC input power and delivers a regulated 24 VDC output with 0.5 A current capacity for connected automation hardware.

Hardware Specifications

Parameter	Specification
Model	SPS02
Brand	ABB
Product Type	Power Supply Module
Origin	Sweden
Weight	0.38 kg
Dimensions	10.2 x 2.5 x 17.8 cm
Operating Temp	-25 deg C to +70 deg C
Storage Temp	-40 deg C to +85 deg C
Humidity	5-95% non-condensing
Power Consumption	Approximately 12 W output rating
AC Input Voltage	85-264 VAC
DC Input Voltage	100-300 VDC
Output Voltage	24 VDC
Output Current	0.5 A (500 mA)
Efficiency	>=85%
Inrush Current	<20 A
Isolation Voltage	3 kVAC

ABB Industrial Control Power Conversion Features

The ABB SPS02 applies industrial power conversion technology for PLC and automation system power distribution. The module supports a wide AC input range from 85 VAC to 264 VAC and accepts 100 VDC to 300 VDC input sources. Therefore, it can operate with different plant power architectures.

The 24 VDC output supplies connected control devices with a rated current of 0.5 A. Additionally, the module provides electrical isolation up to 3 kVAC between input and output circuits to separate power domains.

The SPS02 design supports ABB industrial control environments with compact I/O density requirements. Furthermore, its firmware flash compatibility and backplane-oriented power architecture allow integration with ABB control system hardware where applicable.

Frequently Asked Questions

Q: What input power sources does the ABB SPS02 support?
A: The SPS02 supports 85-264 VAC input and 100-300 VDC input configurations.

Q: What output power does the SPS02 provide?
A: The module provides a 24 VDC output with a rated current of 0.5 A and an approximate 12 W power rating.

Q: Does the SPS02 provide electrical isolation?
A: Yes. The module provides 3 kVAC isolation voltage between input and output circuits.

Field Installation Guidelines

• Install the ABB SPS02 in a suitable control cabinet environment with sufficient airflow around the module.
• Verify that the input voltage matches the specified AC or DC operating range before energizing the unit.
• Use correctly rated wiring for input and output power terminals according to the installation design.
• Separate power wiring from sensitive signal cables to reduce electrical interference.
• Connect protective grounding according to the cabinet grounding scheme and applicable electrical standards.
• Inspect terminal connections periodically to prevent loose wiring and abnormal heating conditions.
