ABB SD834 3BSC610067R1 Power Supply Device

Configured for 24 VDC power conversion and industrial DC supply distribution in ABB automation systems, the ABB SD834 3BSC610067R1 (SD834 Power Supply Device) provides direct electrical conversion from AC/DC input sources to a regulated 24 VDC output supply.

Hardware Specifications

Parameter	Specification
Model	SD834 3BSC610067R1
Brand	ABB
Product Type	Power Supply Device
Origin	Sweden
Weight	1.3 kg
Dimensions	15.5 x 23 x 36 cm (estimated shipping size)
Operating Temp	Not specified
Power Consumption	547/568 VA rated input power
Input Voltage	100-240 VAC or 110-150 VDC
Output Voltage	24 VDC
Rated Output Current	20 A
Rated Output Power	480 W
Efficiency	92.4/93.9 %
Application	SELV and PELV systems

ABB Industrial Power Architecture and Control System Integration

The ABB SD834 3BSC610067R1 operates as a switch-mode power supply component within ABB industrial control architectures. It converts mains AC or DC input power into a regulated 24 VDC output used for control equipment, I/O modules, and automation system components.

Furthermore, the SD834 supports SELV and PELV applications by maintaining separated low-voltage output characteristics. The module design fits ABB power distribution structures where stable DC voltage delivery and load capacity management are required.

The unit supports ABB system power configurations with high output density. Therefore, its 20 A rated output current allows connection to multiple automation devices while maintaining defined electrical load limits.

Frequently Asked Questions

Q: What input voltage ranges does the ABB SD834 3BSC610067R1 support?
A: The SD834 accepts 100-240 VAC input or 110-150 VDC input sources according to the provided technical specifications.

Q: What output parameters are provided by the SD834 power supply device?
A: The module provides a 24 VDC output with a rated current of 20 A and rated output power of 480 W.

Q: Can the SD834 be used for SELV and PELV applications?
A: Yes. The SD834 is specified for SELV and PELV applications within compatible ABB industrial automation installations.

Field Installation Guidelines

• Install the SD834 in an enclosure that provides suitable mechanical protection and environmental control.
• Verify that input voltage wiring matches the specified AC or DC supply range before energizing the module.
• Use appropriate cable sizing based on the 20 A output current requirement and connected load conditions.
• Separate power wiring from sensitive signal cables to reduce electrical interference.
• Connect protective grounding according to the applicable industrial electrical installation standards.
• Confirm output polarity before connecting downstream 24 VDC devices.
• Check ventilation clearance and mounting conditions according to the system cabinet design requirements.
