Description

The Schneider Electric XBTF034510 is a high-performance operator interface terminal from the Magelis series. Designed for industrial visualization and control, this unit features a 10.4-inch touch screen interface, providing clear data display and intuitive input capabilities for machine operators. Although this model has been discontinued by the manufacturer, it remains a critical component for maintaining legacy automation systems and human-machine interface (HMI) stations.

Features

• Large 10.4-inch display for enhanced operator visibility
• Integrated touch screen interface for streamlined process control
• Designed for 24 VDC power supply environments
• Robust construction suitable for demanding plant-floor conditions
• Part of the established Magelis series operator interface ecosystem

Technical Specifications

Manufacturer	Schneider Electric
Model Number	XBTF034510
Series	Magelis
Display Size	10.4 inches
Supply Voltage	24 VDC
Power Consumption	35 W
Status	Discontinued by Manufacturer

Installation Guidelines

• Ensure the control cabinet is properly ventilated to dissipate the 35 W heat load generated during operation.
• Verify that the 24 VDC power source is stable and filtered to prevent signal noise or premature component failure.
• Mount the panel in a cutout that meets the manufacturer's specified dimensions to maintain the integrity of the bezel seal.
• Use appropriate ESD precautions when handling the terminal to protect internal circuitry.
• Confirm that all communication cables are shielded and routed away from high-voltage power lines to minimize electromagnetic interference.

FAQ

Is the XBTF034510 still supported by Schneider Electric?

This specific model is classified as discontinued by the manufacturer. While it may no longer be available for direct purchase from new stock, it is often sourced through specialized industrial suppliers to support existing installations.

What power supply is required for this operator panel?

The XBTF034510 is designed to operate on a 24 VDC power supply with a power consumption of 35 W.
