The Schneider Electric ATV610D30N4 is a high-performance variable speed drive from the Easy Altivar 610 series. Designed for industrial motor control applications, this drive provides reliable speed regulation and energy efficiency for 3-phase electrical systems. It features a standard design optimized for forced convection cooling, ensuring stable operation in demanding environments.
Features
- Supports 3-phase supply voltage ranging from 380 V to 460 V.
- Integrated Modbus serial communication protocol for seamless system integration.
- Offers 16 preset speeds for flexible process control.
- Adjustable switching frequency between 2 kHz and 12 kHz, with a nominal setting of 4 kHz.
- Wide output frequency range from 0.1 Hz to 500 Hz.
Technical Specifications
| Product Model |
ATV610D30N4 |
| Product Range |
Easy Altivar 610 |
| Supply Frequency |
50 to 60 Hz (+/- 5%) |
| Number of Phases |
3-phase |
| Rated Supply Voltage |
380 to 460 V (-15% to +10%) |
| Output Frequency |
0.1 to 500 Hz |
| Nominal Switching Frequency |
4 kHz |
| Communication Protocol |
Modbus Serial |
Installation Guidelines
- Ensure the drive is mounted vertically on a flat, non-flammable surface to maintain proper airflow for the forced convection cooling system.
- Maintain adequate clearance around the unit to prevent overheating.
- Verify that the supply voltage matches the rated input range of 380-460V before applying power.
- Use shielded cables for communication and control signals to minimize EMI interference.
- Always disconnect the main power supply and wait for the internal capacitors to discharge before performing any wiring or maintenance.
- Ensure proper grounding of the drive chassis to a common plant earth point to ensure safety and signal integrity.
FAQ
What is the primary application for the ATV610D30N4?
This variable speed drive is designed for controlling the speed and torque of 3-phase induction motors in various industrial processes, such as pumps, fans, and conveyors, where precise speed control is required.
Does this drive support communication with other devices?
Yes, the ATV610D30N4 includes a built-in Modbus serial communication port, allowing it to be integrated into larger automation networks for remote monitoring and control.
