ABB PM891K01 Processor Unit

The ABB PM891K01, also cataloged as the PM891K01 Processor Unit, provides direct processing execution and controller communication within ABB System 800xA and AC 800M controller platforms. The unit includes the PM891 CPU module, TB850 CEX-Bus Terminator, TB853 RCU Control Link Terminator, and power plug assembly.

Hardware Specifications

Parameter	Specification
Model	PM891K01
Spare Model	3BSE053241R1
Brand	ABB
Product Type	Processor Unit
Series	AC 800M Controller Family
System Platform	ABB System 800xA
Origin	Sweden
Weight	1.64 kg
Dimensions	20 x 18.7 x 10 cm (shipping size)
Included Components	PM891 CPU Module, TB850 CEX-Bus Terminator, TB853 RCU Control Link Terminator, Power Plug
Communication Interface	CEX-Bus and RCU Control Link interfaces
Tariff Code	8537101190

Backplane Bus Communication and Controller Integration

The PM891K01 uses ABB AC 800M controller architecture for processor execution and internal module communication. The CPU module manages application processing, controller diagnostics, and communication services through the controller backplane structure.

Furthermore, the processor unit supports ABB controller configuration through System 800xA engineering environments. The CEX-Bus interface allows connection of compatible communication and expansion modules, while the included TB850 terminator maintains correct bus termination conditions.

The PM891K01 follows ABB industrial control hardware design principles, including firmware flash compatibility management and I/O density scaling within AC 800M-based control systems.

Frequently Asked Questions

Q: What components are included with the ABB PM891K01 processor unit?
A: The PM891K01 package includes the PM891 CPU module, TB850 CEX-Bus Terminator, TB853 RCU Control Link Terminator, and power plug.

Q: Can the PM891K01 operate as a standalone I/O module?
A: No. The PM891K01 functions as a processor unit within ABB AC 800M controller configurations and requires compatible controller hardware architecture.

Q: What is the function of the TB850 and TB853 components supplied with this unit?
A: TB850 provides CEX-Bus termination, while TB853 provides RCU Control Link termination to maintain proper communication line conditions.

Field Installation Guidelines

Install the PM891K01 inside the designated ABB AC 800M controller assembly according to the system hardware configuration.

Ensure the processor module is correctly seated on the controller backplane before applying power. Verify that all termination components, including TB850 and TB853, are installed according to the required bus topology.

Maintain proper cabinet grounding and separate signal wiring from high-voltage power cables to reduce electrical interference. Use approved industrial wiring practices for communication connections and verify connector engagement before system startup.
