Description
The IS200DSPXH1D is a high-performance Digital Signal Processor (DSP) board manufactured by General Electric for the Mark VIe control system. This control board is engineered to provide precise signal processing capabilities within industrial automation environments, operating at a clock speed of 60 MHz. It serves as a critical component for managing high-speed data acquisition and control logic execution in complex turbine or power generation control architectures.
Features
- Integrated 60 MHz processor for real-time signal processing tasks.
- Equipped with 512 kB of onboard Flash memory.
- Designed for integration into the GE Mark VIe control platform.
- Robust construction with 500 V DC isolation to ensure signal integrity and system protection.
- Low power consumption profile with a typical draw of 15 W.
Technical Specifications
| Model |
IS200DSPXH1D |
| Spare Model |
IS200DSPXH1DBC |
| Processor Speed |
60 MHz |
| Memory |
512 kB Flash |
| Power Supply |
+5 V DC |
| Power Consumption |
15 W (typical) |
| Isolation Rating |
500 V DC |
| Operating Temperature |
0 degC to +60 degC |
| Relative Humidity |
5 to 95 % RH (non-condensing) |
Installation Guidelines
- Ensure the control rack is powered down before inserting or removing the IS200DSPXH1D board to prevent electrical arcs or damage to the backplane connectors.
- Handle the module using proper ESD (Electrostatic Discharge) mitigation techniques, such as wearing a grounded wrist strap.
- Verify that the board is fully seated in the designated slot of the Mark VIe rack to ensure proper contact with the system bus.
- Maintain adequate ventilation within the cabinet to keep the ambient temperature within the 0 to +60 degC range.
- Route signal cables away from high-voltage lines or high-EMI sources to maintain signal accuracy.
FAQ
What is the primary function of the IS200DSPXH1D?
This board acts as a Digital Signal Processor, responsible for executing high-speed calculations and signal management within the Mark VIe control system.
Is this board compatible with the IS200DSPXH1DBC?
Yes, the IS200DSPXH1DBC is listed as a spare model for this unit, indicating functional interchangeability in most Mark VIe configurations.
What are the power requirements for this board?
The module operates on a +5 V DC power supply and typically consumes 15 W during normal operation.
