GE IS200BPPBH2BJD SmartPack 200 Motor Starter Module

The GE IS200BPPBH2BJD, also cataloged as the IS200BPPBH2B Motor Starter Module, operates as a dedicated hardware component for three-phase motor control and protection within SmartPack 200 control platforms. The module executes AC motor switching, monitoring, and protective functions with 460 V AC operation, 22 A current handling, and RS-485 communication capability.

Hardware Specifications

Parameter	Specification
Model	IS200BPPBH2BJD
Brand	GE
Origin	United States
Weight	0.35 kg
Dimensions	115 x 70 x 45 mm
Operating Temp	-20 to +55 deg C
Power Consumption	Not specified
Product Type	Motor Starter Module
Series	SmartPack 200
Voltage Rating	460 V AC
Current Rating	22 A
Rated Power	10 kW
Motor Type	Three-phase asynchronous motor
Communication Interface	RS-485
Protection Functions	Short circuit, overload, phase loss, overspeed, ground fault
Humidity Range	5% to 95% non-condensing
Protection Level	IP20

Industrial Control and SmartPack Motor Protection Features

The IS200BPPBH2BJD integrates motor control and protective monitoring functions for three-phase AC motor applications. The module processes electrical operating conditions and provides protection responses for overload, short circuit, phase loss, overspeed, and ground fault conditions.

The SmartPack 200 series architecture supports industrial communication through the RS-485 interface, allowing data exchange with supervisory control systems. The communication path is configured for status monitoring, control commands, and operational diagnostics.

The module uses industrial control hardware design principles including I/O density scaling and firmware flash compatibility within supported SmartPack 200 configurations. Installation requires verification of controller compatibility, communication parameters, and motor electrical ratings before commissioning.

Frequently Asked Questions

Q: What motor electrical parameters are supported by the IS200BPPBH2BJD?
A: The module supports three-phase asynchronous motor control with a rated voltage of 460 V AC and a current rating of 22 A.

Q: What communication interface is available on the IS200BPPBH2BJD?
A: The module provides an RS-485 communication interface for connection with industrial monitoring or supervisory systems.

Q: What protection functions are integrated into this motor starter module?
A: The module provides protection functions including overload, short circuit, phase loss, overspeed, and ground fault monitoring.

Field Installation Guidelines

Install the IS200BPPBH2BJD in an enclosure that maintains the specified environmental conditions and provides appropriate mechanical protection. Verify terminal wiring, motor phase connections, and control circuit isolation before energizing the system.

Route RS-485 communication cables separately from high-current motor power conductors to reduce electromagnetic interference. Apply proper cable shielding and connect shield layers according to the grounding practice defined by the control system design.

Confirm that the module mounting arrangement maintains adequate ventilation clearance and that all protective earth connections are properly installed before operational testing.
