ICS Triplex T8193 Trusted Digital Input Module

Configured for digital input interface protection and controller slot shielding in the Trusted safety platform, the ICS Triplex T8193 (T8193 Digital Input Module) provides direct physical integration. It functions as a three-slot shield assembly associated with the Trusted controller architecture, where it protects unused controller positions, preserves airflow characteristics, and supports the mechanical integrity required by the backplane assembly.

Suffix Breakdown & Model Matrix

The supplied documentation identifies a single catalog number: T8193. No official suffix variants or ordering matrix are specified in the available manufacturer information.

Hardware Specifications

Parameter	Specification
Model	T8193
Brand	ICS Triplex
Product Type	Digital Input Module / Controller Shield
Trusted Series	Trusted TMR
Function	Shield for Controller Module
Slot Width	Three slot width
Origin	USA
Shipping Location	Xiamen, China
Weight	0.38 kg
Dimensions	5.1 x 10.2 x 7.0 cm
Operating Temp	-40 deg C to +85 deg C
Storage Temp	-40 deg C to +85 deg C
Humidity	5 % to 95 % RH, non-condensing
Typical Attenuation	>= 60 dB at 100 MHz
Power Consumption	Not specified by manufacturer
Tariff Code	8537101190

Triple Modular Redundancy Architecture Considerations

The Trusted platform employs a triple modular redundancy (TMR) 2oo3 architecture to support fault-tolerant safety control. Accordingly, the T8193 is designed to fit the mechanical arrangement of the Trusted controller assembly while maintaining enclosure continuity around controller positions.

Although the T8193 does not process field signals, its installation contributes to the physical configuration expected by the Trusted hardware platform. Proper slot coverage also helps maintain airflow through the chassis and limits unnecessary exposure of internal backplane components during operation and maintenance.

Frequently Asked Questions

Q: Can the T8193 be installed while adjacent Trusted modules remain energized?

A: Installation procedures should follow the system maintenance instructions provided for the Trusted platform. Always observe plant lockout procedures and verify the permitted maintenance condition before inserting or removing any hardware.

Q: Does the T8193 require electrical field wiring?

A: No. The T8193 functions as a mechanical shield for the controller assembly and does not provide field signal termination or electrical I/O connections.

Q: Does the T8193 consume power from the backplane?

A: The available product documentation does not specify any electrical power consumption for this component.

Field Installation Guidelines

• Verify that the target controller position matches the designated three-slot mounting location before installation.
• Remove dust or foreign material from the chassis opening before fitting the shield.
• Tighten retaining hardware according to the system maintenance manual. Avoid excessive mechanical force during installation.
• Keep unused controller positions covered to reduce contamination inside the enclosure.
• Route nearby field wiring separately from ventilation openings so airflow through the chassis remains unobstructed.
• Inspect adjacent module latches and backplane connectors before returning the system to service.
