ICS Triplex T3481 High Density Guarded Output 24 VDC

The ICS Triplex T3481, also cataloged as the T3481 High Density Guarded Output Module, provides 24 VDC guarded output switching within the ICS Triplex Trusted safety control architecture. The module controls discrete output circuits while supporting fault containment through the system's safety-oriented hardware design.

Hardware Specifications

Parameter	Specification
Model	T3481
Brand	ICS Triplex
Product Type	High Density Guarded Output 24 VDC
Application	Guarded digital output control
Output Type	24 VDC guarded output
Safety Architecture	ICS Triplex safety control architecture
Origin	Not specified in supplied data
Weight	1.82 kg
Dimensions	Estimated shipping size: 3.2 x 26.5 x 35.8 cm
Manufacturer Status	Discontinued by manufacturer

Safety Output and Fault Handling

The T3481 operates as a guarded digital output component within an ICS Triplex safety system. Its 24 VDC output circuitry interfaces the controller with discrete field loads.

The system architecture supports fault detection and containment at the module and system levels. However, the supplied data does not specify channel count, output current rating, isolation voltage, diagnostic coverage, or individual channel fault response.

The T3481 should therefore remain within the documented Trusted system configuration. Field wiring should follow the applicable system installation documentation and approved termination hardware.

Frequently Asked Questions (FAQ)

Q: Is the T3481 a 24 VDC output module?
A: Yes. The supplied specification identifies the T3481 as a High Density Guarded Output 24 VDC module.

Q: Does the supplied data specify the output current rating?
A: No. The available information does not state the per-channel or total output current rating.

Q: Is the T3481 currently manufactured?
A: No. The supplied information identifies the T3481 as discontinued by the manufacturer.

Field Installation Guidelines

• Install the module only in the designated ICS Triplex system hardware position.
• Verify the rack, termination assembly, and field wiring configuration before energizing the module.
• Route 24 VDC output wiring separately from high-voltage and high-noise conductors where practical.
• Maintain correct polarity and verify field circuit continuity before applying power.
• Connect cable shields according to the system grounding design and avoid creating unintended ground loops.
• Do not substitute output modules without confirming hardware and system configuration compatibility.
• Because the manufacturer has discontinued the T3481, verify the installed system documentation before replacement or configuration changes.
