Honeywell MU-TAIH23 High-Level Analog Input Termination Assembly

Configured for analog signal termination and conditioning in Honeywell TDC 3000 / TPS control system platforms, the Honeywell MU-TAIH23 (MU-TAIH23 High-Level Analog Input Termination Assembly) provides direct field signal interface execution for 4-20 mA and 1-5 VDC input circuits.

Hardware Specifications

Parameter	Specification
Model	MU-TAIH23
Brand	Honeywell
Origin	USA
Module Type	High-Level Analog Input Termination Assembly (FTA)
System Platform	Honeywell TDC 3000 / TPS series
Channel Count	16 analog input channels (typical configuration)
Input Signal Type	4-20 mA DC, 1-5 VDC analog signals
Signal Function	Field analog signal termination, conditioning, and routing
Isolation	Channel-to-channel and channel-to-ground galvanic isolation
Power Supply	24 VDC system power or external loop power depending on configuration
Operating Temp	0 deg C to 60 deg C
Storage Temp	-40 deg C to 85 deg C
Relative Humidity	5% to 95% RH, non-condensing
Power Consumption	Not specified
Mounting Type	FTA mounting rack or DIN rail installation
Protection Features	Surge protection and signal conditioning circuits

4-20 mA HART Loop and Channel Isolation Characteristics

The MU-TAIH23 interfaces with standard process instrumentation signals through high-level analog input termination circuits. It conditions incoming field signals before transmission to the Honeywell I/O processing hardware. Therefore, the assembly maintains signal integrity through channel isolation and electrical protection.

For instrumentation loops using 4-20 mA HART communication protocols, the termination assembly supports the physical connection requirements between field transmitters and DCS input channels. Additionally, channel-to-channel isolation reduces electrical interference between independent measurement loops.

The module design supports analog measurement applications requiring stable signal conversion, loop protection, and controlled field wiring termination.

Frequently Asked Questions

Q: What type of field signals does the Honeywell MU-TAIH23 accept?
A: The MU-TAIH23 accepts standard high-level analog input signals, including 4-20 mA DC and 1-5 VDC signals from field transmitters and sensors.

Q: Does the MU-TAIH23 provide electrical isolation between input channels?
A: The MU-TAIH23 supports channel-to-channel and channel-to-ground galvanic isolation to separate field measurement circuits and reduce signal interference.

Q: Can the MU-TAIH23 be replaced during system operation?
A: Hot-swap capability depends on the installed Honeywell I/O architecture and rack configuration. Maintenance personnel should verify system procedures before removing or installing the assembly.

Field Installation Guidelines

• Install the MU-TAIH23 according to the approved Honeywell FTA mounting arrangement and system wiring documentation.
• Separate analog signal cables from high-voltage power cables to reduce electromagnetic interference.
• Connect cable shields according to the plant grounding standard and avoid multiple-point shield grounding.
• Verify field transmitter loop polarity before energizing the analog input circuit.
• Inspect terminal connections for correct tightening and mechanical stability.
• Confirm the DCS channel configuration matches the connected transmitter signal type before commissioning.
