Honeywell FS-SICC-1011/L15 RUSIO System Interconnection Cable

Configured for signal interconnection between RUSIO I/O assemblies and field termination interfaces in Honeywell Safety Manager and Experion PKS systems, the Honeywell FS-SICC-1011/L15 (FS-SICC-1011 System Interconnection Cable) provides direct physical signal and power routing through shielded multi-core cabling.

Hardware Specifications

Parameter	Specification
Model	FS-SICC-1011/L15
Brand	Honeywell
Origin	USA
Product Type	RUSIO System Interconnection Cable
Cable Length	15 m
Connector Type	Female Sub-D Connector
Cable Construction	Shielded multi-core / twisted pair cable
Operating Voltage	24 VDC nominal
Maximum Voltage	36 VDC
Wire Gauge	24 AWG - 28 AWG
Operating Temp	-40 deg C to +70 deg C
Storage Temp	-40 deg C to +85 deg C
Relative Humidity	5% to 95% non-condensing
Jacket Material	Industrial PVC flame-retardant oil-resistant jacket
Shielding	Braided and foil shield structure
Power Consumption	Passive cable assembly, no independent power consumption

Honeywell Process Control Interconnection Characteristics

The FS-SICC-1011/L15 supports physical signal transmission within Honeywell Safety Manager and Experion PKS architectures. The shielded cable construction reduces electromagnetic interference during I/O signal transfer between RUSIO modules, termination assemblies, and marshalling interfaces.

In addition, the cable assembly maintains separated signal paths through multi-core wiring, which supports channel-to-channel isolation practices used in process control installations. The assembly does not process 4-20 mA HART signals or FOUNDATION Fieldbus communication directly; instead, it provides the electrical connection path between compatible Honeywell I/O hardware interfaces.

Frequently Asked Questions

Q: Does the FS-SICC-1011/L15 require an external power supply?
A: No. The FS-SICC-1011/L15 is a passive interconnection cable and does not contain active electronic circuits or independent power requirements.

Q: What connector type does the FS-SICC-1011/L15 use?
A: The cable uses a female Sub-D connector configuration for connection between compatible Honeywell RUSIO I/O assemblies and field interface equipment.

Q: How should the cable shield be installed in an industrial cabinet?
A: The shield should follow the system grounding design. Installers should avoid multiple unintended ground paths and maintain proper separation from high-current power wiring.

Field Installation Guidelines

• Install the FS-SICC-1011/L15 using cabinet wiring practices defined for Honeywell Safety Manager and Experion PKS systems.
• Maintain physical separation between the interconnection cable and high-voltage power conductors to reduce electrical noise coupling.
• Connect the cable shield according to the approved grounding scheme of the control cabinet.
• Verify the Sub-D connector engagement before system commissioning to prevent intermittent signal interruption.
• Avoid excessive bending, mechanical stress, or sharp routing angles that may damage internal conductors.
• Confirm cable identification and termination points before connecting to RUSIO modules or field interface assemblies.
