Honeywell FS-BSDI-16UNI Digital Input Module

Configured for 16 channel digital signal acquisition in Honeywell I/O backplane environments, the Honeywell FS-BSDI-16UNI (FS-BSDI-16UNI Digital Input Module) provides direct physical/electrical execution for voltage input monitoring without external power requirements.

Hardware Specifications

Parameter	Specification
Model	FS-BSDI-16UNI
Brand	Honeywell
Product Type	Digital Input Module
Dimensions	58.5 x 28.5 x 9 mm (2.3 x 1.125 x 0.35 in)
Power Consumption	None (no external power required)
Number of Input Channels	16 digital input channels
Input Voltage	Maximum 90 V
Reverse Current	Maximum 200 mA
Reverse Voltage Drop	Less than 1 V
Approvals	CE, TUV, UL, CSA, FM
Chassis Space Requirement	None; installed on programming connector of I/O backplane

Channel-to-Channel Signal Isolation and Process I/O Interface

The Honeywell FS-BSDI-16UNI uses a direct digital input architecture for discrete voltage signal acquisition. The module accepts input signals up to 90 V and processes 16 independent digital channels through the I/O backplane connection.

Furthermore, the unit requires no additional power supply because the module receives its operating interface through the existing programming connector arrangement. The reverse current specification is limited to a maximum of 200 mA, while the reverse voltage drop remains below 1 V during protected input conditions.

For Honeywell control environments, digital input modules typically operate as part of distributed process I/O systems where electrical signal integrity and channel separation requirements must be maintained. The FS-BSDI-16UNI applies channel-oriented input handling rather than analog measurement conversion, making it suitable for discrete field contact and voltage status monitoring.

Frequently Asked Questions

Q: Does the FS-BSDI-16UNI require an external power supply connection?
A: No. The module requires no separate power supply and connects through the programming connector on the I/O backplane.

Q: How many digital input channels does the FS-BSDI-16UNI provide?
A: The module provides 16 digital input channels with a maximum input voltage rating of 90 V.

Q: What installation limitation applies to chassis mounting space?
A: The module requires no additional chassis space because it mounts directly on the programming connector of the I/O backplane.

Field Installation Guidelines

• Install the FS-BSDI-16UNI only on the designated Honeywell I/O backplane programming connector.
• Verify field wiring voltage levels before connecting digital input circuits to prevent input overvoltage conditions.
• Route digital signal wiring separately from high-current power cables to reduce electrical interference.
• Maintain proper shielding and grounding practices when installing the module in industrial control cabinets.
• Confirm connector seating and mechanical engagement before applying system power.
• Inspect field terminals and cable insulation before commissioning the digital input channels.
