Honeywell CC-TAIM01 Analog Input Termination Assembly

Configured for analog input signal termination in the Honeywell Experion PKS platform, the Honeywell CC-TAIM01 (CC-TAIM01 Analog Input Termination Assembly) provides direct electrical interface between field wiring and the associated analog input module. The associated spare part number is 51305959-175, while the corresponding IOTA variant is identified as 51308363-175.

Suffix Breakdown & Model Matrix

The available information identifies CC-TAIM01 as a fixed hardware model. No official suffix decoding or option matrix is provided in the supplied documentation. The following associated ordering references are available:

Model	Description
CC-TAIM01	Analog Input Termination Assembly
51305959-175	Spare Model
51308363-175	IOTA Analog Input Termination Assembly

Hardware Specifications

Parameter	Specification
Model	CC-TAIM01
Brand	Honeywell
Origin	USA
Product Type	Analog Input Termination Assembly (IOTA)
Spare Model	51305959-175
Associated Part Number	51308363-175
Input Type	Analog Input
Supply Voltage	24 VDC
Current Consumption	0.195 A
Estimated Shipping Dimensions	18.5 x 15 x 7.5 cm
Weight	0.3 kg
Operating Temp	Not specified
Power Consumption	Approximately 4.68 W (24 VDC x 0.195 A)

Channel Isolation and Analog Signal Interface

The CC-TAIM01 functions as the field termination interface for analog input channels. Proper field wiring practices, shield termination, and grounding methods contribute to minimizing conducted electrical noise before signal processing by the associated controller hardware.

For analog process instrumentation, signal integrity depends on correct loop wiring and compliance with the electrical characteristics of the connected transmitter. When deployed in 4-20 mA measurement loops, installation should follow the applicable Honeywell system documentation for wiring topology, grounding, and termination requirements. Where supported by the connected input module, HART communication shares the same current loop without affecting the primary analog measurement.

Frequently Asked Questions

Q: Does the CC-TAIM01 support hot replacement while the controller is operating?
A: Hot replacement capability depends on the installed Honeywell controller, carrier, and maintenance procedures. The supplied documentation does not specify hot-swap support for this termination assembly.

Q: Is the module itself responsible for analog signal conversion?
A: No. The CC-TAIM01 serves as the field termination assembly. Analog signal conditioning and conversion are performed by the associated analog input electronics.

Q: Are firmware updates required for the CC-TAIM01?
A: The termination assembly is a passive hardware interface. Firmware compatibility applies to the associated controller or analog input module rather than the termination assembly itself.

Field Installation Guidelines

• Verify all field wiring against the designated terminal assignment before energizing the system.
• Isolate field power before connecting or disconnecting terminal wiring.
• Route analog signal cables separately from high-voltage and high-current conductors to reduce electrical interference.
• Terminate cable shields according to the grounding practice specified for the control system installation.
• Confirm the connected field device operating voltage and loop configuration before applying 24 VDC supply power.
• Tighten terminal connections according to the specified installation procedure to prevent intermittent electrical contact.
