GE Multilin UR6EH UR-6EH Digital Input/Output Module

The GE Multilin UR6EH, also cataloged as the UR6EH Digital Input/Output Module, operates as a dedicated hardware component for discrete signal acquisition and output switching within the GE Multilin Universal Relay (UR) Series platforms.

Hardware Specifications

Parameter	Specification
Model	UR6EH (UR-6EH)
Brand	GE Multilin (General Electric)
Weight	2.55 kg
Module Type	Digital Input/Output Module
Product Series	Universal Relay (UR) Series
Input Channels	8 contact inputs
Output Channels	4 Form C outputs
Output State	Single Pole Double Throw (SPDT)

Deterministic Network and I/O Integration Characteristics

The UR6EH module is designed for integration within the GE Multilin Universal Relay modular chassis. The hardware performs direct discrete signal processing through contact input acquisition and Form C relay output switching. The module supports modular I/O density scaling by allowing additional signal channels to be configured within the relay platform architecture.

The module interface is intended for structured backplane communication between the I/O assembly and the Universal Relay control system. System configuration depends on the installed relay platform firmware and chassis hardware compatibility.

Frequently Asked Questions

Q: What type of output switching is provided by the UR6EH module?
A: The UR6EH provides 4 Form C outputs using SPDT contact configuration, allowing Normally Open and Normally Closed switching states.

Q: How many discrete inputs are available on the UR6EH module?
A: The module provides 8 contact inputs for discrete signal monitoring.

Q: Is the UR6EH designed for standalone operation?
A: No. The UR6EH is a modular I/O component intended for installation within the GE Multilin Universal Relay chassis architecture.

Field Installation Guidelines

Install the UR6EH module only in a compatible GE Multilin Universal Relay chassis position. Verify module orientation and mechanical seating before applying system power.

Use appropriate industrial wiring practices for contact input and relay output terminals. Maintain separation between signal wiring and high-energy conductors to reduce electrical interference.

Connect cable shields according to the system grounding design. Avoid routing low-level contact signal wiring parallel to high-voltage switching conductors.

Confirm firmware and configuration compatibility between the installed relay controller and the UR6EH hardware before commissioning.
