GE IS200VCMIH2BEE VME Communication Interface Module

Configured for deterministic data exchange between VME controllers and I/O boards in the GE Mark VI/VIe Speedtronic control system, the GE IS200VCMIH2BEE (IS200VCMIH2BEE VME Communication Interface Module) provides direct physical and data communication execution. The module manages VME bus communication, Ethernet links, serial interfaces, synchronization, and diagnostic reporting functions.

Hardware Specifications

Parameter	Specification
Model	IS200VCMIH2BEE
Brand	GE
Origin	United States
Weight	0.5 kg
Operating Temp	-30 to 65 deg C
Product Type	VME Communication Interface Modules
Series	Mark VI / Mark VIe Speedtronic Control System
System Role	Communication interface between VME controller and I/O boards
Processor Interface	VME bus master/slave communication
Communication Protocols	Ethernet 100Base-TX, RS-232/RS-485 serial
Redundancy Support	Simplex and TMR architectures
Diagnostics	Built-in self-test, watchdog timer, fault reporting
Isolation	Optical/electrical isolation between communication channels
Connectors	VME backplane connectors and RJ-45 Ethernet ports
Mounting	Standard VME rack slot
Humidity Tolerance	5%-95% non-condensing
Storage Temperature	-40 to 85 deg C

Industrial Control Network Communication Characteristics

The IS200VCMIH2BEE integrates with GE Mark VI/VIe control architectures through VME bus communication paths. The module supports deterministic data transfer between the VME processor and connected I/O boards while maintaining synchronization and diagnostic exchange.

The VCMI module supports Profinet / EtherNet/IP deterministic network principles at the system communication level where applicable through connected control architectures. Its hardware design includes communication channel isolation, watchdog monitoring, and firmware flash compatibility considerations for maintaining module operation within Mark VI/VIe controller configurations.

The module supports simplex and triple modular redundant (TMR) system arrangements, allowing communication paths to be configured according to the controller architecture requirements.

Frequently Asked Questions

Q: What communication interfaces are available on the IS200VCMIH2BEE?
A: The module provides VME bus master/slave communication, Ethernet 100Base-TX connectivity, and RS-232/RS-485 serial communication interfaces.

Q: Does the IS200VCMIH2BEE support redundant control architectures?
A: Yes. The module supports simplex and TMR configurations within compatible GE Mark VI/VIe control system architectures.

Q: What diagnostic functions are integrated into this module?
A: The module includes built-in self-test functions, watchdog timer monitoring, and fault reporting for communication status supervision.

Field Installation Guidelines

Install the IS200VCMIH2BEE into the designated VME rack slot and confirm proper mechanical engagement with the backplane connector before applying power.

Route Ethernet and serial communication cables separately from high-voltage power wiring to reduce electromagnetic interference. Use shielded communication cables where required by the cabinet grounding design, with cable shields terminated according to industrial grounding practices.

Verify VME rack addressing, communication channel assignments, and controller configuration parameters before system startup. Confirm module diagnostic status through the Mark VI/VIe control interface after installation.
