GE IS200REBFH1ABA Mark VIe Controller PCB Module

Configured for safety control execution in GE Mark VIe turbine control system networks, the GE IS200REBFH1ABA (IS200REBFH1ABA Controller PCB Module) provides direct physical/electrical execution for real-time signal processing, redundant controller operation, and analog/digital I/O handling.

Suffix Breakdown & Model Matrix

The IS200REBFH1ABA is identified as a Mark VIe controller PCB module. The available ordering designation is provided as a complete hardware catalog number. No separate user-selectable suffix matrix information is specified in the supplied data.

Model Identifier	Description
IS200REBFH1ABA	Mark VIe Controller PCB Module

Hardware Specifications

Parameter	Specification
Model	IS200REBFH1ABA
Brand	GE
Origin	United States
Weight	0.35 kg
Dimensions	215 mm x 125 mm x 40 mm
Operating Temp	-40 deg C to +85 deg C
Power Consumption	Not specified
Processor	AMD G-Series dual-core processor, 1.6 GHz
Memory	2 GB DDR3-1066 SDRAM
Storage	128 GB Flash
Operating System	QNX Neutrino RTOS
Input Voltage	24 VDC
Signal Support	Analog and digital input/output processing
Safety Compliance	SIL2 / SIL3, IEC 61508
Redundancy Modes	Simplex, Duplex, Triple Modular Redundancy (TMR)
Humidity Rating	Up to 95% non-condensing
Mounting Type	Control cabinet PCB installation

Firmware Flash Compatibility and Redundant Control Execution

The IS200REBFH1ABA uses flash storage and QNX Neutrino RTOS for deterministic execution of control applications within the Mark VIe platform. The controller hardware supports firmware flash compatibility management for system configuration updates and application execution requirements.

The module supports simplex, duplex, and triple modular redundancy configurations. Redundant operation uses controller coordination logic to maintain synchronized processing states and execute safety-related control functions. Analog and digital signal handling is integrated through the Mark VIe control architecture.

Frequently Asked Questions (FAQ)

Q: What redundancy configurations are supported by the IS200REBFH1ABA?
A: The module supports simplex, duplex, and Triple Modular Redundancy (TMR) configurations according to Mark VIe system architecture requirements.

Q: What operating system is installed on the IS200REBFH1ABA?
A: The module operates with QNX Neutrino RTOS for real-time control application execution.

Q: What supply voltage is required for the controller PCB module?
A: The specified input voltage is 24 VDC for controller operation.

Field Installation Guidelines

Install the IS200REBFH1ABA in the designated GE Mark VIe control cabinet location and verify mechanical mounting alignment before connection to the system interface.

Before energization, confirm the 24 VDC supply wiring polarity and inspect all connector interfaces for proper engagement. Use separated routing for low-level signal wiring and high-current power conductors to reduce electromagnetic interference.

For redundant configurations, verify controller addressing, synchronization settings, and firmware compatibility between associated modules. Maintain proper cabinet grounding practices, including correct connection of cable shields according to GE installation procedures.

Avoid installation locations exposed to conductive contamination, excessive vibration, or moisture outside the specified environmental limits.
