GE IS200JPDEG1AAA Mark VIe DC Battery Power Distribution Board

The GE IS200JPDEG1AAA, also cataloged as the IS200JPDEG1AAA DC Battery Power Distribution Board, operates as a dedicated hardware component for DC power distribution, voltage feedback, and fault monitoring within the GE Mark VIe Speedtronic Turbine Control System.

Hardware Specifications

Parameter	Specification
Model	IS200JPDEG1AAA
Brand	GE (General Electric)
Origin	United States
Weight	1.0 kg
Operating Temp	0 deg C to +60 deg C
Product Type	DC Battery Power Distribution Boards
Series	Mark VIe Speedtronic Turbine Control System
Voltage Range	18-32 VDC nominal 24 VDC or 48 VDC
Distribution Channels	24 channels
Input Isolation	1500 VAC
Voltage Rejection	60 V RMS
Power Sources	Dual power supply input support
Feedback Interface	PPDA I/O pack voltage feedback
Bus Type	Floating DC bus centered on earth through resistors
Mounting	DIN-rail mounting, vertical installation
Technology	Surface-mount PCB

Firmware Flash Compatibility and DC Power Distribution Control

The IS200JPDEG1AAA distributes DC power from battery supplies or rectifier sources to Mark VIe terminal boards and system loads. The board provides multiple distribution channels with input isolation and voltage feedback functions through the PPDA I/O pack interface.

The module integrates with Mark VIe deterministic control architectures through configured power monitoring functions. Firmware flash compatibility within the system platform allows the controller to identify power distribution status and maintain configured diagnostic parameters.

Frequently Asked Questions

Q: How many DC distribution channels are available on the IS200JPDEG1AAA?
A: The board provides 24 DC power distribution channels for connected Mark VIe system loads.

Q: What isolation level is provided by the IS200JPDEG1AAA input circuits?
A: The board provides 1500 VAC input isolation between power circuits and connected system interfaces.

Q: How does the board provide voltage feedback information?
A: Voltage feedback is provided through the PPDA I/O pack interface for Mark VIe system monitoring functions.

Field Installation Guidelines

Install the IS200JPDEG1AAA on the designated DIN rail mounting location with the board installed in the specified vertical orientation. Verify DC power input polarity and terminal connections before energizing the distribution circuit.

Maintain separation between DC power wiring and sensitive communication or signal cables. Ensure protective grounding and cabinet bonding connections follow the Mark VIe installation design.

Before commissioning, verify all connected power distribution channels, supply source configuration, and PPDA feedback wiring. Confirm voltage status and fault monitoring indications before enabling connected control hardware.
