GE DS200SHVMG1AGE High Voltage M-Frame Interface Board

Configured for high-voltage signal interfacing in the Mark V Speedtronic turbine control system, the GE DS200SHVMG1AGE (DS200SHVMG1AGE High Voltage M-Frame Interface Board) provides direct electrical execution for signal conditioning, isolation, and monitoring between exciter/drive circuits and controller assemblies.

Hardware Specifications

Parameter	Specification
Model	DS200SHVMG1AGE
Brand	GE
Origin	United States
Weight	0.5 kg
Operating Temp	0 deg C to +55 deg C
Power Consumption	Supplied through Mark V backplane: +5 VDC, +/-15 VDC
Series	Mark V Speedtronic turbine control system
Product Type	SCR High Voltage M-Frame Interface Board
Functional Acronym	SHVM
Voltage Handling	High-voltage signal interfacing, typically >600 V
Connectors	Eight plug connectors, edge connectors, multi-pin signal connectors
Signal Processing	Voltage dividers, isolation transformers, filtering components
Protection Components	Fuses with LED indicators
Diagnostics	LED status indicators, RESET button, test points
PCB Coating	Conformal coating

Industrial Control and Drive Interface Processing

The DS200SHVMG1AGE is designed for GE Mark V drive and exciter interface applications. The board processes high-voltage feedback and control signals through isolation components, voltage scaling circuits, and filtering networks before communication with the controller backplane.

The interface architecture supports deterministic signal transfer within the Mark V control rack. Voltage isolation and signal conditioning circuits provide electrical separation between high-voltage field circuits and low-voltage controller electronics.

The board follows GE industrial control revision management practices, requiring firmware and hardware compatibility verification when integrated into existing Mark V assemblies. Backplane communication and I/O density scaling depend on the installed controller configuration and associated interface boards.

Frequently Asked Questions

Q: What type of signals does the DS200SHVMG1AGE process?
A: The board processes high-voltage interface signals associated with GE Mark V exciter and drive subsystems, using isolation and scaling circuits for controller monitoring.

Q: What protection components are installed on the SHVM board?
A: The board includes protective fuses, LED indicators, voltage isolation components, and filtering elements for high-voltage interface circuits.

Q: How is the board connected to the Mark V system?
A: The module connects through Mark V rack backplane edge connectors and dedicated multi-pin connectors for high-voltage signal interfaces.

Field Installation Guidelines

Install the DS200SHVMG1AGE only in the designated Mark V rack position with the correct connector orientation. Verify that high-voltage circuits are de-energized before removing or installing the board.

Route high-voltage signal wiring separately from low-level control and communication wiring to reduce electrical interference. Connect cable shields according to cabinet grounding practices and maintain proper separation between field power circuits and controller signal paths.

Inspect plug connectors, fuse indicators, and PCB surfaces before installation. Apply standard ESD protection procedures when handling the circuit board.
