GE DS200CPCAG1A Power Connect Board

The GE DS200CPCAG1A, also cataloged as the DS200CPCAG1A Power Connect Board, operates as a dedicated hardware component for power distribution and contactor pilot control within the GE Mark V Speedtronic and EX2000 control platforms.

Hardware Specifications

Parameter	Specification
Model	DS200CPCAG1A
Brand	General Electric (GE)
Origin	United States
Weight	0.45 kg
Dimensions	23.8 cm high x 8.6 cm
Operating Temp	-35 to 65 deg C
Power Consumption	25 VDC power supply input
Functional Name	Power Connect Board / Contactor Pilot Card
Functional Acronym	CPCA
System Series	Mark V Speedtronic / EX2000
Board Revision	A Function Revision
PCB Coating	Normal Coating
Protection Circuit	On-board fused protection circuits
Interface Type	Ribbon and plug connector interfaces

Firmware Flash Compatibility and Backplane Control Interface

The DS200CPCAG1A is designed for GE industrial control architectures where controlled power routing and contactor pilot functions are executed through board-level electrical interfaces. The board provides power distribution paths between control electronics and connected drive components, with integrated voltage scaling and filtering circuits.

The board revision identification supports compatibility management within Mark V and EX2000 assemblies. Installation replacement procedures require verification of hardware revision, connector configuration, and system-level compatibility before energization.

Frequently Asked Questions

Q: What is the primary function of the DS200CPCAG1A board?
A: The DS200CPCAG1A functions as a Power Connect Board and Contactor Pilot Card, providing electrical distribution, contactor pilot control, and interface functions within GE Mark V and EX2000 systems.

Q: Does the DS200CPCAG1A support hot-swap replacement?
A: The board is a fixed control assembly component. Power isolation and system shutdown procedures are required before removal or installation.

Q: What power supply voltage is specified for this board?
A: The board operates with a 25 VDC power supply input according to the provided technical specifications.

Field Installation Guidelines

• Verify the GE Mark V or EX2000 rack configuration before installing the DS200CPCAG1A.
• Confirm connector alignment and inspect ribbon cable and plug interfaces for mechanical damage before connection.
• Disconnect system power before removing the board to prevent electrical stress on control circuits.
• Maintain proper cable routing to avoid interference with low-level control signals.
• Connect protective grounding according to the control cabinet grounding practice.
• Inspect fuse conditions and board indicators during commissioning checks.
• Ensure replacement boards match the required hardware revision before system startup.
