The Emerson FX-340 is a high-performance positioning servo drive designed for demanding industrial motion control applications. As part of the Control Techniques product family, this unit provides precise motor control and advanced positioning logic, making it suitable for high-speed automated systems, CNC machinery, and packaging lines. The drive is engineered to deliver smooth acceleration and deceleration profiles, which helps minimize mechanical stress and improve overall system longevity.
Features
- High-speed digital signal processor (DSP) for complex motion tasks including indexing and electronic gearing.
- Integrated protection circuits for overvoltage, overcurrent, and phase loss detection.
- High-resolution feedback support to maintain strict positioning tolerances.
- Flexible communication options including standard RS-232/RS-485 interfaces with support for optional fieldbus modules.
- Robust mechanical design for reliable operation in industrial environments.
Applications
This servo drive is frequently deployed in sectors requiring high-precision motion, such as automotive assembly, electronics manufacturing, and high-speed CNC machining environments.
Technical Specifications
| Model |
FX-340 (960133-01) |
| Brand |
Emerson / Control Techniques |
| Module Type |
Positioning Servo Drive |
| Input Voltage |
230 VAC / 460 VAC (Model Dependent) |
| Output Current |
4.0 A Continuous / 8.0 A Peak |
| Feedback Compatibility |
Incremental Encoder, Resolver, SinCos |
| Operating Temperature |
0 to 50 deg C |
| Storage Temperature |
-20 to 70 deg C |
| Protection Class |
IP20 |
| Communication |
RS-232 / RS-485 (Fieldbus optional) |
Installation Guidelines
- Ensure the drive is installed in a clean, dry environment within an IP20 or higher rated enclosure.
- Maintain adequate clearance around the unit to facilitate proper airflow and cooling.
- Always verify that the input voltage matches the specific drive configuration before powering the system.
- Ensure that all signal and power cables are properly shielded and routed away from high-EMI noise sources.
- Power down the unit and wait for internal capacitors to discharge before performing any wiring or maintenance tasks.
FAQ
What type of feedback sensors does the FX-340 support?
The drive is compatible with incremental encoders, resolvers, and SinCos feedback devices to ensure high-resolution positioning.
Can this drive be used in a standalone configuration?
Yes, while it integrates seamlessly into PLC-based architectures via fieldbus, it is also capable of localized, standalone task execution.
