The DS200PTBAG1A is a specialized Protection Termination Module designed for integration within the General Electric Mark V Speedtronic turbine control architecture. This hardware serves as a critical interface layer between field instrumentation and the primary turbine control system, ensuring the accurate monitoring and protection of steam and gas turbine assets. By facilitating reliable signal routing, the module supports the deterministic performance required for emergency shutdown and operational safety sequences in heavy-duty power generation environments.
Features
-
System Compatibility: Engineered specifically for the Mark V Speedtronic platform, ensuring seamless integration with existing turbine control cabinets.
-
Signal Termination: Provides a structured interface for field-side wiring, simplifying maintenance and diagnostic procedures.
-
Group 1 Classification: Designed as a Group 1 component, adhering to established hardware routing and logic standards for the Mark V series.
-
Integrated Connectivity: Features a dedicated JJS/T connector port to maintain hardware-level compatibility with standard Mark V control configurations.
-
Robust Construction: Built to operate reliably in demanding industrial conditions, supporting consistent performance for legacy system maintenance.
Installation Guidelines
-
Handling: This module contains sensitive electronic components. Always use proper ESD (electrostatic discharge) protection during handling and installation.
-
Power Status: Ensure all power to the Mark V control rack is disconnected before inserting or removing the module to prevent electrical damage.
-
Mounting: The module is designed for standard mounting within the control cabinet, typically utilizing DIN-rail or panel stand-offs. Ensure all mounting hardware is securely fastened to prevent vibration-induced loosening.
-
Wiring: Verify that all field connections are correctly terminated according to the specific turbine control loop diagrams. Ensure cables are properly routed and shielded to minimize EMI interference.
-
Environment: Maintain the cabinet environment within the specified operating temperature range (0 to 60 deg C) to ensure component longevity.
Technical Specifications
| Model |
DS200PTBAG1A |
| Brand |
GE Fanuc |
| Series |
Mark V Speedtronic |
| Product Type |
Protection Termination Module |
| Operating Temperature |
0 to 60 deg C |
| Storage Temperature |
-40 to 85 deg C |
| Series Group |
Group 1 |
| Connector Type |
JJS/T |
| Mounting |
DIN Rail / Panel Mount |
FAQ
Is the DS200PTBAG1A compatible with non-Mark V systems?
No, this module is specifically engineered for the GE Mark V Speedtronic turbine control system and is not intended for use in other control platforms.
Does the JJS/T connector require external wiring?
In standard Group 1 applications, the JJS/T connector is often designated as unused; however, it remains on the board for factory-standard hardware compatibility. Please consult your specific turbine wiring schematic to determine if your application requires utilization of this port.
What is the recommended storage environment for this module?
To ensure the integrity of the PCB, store the module in a dry, climate-controlled area within the temperature range of -40 to 85 deg C, preferably in its original anti-static packaging.
