ABB DSQC658 DeviceNet M/S Single

Configured for DeviceNet master/slave communication within the ABB IRC5 controller architecture, the ABB DSQC658 3HAC037084-001 (DSQC658 DeviceNet M/S Single) provides the controller with a dedicated DeviceNet communication interface. The supplied data identifies the unit as a single DeviceNet M/S module for ABB IRC5 systems.

Hardware Specifications

Parameter	Specification
Model	DSQC658
Brand	ABB
Part Number	3HAC037084-001
Product Type	DeviceNet M/S Single
Application Platform	ABB IRC5 industrial robot controller
Communication Interface	DeviceNet
Communication Role	Master / Slave
Mounting	Controller rack / chassis installation
Weight	0.08 kg
Dimensions	Not specified; estimated shipping size: 2 x 8.7 x 12.5 cm
Operating Temp	Typically 0 deg C to +55 deg C
Power Consumption	Not specified in supplied data
Protection Class	IP20
Hardware Function	DeviceNet network interface for IRC5 controller architecture

DeviceNet Communication Interface

The DSQC658 provides a dedicated DeviceNet communication function within the IRC5 controller environment. It supports a master/slave operating role, allowing the controller architecture to exchange DeviceNet data with connected field devices.

Furthermore, the module is intended for installation inside the IRC5 controller cabinet rather than direct exposure to the plant environment. The supplied information does not specify DeviceNet baud rate, node capacity, current consumption, or connector pin assignment; therefore, these values should be verified against the applicable ABB hardware manual before system configuration.

The module also forms part of the ABB controller hardware architecture. Consequently, physical installation must follow the rack position and backplane requirements defined for the corresponding IRC5 controller configuration.

Frequently Asked Questions

Q: What communication protocol does the DSQC658 use?
A: The supplied specification identifies the DSQC658 as a DeviceNet M/S Single module, providing DeviceNet master/slave communication.

Q: What controller platform is compatible with the DSQC658?
A: The supplied data identifies the ABB IRC5 industrial robot controller platform as the intended application.

Q: Is the power consumption specified for this module?
A: No. The supplied product information does not provide a power-consumption value. The applicable ABB hardware documentation should be used for cabinet power-budget calculations.

Field Installation Guidelines

1. Install the DSQC658 in the designated ABB IRC5 controller rack or chassis position.
2. Confirm the controller configuration before inserting the communication module.
3. Keep DeviceNet cabling separated from high-current motor and power wiring where practical.
4. Maintain correct cable shielding and grounding practices according to the DeviceNet installation specification.
5. Verify connector orientation and mechanical seating before energizing the controller.
6. Confirm DeviceNet network configuration, node addressing, and master/slave assignment through the applicable ABB controller configuration documentation.
7. Do not apply unverified supply voltage or external wiring connections to the module.
8. After installation, check controller diagnostics and DeviceNet communication status before returning the robot system to service.
