ABB CI871K01 Profinet IO Interface

Configured for Profinet I/O communication, the ABB CI871K01 (CI871 Profinet I/O Interface) provides network communication between ABB control hardware and Profinet I/O devices. The package includes the CI871 communication interface and TP867 baseplate.

Hardware Specifications

Parameter	Specification
Model	CI871K01
Base Model	CI871
Product ID	3BSE056767R1
Brand	ABB
Product Type	Communication Module
Function	Profinet IO Interface
Package Contents	CI871 Communication Interface + TP867 Baseplate
Communication Network	Profinet IO
Dimensions	127.5 mm D x 186 mm H x 59 mm W
Weight	0.7 kg
RoHS	Complies with EU Directive 2011/65/EU
WEEE Category	Category 5 - Small Equipment
Batteries	0
HS Code	851762
Customs Tariff Number	85176200

Profinet IO Communication and Hardware Integration

The CI871 provides the communication interface required for Profinet IO connectivity. It operates as a dedicated network component rather than as a field signal termination device.

The supplied TP867 baseplate provides the specified mechanical mounting interface for the CI871. Therefore, installation should maintain the manufacturer's prescribed baseplate arrangement and physical clearances.

For network operation, Profinet cabling should follow the applicable industrial Ethernet wiring practices. Keep communication cables separated from high-voltage or high-current conductors where practical, and maintain appropriate shielding and grounding practices.

The supplied data does not specify communication speed, supported Profinet device count, network topology limits, firmware compatibility, or backplane current consumption. These parameters should therefore be verified against the applicable ABB system documentation before system configuration.

Frequently Asked Questions

Q: What is included with the ABB CI871K01 package?
A: The package includes one CI871 Communication Interface and one TP867 Baseplate.

Q: What network function does the CI871K01 provide?
A: It provides a Profinet IO communication interface for connecting compatible industrial control hardware with Profinet IO devices.

Q: What are the physical dimensions and weight of the package hardware?
A: The supplied product data specifies 127.5 mm depth, 186 mm height, 59 mm width, and 0.7 kg net weight.

Field Installation Guidelines

• Install the CI871 on the specified TP867 baseplate and secure the assembly according to ABB mechanical installation requirements.
• Verify the mounting position before connecting network or system wiring.
• Route Profinet communication cables separately from power conductors where practical to reduce electromagnetic interference.
• Maintain cable bend radius and connector access required by the selected industrial Ethernet cabling system.
• Apply the applicable shield termination and protective grounding method defined by the system installation design.
• Confirm connector engagement before commissioning network communication.
• Verify the installed module identification against the configured CI871 hardware before system startup.
• Do not assume operating temperature, power consumption, network capacity, or firmware compatibility from the supplied product identification alone; verify these values against the applicable ABB documentation.
