ABB CI854AK01 PROFIBUS-DP/V1 Communication Interface

Configured for PROFIBUS-DP/V1 communication within ABB AC 800M systems, the ABB CI854AK01 (CI854 Communication Interface) provides the physical interface between the controller platform and PROFIBUS network devices. The package includes the CI854 communication interface and TP854 baseplate. This model is a legacy spare part and is not intended for new installations.

Hardware Specifications

Parameter	Specification
Model	CI854AK01
Product ID	3BSE030220R1
Brand	ABB
Product Type	Communication Module
Communication Protocol	PROFIBUS-DP/V1
Included Components	CI854 Communication Interface, TP854 Baseplate
Origin	Not specified in supplied data
Weight	0.7 kg
Dimensions	59 mm W x 186 mm H x 127.5 mm D
Operating Temp	Not specified in supplied data
Power Consumption	Not specified in supplied data
HS Code	851762
Customs Tariff Number	85176200
WEEE Category	5 - Small Equipment
Battery Quantity	0
Application Status	Spare part for systems placed on the market before July 22, 2017

PROFIBUS-DP/V1 Communication Characteristics

The CI854 provides the communication interface required for PROFIBUS-DP/V1 connectivity in an AC 800M system. Therefore, the module handles the interface function while the TP854 provides the associated mounting and connection base.

The supplied ABB data identifies the product as a PROFIBUS-DP/V1 interface but does not specify channel count, transmission speed, cable limits, or electrical current consumption. These parameters should therefore be verified against the applicable ABB system documentation before installation.

The CI854AK01 also has a specific lifecycle restriction. ABB identifies this version as a non-RoHS 2 compliant spare part for existing systems. For new installations, ABB specifies CI854BK01, Product ID 3BSE069449R1, instead.

Frequently Asked Questions

Q: What components are included with CI854AK01?
A: The package includes one CI854 Communication Interface and one TP854 Baseplate.

Q: Can CI854AK01 be used for a new AC 800M installation?
A: ABB identifies CI854AK01 as a legacy spare part. For new installations, ABB specifies CI854BK01, Product ID 3BSE069449R1.

Q: What environmental operating temperature is specified for CI854AK01?
A: The supplied product data does not state an operating temperature range. The applicable ABB hardware manual should be consulted for environmental limits.

Field Installation Guidelines

Install the CI854 communication interface on the specified TP854 baseplate and verify mechanical engagement before energizing the system.

Route PROFIBUS cabling separately from high-voltage power conductors and high-current switching circuits where practical. Maintain appropriate cable shielding and termination according to the PROFIBUS installation specification and the applicable ABB system documentation.

Before commissioning, verify the installed module identification, baseplate compatibility, network connections, and controller configuration. Also confirm that the legacy CI854AK01 status is acceptable for the existing system, because ABB specifies CI854BK01 for new installations.
