Honeywell CC-KFPVR5 51202353-111 Fiber Optic Ethernet

Configured for fiber optic Ethernet communication in a Honeywell control network, the Honeywell CC-KFPVR5 51202353-111 (CC-KFPVR5 Fiber Optic Ethernet Cable) provides direct physical signal transmission between compatible Input/Output Link (IOL) interfaces. The 0.5 m cable assembly is designed for optical data communication using IOL connectors and specified electrical operating characteristics.

Suffix Breakdown & Model Matrix

The available documentation identifies CC-KFPVR5 51202353-111 as a complete catalog number. No official suffix allocation or ordering matrix is provided; therefore, no further model code decomposition can be confirmed.

Hardware Specifications

Parameter	Specification
Model	CC-KFPVR5 51202353-111
Brand	Honeywell
Product Type	Fiber Optic Ethernet Cable
Cable Type	Fiber Optic Ethernet
Connector Type	IOL (Input/Output Link) connectors
Cable Length	0.5 m
Operating Voltage	24 VDC
Operating Current	0.5 A
Power Consumption	12 W maximum
Origin	USA
Place of Shipment	Xiamen, China
Dimensions	16 x 16.2 x 1.5 cm
Weight	0.06 kg
Tariff Code	8537101190
Operating Temp	Not specified

Channel-to-Channel Signal Integrity

The cable is intended for point-to-point optical communication through IOL interfaces within compatible Honeywell control systems. Fiber optic transmission provides electrical isolation between connected equipment and eliminates conductive signal paths through the communication medium. Proper connector cleanliness, bend radius control, and secure connector engagement are required to maintain optical signal quality. No protocol conversion or signal conditioning functions are incorporated into the cable assembly.

Frequently Asked Questions

Q: Does this cable support hot replacement while the control system is operating?
A: The available product data does not specify hot-swap capability. Follow the installation and maintenance procedures defined for the connected Honeywell controller or I/O platform.

Q: Is shielding or grounding required for the fiber optic cable itself?
A: Optical fibers do not require electrical shielding for signal transmission. Grounding practices should follow the requirements of the connected control cabinet and associated equipment.

Q: Can the cable length be modified in the field?
A: The supplied assembly is specified as a factory-terminated 0.5 m cable with IOL connectors. Field modification of the optical cable or connectors is not recommended unless approved optical termination procedures are used.

Field Installation Guidelines

• Verify compatibility of the IOL connectors before installation.
• Inspect connector end faces for dust or contamination prior to mating.
• Avoid excessive bending, twisting, crushing, or tensile loading of the fiber optic cable.
• Route the cable separately from power conductors where practical to reduce the possibility of mechanical damage during maintenance.
• Confirm connector locking mechanisms are fully engaged after installation.
• Observe the minimum bend radius recommended for the installed fiber cable to prevent optical attenuation.
• Perform communication verification after installation according to the commissioning procedure of the connected Honeywell control system.
