Bently Nevada 3500/22-01-03-01 Transient Data Interface Module
Configured for data acquisition, rack communication, and external system interfacing in 3500 Machinery Protection System networks, the Bently Nevada 3500/22-01-03-01 (3500/22 Transient Data Interface Module) provides direct physical/electrical execution of rack-to-host communication and diagnostic data transfer.
Suffix Breakdown & Model Matrix
No formally published segmentation logic is provided for the suffix "01-03-01". It is treated as a factory configuration and compliance/options code associated with hardware revision, communication configuration, and regional certification variants.
Hardware Specifications
| Parameter |
Specification |
| Model |
3500/22-01-03-01 |
| Brand |
Bently Nevada |
| Origin |
USA |
| Operating Temp |
-20 deg C to +65 deg C |
| Communication Protocols |
Ethernet TCP/IP, Modbus, OPC |
| Data Types |
Steady-state data, transient waveform capture |
| Rack Compatibility |
3500/05 System Rack |
| Front Indicators |
Status, TX/RX, alarm LEDs |
TDI Communication and Diagnostic Data Exchange Layer
The 3500/22 TDI implements a dual-domain data pipeline between the 3500 backplane and external supervisory systems. Ethernet-based TCP/IP transport is used for configuration access and continuous data streaming, while Modbus and OPC interfaces support structured integration with control and asset management platforms.
The module maintains concurrent acquisition of steady-state and transient waveform datasets without interrupting rack-level protection execution. System 1 integration enables buffered transfer of time-synchronous vibration and machinery state datasets.
Cross-talk suppression is handled at the backplane interface layer to maintain signal integrity during high-throughput waveform extraction cycles across multiple monitored channels.
Frequently Asked Questions (FAQ)
Q: Can the 3500/22 module be removed while the rack remains powered?
A: The module supports hot-swap under controlled rack configuration conditions. Communication interruption occurs during physical removal, but protection modules continue local execution via backplane.
Q: Does the module affect backplane signal acquisition timing?
A: The TDI operates asynchronously to protection processing. Backplane data acquisition timing for monitoring modules is not altered by Ethernet data transmission load.
Q: What is the dependency requirement for System 1 software?
A: System 1 is required for advanced transient waveform analysis and historical data reconstruction. Basic communication via Modbus and OPC does not require System 1.
Field Installation Guidelines
-
Install only in the left-most slot of the 3500/05 rack as defined by system architecture
-
Verify backplane connector alignment prior to insertion to avoid pin miscontact
-
Ensure Ethernet cabling follows shielded twisted-pair grounding practices at cabinet entry point
-
Maintain separation between communication cabling and high-energy power conductors to reduce EMI coupling
-
Apply rack configuration validation via 3500 configuration software before enabling external communication interfaces
