The Bently Nevada 3500/05-01-01-00-00-00 is a 19-inch full-size rack chassis designed to house the components of the 3500 Machinery Protection System. This rack provides the physical mounting, power distribution, and communication backplane required for the operation of 3500 series monitoring modules. As a critical component of the Bently Nevada 3500 series, this chassis supports up to 14 module slots, allowing for flexible configuration of monitoring, relay, and communication interfaces.
Features
- Standard 19-inch rack-mount design for integration into industrial control cabinets.
- Accommodates up to 14 module slots for versatile system expansion.
- Integrated backplane for high-speed communication between installed modules.
- Panel mount configuration for secure, fixed-location installation.
- Robust construction designed for industrial environments.
Technical Specifications
| Model |
3500/05-01-01-00-00-00 |
| Rack Size |
19-inch (14 slots) |
| Mounting Type |
Panel Mount |
| Agency Approvals |
None |
| Weight |
5.95 kg |
Installation Guidelines
- Ensure the rack is mounted in a clean, dry, and vibration-dampened environment to maintain system integrity.
- Verify that the panel cutout dimensions are compatible with the 19-inch rack footprint before installation.
- Always power down the system before inserting or removing any monitoring modules from the rack slots to prevent electrical damage.
- Ensure proper grounding of the chassis to the cabinet ground bus to minimize EMI and protect against electrical surges.
- Maintain adequate clearance around the rack to allow for proper airflow and cooling of the internal modules.
FAQ
Is this rack compatible with all 3500 series modules?
Yes, this 19-inch full-size rack is designed to be the primary housing for standard 3500 series monitoring modules, relay modules, and communication gateways.
Does this unit include power supplies?
No, this order code represents the chassis rack only. Power supplies and monitoring modules must be ordered and installed separately according to your specific system requirements.
