Bently Nevada 3500/01 129133-01 Rack Configuration Software
The Bently Nevada 3500/01 129133-01, also cataloged as the 3500/01 rack configuration software, operates as a dedicated software component for rack-level configuration, module parameter definition, and communication mapping within the 3500 Machinery Protection System.
Configured for system-level configuration management in 3500 monitoring architectures, the Bently Nevada 3500/01 129133-01 (3500/01 rack configuration software) provides direct logical execution for monitor module setup, alarm threshold definition, and communication gateway parameterization across API 670 compliant racks.
Hardware Specifications
| Parameter |
Specification |
| Model |
3500/01 |
| Part Number |
129133-01 |
| Brand |
Bently Nevada |
| Origin |
USA |
| Weight |
0.8 kg |
| Dimensions |
16 cm x 16 cm x 12 cm |
| HS Code |
85389091 |
| Function |
Rack configuration software for 3500 system |
| Compliance |
API 670 machinery protection standard |
Bently Nevada 3500 System Configuration & Communication Layer
Within Bently Nevada 3500 system architecture, the 3500/01 software defines rack-level behavior by mapping module interaction logic, alarm setpoint structures, and communication pathways between monitoring modules and external systems.
Configuration data is distributed to rack components via Ethernet or Modbus gateways, enabling deterministic alignment of vibration channels, process variables, and relay outputs. System integrity depends on correct propagation of configuration sets across monitor modules, communication modules, and redundant system power configurations.
Frequently Asked Questions (FAQ)
Q: Does 3500/01 execute real-time monitoring functions directly?
A: No. It defines configuration parameters that are executed by 3500 hardware monitor modules.
Q: Can configuration be modified while the system is running?
A: Yes. Online configuration is supported, subject to module firmware compatibility and system state.
Q: Is 3500/01 required for API 670 compliance?
A: Yes. Proper system configuration via 3500/01 is required to maintain API 670 compliant machinery protection behavior.
Field Installation Guidelines
-
Install the software on an engineering workstation connected to the 3500 rack network.
-
Verify communication access to rack interface modules before uploading configuration data.
-
Maintain backup of existing configuration prior to parameter modification.
-
Apply configuration changes in controlled sequence to avoid transient alarm conditions.
-
Ensure module firmware compatibility before deploying updated configuration sets.
-
Validate system behavior after download using controlled test procedures.
